Satellite A660 Detailed Product Specification
Model Name: A660-ST2N02
C1
2
Operating System
®
Genuine
Windows
7 Home Premium 64-bit
3
Processor
and Graphics
Intel
®
Core™ i5-460M Processor
o 2.53 GHz (2.80 GHz with Turbo Boost Technology), 3MB Cache
Mobile Intel
®
HM55 Express Chipset
Mobile Intel
®
HD Graphics with 64MB – 1696MB dynamically allocated
shared graphics memory
5
Memory
Configured with 4GB DDR3 (max 8GB)
2 memory slots accessible from the bottom. Both slots occupied.
6
Storage Drive
500GB (5400 RPM); Serial ATA hard disk drive
TOSHIBA Hard Drive Impact Sensor (3D sensor)
Fixed Optical Disk Drive
DVD SuperMulti drive with Labelflash
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (6x),
DVD-RW (6x), DVD+R (8x), DVD+R DL (6x), DVD+RW (8x),
DVD-RAM (5x)
®
o Uses Labelflash
media to burn high quality labels directly to disc
8
Display
16.0" diagonal widescreen HD TruBrite
native resolution
o Native support for 720p content
o 16:9 aspect ratio
o LED backlit
Sound
Built-in harman/kardon
®
stereo speakers
DOLBY
®
Advanced Audio™
Input Devices
Premium Raised Tile LED backlit Keyboard with 10-Keypad (black)
TouchPad™ pointing device with multi-touch control
TouchPad™ Enable/Disable
Media Control Buttons:
o TOSHIBA eco utility™ (Energy-saving mode)
o Mute
o Media
o CD/DVD control buttons
o Volume up, volume down
Communications
Webcam and microphone
10/100/1000 Ethernet
Modem
9
Wi-Fi
®
Wireless networking (802.11b/g/n)
Bluetooth
®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
ExpressCard™ slot
Memory Card Reader
o Secure Digital, Secure Digital High Capacity, Memory Stick™,
Memory Stick PRO™, xD Picture Card, Mini SD Card, SDXC,
Multi Media Card [shared slot may require adapter for use]
Ports
Video
RGB
o
HDMI-CEC (REGZA LINK™)
o
Audio
o Microphone input port with Sleep and Music
o Headphone output port
Data
1
Part Number: PSAW0U-06H031
4
7
®
supporting 11 formats
®
TFT LCD display at 1366x768
10
11
© Copyright 2010 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
o 4 USB v2.0 ports (3 USB + 1 eSATA/USB combo with USB
Sleep and Charge
o RJ-11 port
o RJ-45 LAN port
Security
o Slot for security lock
Physical Description
Fusion
®
X2 Finish in Charcoal
Dimensions (W x D x H Front/H Rear): 14.98" x 10.0" x 1.18"/1.48"
without feet
Weight: Starting at 6.5 lbs. depending upon configuration
Power
65W (19V 3.42A) 100-240V/50-60Hz AC Adapter.
o Dimensions (W x H x D): 4.2" x 1.85" x 1.20"
o Weight: starting at 0.55 lbs.
14
Battery
6 cell/48Wh Lithium Ion battery pack
Battery Life Rating (measured by MobileMark™ Productivity 2007)
C1
Software
Toshiba Software and Utilities
Bluetooth Stack for Windows by Toshiba
o
Bluetooth Monitor
o
TOSHIBA App Place
o
TOSHIBA Assist
o
TOSHIBA BookPlace™
o
TOSHIBA Bulletin Board
o
TOSHIBA Disc Creator
o
TOSHIBA eco Utility™
o
TOSHIBA Face Recognition
o
TOSHIBA HDD/SSD Alert
o
TOSHIBA HW Setup Utility
o
TOSHIBA Laptop Checkup
o
TOSHIBA Media Controller
o
TOSHIBA Password Utility
o
TOSHIBA PC Health Monitor
o
TOSHIBA Recovery Disc Creator
o
TOSHIBA ReelTime
o
TOSHIBA Service Station
o
TOSHIBA Supervisor Password Utility
o
TOSHIBA Value Added Package
o
TOSHIBA Web Camera Application
o
Third-party Software
Adobe
o
Corel Label@Once
o
Google
o
Google
o
Internet Explorer 8
o
Microsoft
o
Microsoft
o
Microsoft
o
Microsoft
o
WildTangent
o
Special Offers and Trial Software
®
Intuit
o
KidZui™, The Internet for Kids
o
NetZero
o
Norton Internet Security™ 2011 (30-day trial subscription)
o
Skype
o
Toshiba Online Backup (30-day trial subscription)
o
Satellite A660-ST2N02
UPC: 883974598113
12
)
Included 6 cell battery: 5 hours, 7 minutes
15
SM
16
®
®
Acrobat
Reader
®
Toolbar
®
Chrome
®
17
Office Starter 2010
®
Windows Media Player 12
®
Silverlight™
®
Live Essentials
Photo Gallery
Messenger
Mail
Writer
Movie Maker
®
Games Console
®
Quickbooks
Financial Center
®
Internet Service
®
13
Page 1 of 4
