Satellite A660D Detailed Product Specification
Model Name: A660D-ST2G01
C1
2
Operating System
®
Genuine
Windows
7 Home Premium 64-bit
3
Processor
and Graphics
VISION Technology - Ultimate from AMD Featuring
AMD Phenom™ II Quad Core Mobile Processor P920
1.6 GHz, 2.0MB L2 Cache
o
AMD M880G Chipset
ATI Mobility Radeon™ HD 5650 with 1GB DDR3 discrete graphics
memory, plus up to 1661MB dynamically allocated shared graphics
memory.
o Total Available Graphics Memory 2685MB
5
Memory
Configured with 4GB (2GB+2GB) DDR3 (max 8GB)
6
Storage Drive
500GB (7200 RPM); Serial ATA hard disk drive
TOSHIBA Hard Drive Impact Sensor (3D sensor)
Fixed Optical Disk Drive
DVD SuperMulti drive with Labelflash
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (6x),
DVD-RW (6x), DVD+R (8x), DVD+R DL (6x), DVD+RW (8x),
DVD-RAM (5x)
®
o Uses Labelflash
media to burn high quality labels directly to disc
8
Display
16.0" diagonal widescreen HD TruBrite
native resolution
o Native support for 720p content
o 16:9 aspect ratio
o LED backlight
Sound
Built-in harman/kardon
®
stereo speakers
DOLBY
®
Advanced Audio™
Input Devices
Premium Glossy US LED backlit keyboard with 10-key numeric keypad
(black)
TouchPad™ pointing device with multi-touch control
TouchPad™ Enable/Disable
Media Control Buttons:
o TOSHIBA eco utility™ (Energy-saving mode)
o Mute
o Media
o CD/DVD control buttons
o Volume up, volume down
Communications
Webcam and microphone
10/100 Ethernet
Wi-Fi
®
Wireless networking (802.11b/g/n)
Expandability
2 main memory slots accessible from the bottom. Both slots occupied
ExpressCard™ slot
Memory Card Reader
o Secure Digital, Secure Digital High Capacity, Memory Stick™,
Memory Stick PRO™, xD Picture Card, Mini SD Card, SDXC,
Multi Media Card [shared slot may require adapter for use]
Ports
Video
RGB
o
HDMI
o
Audio
o Microphone input port with Sleep and Music
o Headphone output port
1
Part Number: PSAX3U-004004
4
7
®
supporting 11 formats
®
TFT LCD display at 1366x768
9
10
© Copyright 2010 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
Data
o 4 USB v2.0 ports (3 USB + 1 eSATA/USB combo with USB
Sleep and Charge
o RJ-45 LAN port
Security
o Slot for security lock
Physical Description
Fusion
®
X2 Finish in Charcoal
Dimensions (W x D x H Front/H Rear): 14.98" x 10.0" x 1.18"/1.48"
without feet
Weight: Starting at 5.8 lbs. depending upon configuration
Power
90W (19V 4.74A) 100-240V/50-60Hz AC Adapter.
o Dimensions (W x H x D): 5.2" x 2.3" x 1.27"
o Weight: starting at 0.82 lbs.
13
Battery
6 cell/48Wh Lithium Ion battery pack
Battery Life Rating (measured by MobileMark™ Productivity 2007)
C1
Software
Toshiba Software and Utilities
TOSHIBA Recovery Disc Creator
o
TOSHIBA Service Station
o
TOSHIBA DVD Player with Resolution+ Upconvert Technology
o
TOSHIBA Face Recognition
o
TOSHIBA HW Setup Utility
o
TOSHIBA Value Added Package
o
TOSHIBA Web Camera Application
o
TOSHIBA Disc Creator
o
TOSHIBA PC Health Monitor
o
TOSHIBA Eco Utility
o
TOSHIBA Supervisor Password Utility
o
TOSHIBA Media Controller Plug-in
o
TOSHIBA Assist
o
TOSHIBA Media Controller
o
TOSHIBA Bulletin Board
o
TOSHIBA ReelTime
o
Third-party Software
Microsoft
o
Microsoft
o
Microsoft
o
Microsoft
o
Microsoft
o
®
Corel
o
Adobe
o
Google
o
®
Sun
o
WildTangent
o
Special Offers and Trial Software
Microsoft
o
Toshiba Online Backup (30-day trial subscription available)
o
Norton Internet Security™ 2010 (30-day trial subscription)
o
®
Intuit
o
Skype
o
NetZero
o
Environmental Specifications
This product is RoHS
Energy Star Qualified
EPEAT™ Gold Compliant
18
Temperature
Satellite A660D-ST2G01
UPC: 883974522972
11
)
Included 6 cell battery: 2 hours, 32 minutes
14
16
®
Works 9
®
Windows Media Player 12
®
Silverlight™
®
®
Windows
Live™ Essentials including Photo Gallery,
Messenger, Mail, Writer and Movie Maker
®
Internet Explorer 8
DVD MovieFactory™
®
®
Acrobat
Reader
®
Toolbar
Java™ 2 Runtime Environment
®
Orb™ Game Console
®
Office Home and Student 2007 Edition 60-day trial
®
Quickbooks
Simple Start Online
®
®
Internet Service
17
compatible
Operating
5° to 35° C
12
15
Non-operating
-20° to 60° C
Page 1 of 4
