Summary of Contents for Biostar B250GT6

  • Page 1: Fcc Information And Copyright

    FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 2: Table Of Contents

    Table Of Contents FCC Information and Copyright ������������������������������������������������������������������������������� 1 Chapter 1: Introduction ������������������������������������������������������������������������������������������� 3 1.1 Before You Start ........................3 1.2 Package Checklist ........................ 3 1.3 Specifications ........................4 1.4 Rear Panel Connectors ......................5 1.5 Motherboard Layout ......................6 Chapter 2: Hardware installation �����������������������������������������������������������������������������...
  • Page 3: Chapter 1: Introduction

    B250GT6 & B250GT5 & H270GT5 Chapter 1: Introduction 1�1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: •  Prepare a dry and stable working environment with sufficient lighting.
  • Page 4: Specifications

    Windows 7 (32/64bit) / 8.1(64bit) /10(64bit) OS Support * Windows 7 (32/64bit) / 8.1(64bit) for 6th Generation Intel® Core™ Processor Family only. Biostar reserves the right to add or remove support for any OS with or without notice. 4 | Chapter 1: Introduction...
  • Page 5: Rear Panel Connectors

    B250GT6 & B250GT5 & H270GT5 1.4 Rear Panel Connectors B250GT6 B250GT5 & H270GT5 Note »  HDMI, DVI-D, VGA & mDP ports only work with an Intel® integrated Graphics Processor. »  Maximum resolution HDMI: 4096 x 2160 @30Hz, compliant with HDMI 1.4 DVI-D: 1920 x 1200 @60Hz VGA: 1920 x 1200 @60Hz mDP: 4096 x 2304 @60Hz   » When using the front HD audio jack and plug in the headset, the rear sound will be automatically Disabled. Chapter 1: Introduction | 5...
  • Page 6: Motherboard Layout

    1.5 Motherboard Layout Note »  represents the 1st pin. 6 | Chapter 1: Introduction...
  • Page 7: Chapter 2: Hardware Installation

    B250GT6 & B250GT5 & H270GT5 Chapter 2: Hardware installation 2.1 Install Central Processing Unit (CPU) Step 1: Locate the CPU socket on the motherboard Note »  Remove pin cap before installation, and make good preservation for future use. When the CPU is removed, cover the pin cap on the empty socket to ensure pin legs won’t be damaged. »  The motherboard might equip with two different types of pin cap. Please refer below instruction to remove the pin cap. Step 2: Pull the socket locking lever out from the socket and then raise the lever up.
  • Page 8 Step 4: Hold processor with your thumb and index fingers, oriented as shown. Align the notches with the socket. Lower the processor straight down without tilting or sliding the processor in the socket. Step 5: Hold the CPU down firmly, and then lower the lever to locked position to complete the installation.
  • Page 9: Install A Heatsink

    B250GT6 & B250GT5 & H270GT5 2.2 Install a Heatsink Step 1: Place the CPU fan assembly on top of the installed CPU and make sure that the four fasteners match the motherboard holes. Orient the assembly and make the fan cable is closest to the CPU fan connector.
  • Page 10: Connect Cooling Fans

    2.3 Connect Cooling Fans These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. CPU_FAN1/2: CPU Fan Header Pin Assignment Ground +12V FAN RPM rate sense Smart Fan Control (By Fan) SYS_FAN1/2/3: System Fan Header Pin Assignment Ground...
  • Page 11 B250GT6 & B250GT5 & H270GT5 Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. Step 2: Insert the DIMM vertically and firmly into the slot until the retaining clips snap back in place and the DIMM is properly seated.
  • Page 12: Expansion Slots

    2.5 Expansion Slots PCI1/PCI2: Peripheral Component Interconnect Slots •  The PCI slots support cards used in PCs include: LAN cards, sound cards, modems, TV tuner cards and other cards that comply with PCI standard. PEX16_1: PCI-Express Gen3 x16 Slot (x16 speed) • ...
  • Page 13: Jumper & Switch Setting

    B250GT6 & B250GT5 & H270GT5 Install an Expansion Card You can install your expansion card by following steps: •  Read the related expansion card’s instruction document before install the expansion card into the computer. •  Remove your computer’s chassis cover, screws and slot bracket from the computer.
  • Page 14: Headers & Connectors

    BIOS_SW1: Dual BIOS Switch The Dual BIOS Switch allows you to choose one of the BIOS ROMs (ROM1/ROM2) for boot up. Main BIOS (ROM1) Enabled The LED indicator (ROM1_LED) will light and the Main BIOS is enabled. Backup BIOS (ROM2) Enabled The LED indicator (ROM2_LED) will light and the Backup BIOS is enabled.
  • Page 15 B250GT6 & B250GT5 & H270GT5 ATXPWR2: ATX Power Source Connector The connector provides +12V to the CPU power circuit. If the CPU power plug is 4-pin, please plug it into Pin 1-2-5-6 of ATXPWR2. Assignment +12V +12V +12V +12V Ground...
  • Page 16 SATA3_1/3_2/3_3L/3_3U/3_4L/3_4U: Serial ATA Connectors These connectors connect to SATA hard disk drives via SATA cables. Pin Assignment Ground Ground Ground Note   » When using SATA SSD module on SATA-M.2 slot, the SATA3_1 connector will be disabled. JFRONT_USB3_1/3_2: Header for USB 3.0 Ports at Front Panel (JFRONT_USB3_2 only for H270GT5) This header allows user to add additional USB ports on the PC front panel, and also can be connected with a wide range of external peripherals.
  • Page 17 B250GT6 & B250GT5 & H270GT5 TB1: Thunderbolt 3 Header (only for B250GT6) This header allows user to add additional Thunderbolt ports on the PC front panel, and also can be connected with a wide range of external peripherals. Assignment Force Power...
  • Page 18: Buttons & Leds

    J_COM1: Serial Port Header The motherboard has a serial port header for connecting RS-232 Port. Assignment Carrier detect Received data Transmitted data Data terminal ready Signal ground Data set ready Request to send Clear to send Ring indicator 5050_RGBLED1/2: RGB LED Device (5050 SMD) Header This header providers 12V power and RGB control pins for RGB LED Device (5050 SMD).
  • Page 19 B250GT6 & B250GT5 & H270GT5 LEDs Below LEDs are controlled by RACING GT program. Please refer to Chapter 3.3 for more detail software setting. 1. RGB LED Header 2. MOSFET Heatsink LED 3. on-board LEDs (x12) Chapter 2: Hardware installation | 19...
  • Page 20: Chapter 3: Uefi Bios & Software

    The BIOS can be updated using either of the following utilities: •  BIOSTAR BIOS Flasher: Using this utility, the BIOS can be updated from a file on a hard disk, a USB drive (a flash drive or a USB hard drive), or a CD-ROM.
  • Page 21 B250GT6 & B250GT5 & H270GT5 6. Select the proper BIOS file, and a message asking if you are sure to flash the BIOS file. Click “Yes” to start updating BIOS. 7. A dialog pops out after BIOS flash is completed, asking you to restart the system.
  • Page 22 Then, the BIOS Update is completed. BIOS Update Utility (through a BIOS file) 1. Installing BIOS Update Utility from the DVD Driver. 2. Download the proper BIOS from http://www.biostar.com.tw/ 3. Launch BIOS Update Utility and click the “Update BIOS” button on the main screen.
  • Page 23 B250GT6 & B250GT5 & H270GT5 5. Choose the location for your BIOS file in the system. Please select the proper BIOS file, and then click on “Open”. It will take several minutes, please be patient. 6. After the BIOS Update process is finished, click on “OK”...
  • Page 24: Software

    3.3 Software Installing Software Insert the Setup DVD to the optical drive. The driver installation program would appear if the Auto-run function has been enabled. Select Software Installation, and then click on the respective software title. Follow the on-screen instructions to complete the installation. Launching Software After the installation process is completed, you will see the software icon showing on the desktop.
  • Page 25 B250GT6 & B250GT5 & H270GT5 eHot-Line eHot-Line is a convenient utility that helps you to contact with our Tech-Support system. This utility will collect the system information which is useful for analyzing the problem you may have encountered, and then send these information to our tech-support department to help you fix the problem.
  • Page 26 Open the saved .txt file, you will see your system information including motherboard/BIOS/CPU/ video/device/OS information. This information is also concluded in the sent mail. Note »  Before you use this utility, please set Outlook Express as your default e-mail client application program. »  We will not share customer’s data with any other third parties, so please feel free to provide your system information while using eHot-Line service. »  If you are not using Outlook Express as your default e-mail client application, you may need to save the system information to a .txt file and send the file to our tech support with other e-mail application. Go to the following website http://www.biostar.com.tw/app/en/about/contact.php for getting our contact information. 26 | Chapter 3: UEFI BIOS & Software...
  • Page 27 B250GT6 & B250GT5 & H270GT5 RACING GT RACING GT is an easy-to-use program that integrates several BIOSTAR utilities and allows users to configure these utilities simultaneously and seamlessly. System Information This System Information tab provides you an overview of the basic system information.
  • Page 28 SmartEAR Smart EAR allows you to control system volume and adjust impedance setting (Low/High Gain) to optimize your headphone performance. You can easily enjoy high-quality and awesome sound. Requirements: 1. A chassis with front audio output jacks 2. An earphone or a headphone 3.
  • Page 29 B250GT6 & B250GT5 & H270GT5 Vivid LED DJ Vivid LED DJ can adjust your color scheme of on-board LEDs , MOSFET Heatsink LED and RGB LED Device. 1. Normal Mode: It balances energy consumption and system performance. 2. Default: All the setting are back to default.
  • Page 30 H/W Monitor The HW Monitor tab allows you to monitor hardware voltage, fan speed, and temperature. 1. Temperature: Shows the current CPU and system temperature. 2. Fan: Shows the current fans’ speed. 3. Voltage: Shows the current voltages of CPU and memory. 4.
  • Page 31: Chapter 4: Useful Help

    B250GT6 & B250GT5 & H270GT5 Chapter 4: Useful help 4.1 Driver Installation After you installed your operating system, please insert the Fully Setup Driver DVD into your optical drive and install the driver for better system performance. You will see the following window after you insert the DVD The setup guide will auto detect your motherboard and operating system.
  • Page 32: Ami Bios Beep Code

    4.2 AMI BIOS Beep Code Boot Block Beep Codes Number of Beeps Description Continuing Memory sizing error or Memory module not found POST BIOS Beep Codes Number of Beeps Description Success booting. Display memory error (system video adapter) 4.3 AMI BIOS post code Code Description PEI Core is started Pre-memory CPU initialization is started...
  • Page 33 B250GT6 & B250GT5 & H270GT5 Code Description South Bridge DXE initialization is started South Bridge DXE SMM initialization is started South Bridge devices initialization South Bridge DXE Initialization (South Bridge module specific) ACPI module initialization Boot Device Selection (BDS) phase is started...
  • Page 34: Troubleshooting

    4.4 Troubleshooting Probable Solution 1. There is no power in the system. Power LED does 1. Make sure power cable is securely plugged in. not shine; the fan of the power supply does not work 2. Replace cable. 2. Indicator light on keyboard does not shine. 3.
  • Page 35: Raid Functions

    B250GT6 & B250GT5 & H270GT5 4.5 RAID Functions RAID Definitions In a RAID 0 system data are split up in blocks that get written across all the drives in the array. By using multiple disks (at least 2) at the same time, this offers superior I/O performance.
  • Page 36 RAID 10 combines the advantages (and disadvantages) of RAID 0 and RAID 1 in one single system. It provides security by mirroring all data on a secondary set of disks (disk 3 and 4 in the drawing below) while using striping across each set of disks to speed up data transfers.
  • Page 37: Intel® Optane™ Technology

    B250GT6 & B250GT5 & H270GT5 4.6 Intel® Optane™ Technology (powered by 3D XPoint memory) With Intel® Optane™ technology you can unleash the power of your processor instead of it working at a fraction of its power. Eliminating that bottleneck requires better storage memory that is fast, inexpensive, and non-volatile.
  • Page 38: Appendix I: Specifications In Other Languages

    – ‫اﻟﺤﺪ اﻷﻗﺼﻰ ﻟﻠﻄﺎﻗﺔ اﻟﺤﺮارﻳﺔ ﻓﻲ ﺗﺼﻤﻴﻢ اﻟﻤﻌﺎﻟﺞ‬ ‫اﻟﻤﺮآﺰﻳﺔ‬ ‫دﻋﻢ اﻟﻤﻌﺎﻟﺞ‬ ‫ﻟﻘﺎﺋﻤﺔ‬ www.biostar.com.tw ‫ﻳﺮﺟﻰ اﻟﺮﺟﻮع إﻟﻰ اﻟﻤﻮﻗﻊ‬ INTEL® H270 (H270GT5) / INTEL® B250 (B250GT6 & B250GT5) ‫ﻣﺠﻤﻮﻋﺔ اﻟﺸﺮاﺋﺢ‬ 2400 2133 1866 DDR4 ‫. ار‬ ‫دي‬ ‫ﺗﺪﻋﻢ ﻗﻨﺎة ﻣﺰدوﺟﺔ دي‬...
  • Page 39: German

    * Windows 7 (32/64 Bit) / 8.1 (64 Bit) für die Intel® Core ™ Prozessorfamilie der 6. Generation * Biostar reserves the right to add or remove support for any OS with or without notice. APPENDIX I: Specifications in Other Languages | 39...
  • Page 40: Russian

    * Windows 7 (32/64 бит) / 8,1 (64 бит) только для 6-го поколения Intel® Core ™ семейства Поддержка ОС процессоров * Biostar оставляет за собой право добавлять или удалять поддержку любой ОС, с уведомлением или без. 40 | APPENDIX I: Specifications in Other Languages...
  • Page 41: Spanish

    * Windows 7 (32/64 bits) / 8.1 (64 bits) sólo para la familia de procesadores Intel® Core ™ de 6ª Soporte OS generación *Biostar reserva su derecho de añadir o retirar el soporte para cada OS con o sin notificación. APPENDIX I: Specifications in Other Languages | 41...
  • Page 42: Thai

    ครอบครั ว เท่ � นั ้ น * Biostar ขอสงวนสิ ท ธิ ์ ใ นก�รเพิ ่ ม หรื อ ถอดก�รสนั บ สนุ น สำ � หรั บ ระบบปฏิ บ ั ต ิ ก �ร OS ต่ � งๆ โดยไม่ ต ้ อ งแจ้ ง ให้ ท ร�บล่ ว งหน้ �...
  • Page 43 FCC条款 依照FCC条款第15部分的规定,本装置已经通过测试并且符合Class B级数字装置的限制。 此条款限制了在安装过程中可能造成的有害射频干扰并提供了合理的防范措施。本装置在 使用时会产生无线射频辐射,如果没有依照本手册的指示安装和使用,可能会与无线通讯 装置产生干扰。然而,并不保证在特定的安装下不会发生任何干扰。 如果关闭和重新开启本设备后,仍确定本装置造成接收广播或电视的干扰,用户可以使用 以下列表中的一种或多种方法来减少干扰: • 重新安装或调整接收天线。 • 增加本设备与接收设备之间的距离。 • 连接设备连接到不同的插座以便于两个设备使用不同的回路。 • 咨询经销商或富有经验的无线电工程师, 以获得更多资讯 。 本用户手册内容的变更,恕不另行通知,制造商没有解释的义务。 本用户手册的所有内容若有任何错误,制造商没有义务为其承担任何责任。所有商标和产 品名称均有其各自所有权。 未经过书面许可,不得以任何形式(部分或全部)复制此手册信息。 免责说明 本手册内容系BIOSTAR 知识产权,版权归BIOSTAR 所有。我们本着对用户负责的态度, ® ® 精心地编写该手册,但不保证本手册的内容完全准确无误。BIOSTAR 有权在不知会用户 ® 的前提下对产品不断地进行改良、升级及对手册内容进行修正,实际状况请以产品实物为 准。本手册为纯技术文档,无任何暗示及影射第三方之内容,且不承担排版错误导致的用 户理解歧义。本手册中所涉及的第三方注册商标所有权归其制造商或品牌所有人。 CE符合性简短声明 我们声明此产品符合现行标准,并满足2004/108/CE, 2006/95/CE 和1999/05/CE指令规定的所有基本要求。 防静电操作规则 静电可能严重损坏您的设备,在处理主板以及其它的系统设备的时候要特别注意,避免和...
  • Page 44 目录 第一章: 主板介绍 ������������������������������������������������������������������������������������������������������� 3 1.1 前言 ............................... 3 1.2 包装清单 ............................3 1.3 主板特性 ............................4 1.4 后置面板接口 ..........................5 1.5 主板布局图 ..........................6 第二章: 硬件安装 ������������������������������������������������������������������������������������������������������� 7 2.1 中央处理器(CPU) ........................7 2.2 散热片 ............................9 2.3 风扇接头 ............................. 10 2.4 系统内存...
  • Page 45: 第一章: 主板介绍

    B250GT6 & B250GT5 & H270GT5 第一章: 主板介绍 1�1 前言 感谢您选购我们的产品,在开始安装主板前,请仔细阅读以下安全指导说明: • 选择清洁稳定的工作环境。 • 操作前请确保计算机断开电源。 • 从抗静电袋取出主板之前 ,先轻触安全触地器或使用触地手腕带去除静电以确保安 全。 • 避免触摸主板上的零件。手持电路板的边缘 ,不要折曲或按压电路板。 • 安装之后 ,确认没有任何小零件置于机箱中,一些小的零件可能引起电流短路并可能 损坏设备。 • 确保计算机远离危险区域 ,如: 高温 、 潮湿、靠近水源的地方 。 • 计算机的工作温度应保持在0-45℃之间 • 为避免受伤,请注意以下幾點: 主板或連接器上尖銳的針腳 机箱上的粗糙边缘和尖角 破损的线缆可能引起短路 1�2 包装清单...
  • Page 46: 主板特性

    Socket 1151,Intel Core i7 / i5 / i3 / Pentium / Celeron处理器 CPU支援 CPU最大热功耗(95Watt) * 请访问 www.biostar.com.tw 获取CPU的支持列表 芯片组 INTEL® H270 (H270GT5) / INTEL® B250 (B250GT6 &B250GT5) 支持双通道DDR4 2400/2133/ 1866 4个DDR4 DIMM插槽,最大内存容量为64GB 内存 每个DIMM支持非ECC 4/ 8/ 16 GB DDR4内存模组 * DDR4-2400用于第7代Intel®Core™处理器系列。...
  • Page 47: 后置面板接口

    B250GT6 & B250GT5 & H270GT5 1�4 后置面板接口 B250GT6 B250GT5 & H270GT5 » 仅Intel集成显卡处理器支持HDMI、DVI-D、VGA和mDP端口。 » 最高分辨率: HDMI: 4096 x 2160 @30Hz ,符合HDMI 1.4规范 DVI-D: 1920 x 1200 @60Hz VGA: 1920 x 1200 @60Hz mDP: 4096 x2304 @60Hz » 当使用前置HD音频插孔并插入耳机/麦克风时 ,后置声音将自动禁用。 第一章: 主板介绍 | 5...
  • Page 48: 主板布局图

    1�5 主板布局图 » 标示为针脚1 6 | 第一章: 主板介绍...
  • Page 49: 第二章: 硬件安装

    B250GT6 & B250GT5 & H270GT5 第二章: 硬件安装 2�1 中央处理器(CPU) 步骤1: 找到主板上的CPU插槽。 » 安装前请取掉针脚保护盖,并妥善保管以备后用。移开CPU后, 请盖上保护盖以确保针脚不被损 坏。 » 主板可能配有两种不同的针脚保护盖, 请参照以下指示取掉保护盖。 步骤2: 将拉杆从插槽移出并向上抬起 步骤3: 取掉针脚保护盖 第二章: 硬件安装 | 7...
  • Page 50 步骤4: 按照箭头的指示方向,将CPU上的切口对准插槽上相应的位置,然后将CPU放入 插槽处 步骤5: 固定CPU,将拉杆闭合。 » 请确保安装专为LGA1151插座設計的CPU。 » CPU必须按正确的方向放入 ,不要强行将CPU放进插槽以免损坏CPU。 8 | 第二章: 硬件安装...
  • Page 51: 散热片

    B250GT6 & B250GT5 & H270GT5 2�2 散热片 步骤1: 请将CPU风扇组件置于CPU顶部,确保四个钉钩对齐主板上的插孔,调整其方 位,使风扇电线与CPU风扇接口间距最近。确保钉钩插槽垂直指向散热片。 步骤2: 依次把对角2个钉钩同时向下按,以固定风扇,完成CPU安装。 » 如有必要,在安装散热风扇前请先涂抹散热膏于CPU表面。 » 请务必连接CPU风扇接口。 » 请参照CPU散热片的安装手册获取正确的安装信息。 第二章: 硬件安装 | 9...
  • Page 52: 风扇接头

    2�3 风扇接头 此风扇接头支持电脑内置的冷却风扇,风扇引线和插头可能因制造商而异。 CPU_FAN1/2: CPU 风扇接头 针 定义 接地 +12V FAN RPM rate sense Smart Fan Control (By Fan) SYS_FAN1/2/3: 系统风扇接头 针 定义 接地 +12V FAN RPM rate sense Smart Fan Control (By Fan) » CPU_FAN1/2 , SYS_FAN1/2/3支持4针脚接口 ; 接线时请注意红线是正极需接到第二个针脚, 黑线接地需接到GND针脚。...
  • Page 53 B250GT6 & B250GT5 & H270GT5 步骤1: 向外推开固定夹,打开DIMM插槽。将DIMM按顺序放在插槽上, DIMM上的切 口须与插槽凹口匹配。 步骤2: 垂直插入DIMM并固定好,直到固定夹跳回原位,DIMM就位。 » 如果DIMM未顺利插入 , 请勿强行按压。将DIMM拔出,再重插一次。 内存容量 DIMM插槽位置 模组 总内存 DIMMA1 4GB/8GB/16GB DIMMA2 4GB/8GB/16GB 最大为 64GB. DIMMB1 4GB/8GB/16GB DIMMB2 4GB/8GB/16GB 双通道内存安装 为激活主板双通道功能,使用内存模组必须符合以下要求: 成对安装相同密度的内存模 组。如下表所示 双通道状态 DIMMA1 DIMMA2 DIMMB1 DIMMB2 Enabled Enabled Enabled (“O”表示内存已安装,“X ”表示内存未安装。)
  • Page 54: 扩展槽

    2�5 扩展槽 PCI1/ PCI2: 外围设备互联插槽 • PCI插槽支持用于PC的扩展卡包括:网卡 , 声卡 , 调制解调器,电视调谐器扩展卡和其 他符合PCI标准的扩展卡。 PEX16_1: PCI-Express Gen3 x16 插槽 (x16 模式) • 符合PCI-Express 3.0规范。 • 同步单向最大理论带宽为16GB/s, 总带宽为32GB/s。 PEX16_SB_1: PCI-Express Gen3 x16 插槽 (x4模式) • 符合PCI-Express 3.0规范。 • 同步单向最大理论带宽为4GB/s, 总带宽为8GB/s。 PEX1_1/1_2: PCI-Express Gen3 x1 插槽 •...
  • Page 55: 跳线设置

    B250GT6 & B250GT5 & H270GT5 安装扩展卡 请参照以下步骤安装扩展卡: • 安装扩展卡前请阅读扩展卡的相关指示说明。 • 打开电脑机箱后盖,移除螺丝和插槽支架。 • 将扩展卡按照正确的方向插入插槽, 直到扩展卡完全就位。 • 用螺丝将扩展卡的金属支架固定到机箱后置面板。 • 还原电脑机箱后盖。 • 开机 。如有必要, 可为扩展卡更改BIOS设置。 • 安装扩展卡的驱动。 2�6 跳线设置 下图展示如何设置跳线。当跳帽放置在针脚上时,跳线为闭合(close)状态。否则跳线为 断开(open)状态。 打开 闭合 闭合 Pin 1-2 JCMOS1: 清空CMOS 跳线 用户可清空CMOS数据并恢复BIOS安全设置,请按照以下步骤操作以免损坏主板。 Pin 1-2 打开: 正常操作(默认) Pin 1-2 闭合: 清空CMOS数据...
  • Page 56: 接口和插槽

    BIOS_SW1: 双BIOS切换开关 此开关让你从双BIOS (ROM1/ROM2) 中选择其一作为开机之用。 主BIOS (ROM1)运作中 , LED指示燈(ROM1_LED)將会点亮 顯示主BIOS正运作中。 备用BIOS (ROM2)运作中 , LED指示燈(ROM2_LED)將会点亮 顯示备用BIOS正运作中。 » 当你的系统開機時,不要使用此开关。 » 在刷新BIOS之前, 请确保该开关设置为你想要刷新的BIOS ROM。 2�7 接口和插槽 ATXPWR1: ATX电源接口 为了更好的兼容性,我们建议使用标准的ATX24-pin电源供应此接口的电源。 针 定义 针 定义 +3.3V +3.3V -12V +3.3V 接地 接地 PS_ON 接地 接地 接地 接地...
  • Page 57 B250GT6 & B250GT5 & H270GT5 ATXPWR2: ATX电源接口 此接口给CPU电路提供+12V电压。若CPU电源插头为4针脚,请将其插入ATXPWR2的 1-2-5-6针脚。 针 定义 +12V +12V +12V +12V 接地 接地 接地 接地 » 开机前, 请确保ATXPWR1和ATXPWR2接口都已插上电源。 » 电压不足可能导致系统不稳或者外围设备不能正常运行。当配置使用大功率设备的系统时 ,建议 您使用带有大功率输出的电源。 PANEL1: 前置面板接头 此16针脚接口包含开机,重启,硬盘指示灯,电源指示灯和扬声器接口。 针 定义 功能 针 定义 功能 10 N/A 扬声器 11 N/A 接口...
  • Page 58 SATA3_1/3_2/3_3L/3_3U/3_4L/3_4U: SATA Express 接口 此接口通过SATA数据线连接SATA硬盘。 针 定义 接地 接地 接地 » 当安装 SATA SSD 模块于 SATA-M.2 插槽时 , SATA3_1 接口将会被禁用。 JFRONT_USB3_1/3_2: 前置面板USB 3�0接头 (JFRONT_USB3_2仅H270GT5 支持) PC前置面板支持附加的USB数据线,也可连接即插即用外围设备。 针 定义 针 定义 VBUS0 SSRX1- SSRX1+ 接地 接地 SSTX2+ SSTX1- SSTX2- SSTX1+ 接地 接地...
  • Page 59 B250GT6 & B250GT5 & H270GT5 TB1: Thunderbolt 3接头 (仅B250GT6支持) PC前置面板支持附加的Thunderbolt端口,也可连接即插即用外围设备。 针 定义 Force Power CIO Plug Event I2C_MASTER_DATA SLP_3# I2C_MATSTER_CLK SLP_S5_S4# PA_PPS_INT# 接地 接地 JSPDIFOUT1: 数字音频输出接口 此接口连接PCI支架SPDIF输出接头。 针 定义 SPDIF_OUT 接地 F_AUDIO1: 前置面板音频接头 此接头可连接音频输出数据线,支持HD(高清)音频和AC’97。 HD Audio AC’97 针 定义 针...
  • Page 60: 智能开关和Led灯

    J_COM1: 串行端口 此主板有一个串行端口可接出RS-232接头。 针 定义 载波检测 接收资料 发送数据 资料终端备妥 接地信号 资料集备妥 输送要求 清除发送 振铃指示器 5050_RGBLED1/2: RGB LED装置 (5050 SMD) 接头 此接头提供12V电源与RGB控制讯号,可连接RGB LED装置(5050 SMD)。 针 电缆颜色 定义 12V (黑色) VCC12 G (绿色) LED_GREEN R (红色) LED_RED B (蓝色) LED_BLUE » 确保正确將针脚连接到LED装置 ,错误的连接可能会损坏您的LED装置或主板。 2�8 智能开关和LED灯...
  • Page 61 B250GT6 & B250GT5 & H270GT5 LED灯 下面的LED灯由RACING GT软件控制。请参考3.3章节的软件设置。 1. RGB LED 接头 2. MOSFET散热片LED灯 3. 板载LED灯(x12) 第二章: 硬件安装 | 19...
  • Page 62: 第三章: Uefi Bios和软件

    3�1 UEFI BIOS设置 • BIOS设置程序可用于查看和更改计算机的BIOS设置。开机自检时 ,按<DEL>键可进入 BIOS设置程序。 • 更多相关UEFI BIOS设置信息 , 请参考网站上的UEFI BIOS手册。 3�2 刷新BIOS 以下任意一种工具都可以刷新BIOS: • BIOSTAR BIOS Flasher: 使用此工具 ,BIOS可通过硬盘上的文件刷新 ,USB驱动刷新 , 或者CD-ROM 刷新。 • BIOSTAR BIOS刷新工具: 能够在Windows 环境下自动刷新。使用此工具,BIOS可通 过硬盘上的文件刷新 , USB驱动刷新 ,CD-ROM 刷新或者从网站上的文件地址刷新。 BIOSTAR BIOS Flasher » 此工具仅允许可使用FAT32/16格式化或单个分区的存储设备。...
  • Page 63 B250GT6 & B250GT5 & H270GT5 7. BIOS刷新后会弹出是否重启系统的对话框。 按<Y>重启系统 8. 系统引导并出现相关标识信息时,按<DEL>键进入BIOS设置。 选择<Save & Exit>,使用<Restore Defaults>功能加载系统默认值,然后选择<Save Changes and Reset>来重启系统,完成BIOS刷新。 BIOS刷新工具(通过网络) 1. 用DVD驱动安装BIOS Update Utility。 2. 使用此功能时,请确保电脑联网。 3. 打开BIOS刷新工具,然后点击”Online Update”按钮。 4. 屏幕弹出是否执行刷新BIOS程序的对话请 求,点击”Yes”开始刷新BIOS。 5. 如果BIOS有新版本,屏幕会弹出提示您下 载最新版本的对话框。点击”Yes”下载。 6. 完成下载后,屏幕弹出提示您刷新 BIOS的对话框,点击”Yes”开始刷新。 第三章: UEFI BIOS和软件 | 21...
  • Page 64 7. 刷新程序结束后,屏幕弹出提示您重启系 统的对话框。点击”OK”重启系统。 8. 系统引导并出现相关标识信息时,按<DEL>键进入BIOS设置。 选择<Save & Exit>,使用<Restore Defaults>功能加载系统默认值,然后选择<Save Changes and Reset>来重启系统,完成BIOS刷新。 BIOS刷新工具(通过BIOS文件) 1. 用DVD驱动安装BIOS刷新工具。 2. 从我们的网站www.biostar.com.tw 下载合适的BIOS. 3. 在主页面打开BIOS Updat Utility,然后点 击”Update BIOS”按钮。 4. 屏幕弹出是否执行刷新BIOS程序的对话请 求,点击”OK”开始刷新BIOS。 5. 选择BIOS文件的存放目录。然后选择合适的 BIOS文件,点击”Open”。 刷新BIOS要花几分钟时间,请耐心等待。 6. BIOS刷新过程结束后,点击”OK”重启系 统。 22 | 第三章: UEFI BIOS和软件...
  • Page 65 B250GT6 & B250GT5 & H270GT5 7. 系统引导并出现相关标识信息时,按<DEL>键进入BIOS设置。 选择<Save & Exit>,使用<Restore Defaults>功能加载系统默认值,然后选择<Save Changes and Reset>来重启系统,完成BIOS刷新。 BIOS备份 点击BIOS备份按钮,选择存储备份文件的合适 目录,然后点击”Save”。 第三章: UEFI BIOS和软件 | 23...
  • Page 66 3�3 软件 安装软件 1. 将光盘放入光驱,若Autorun功能已激活,驱动安装程序将会出现。 2. 选择Software Installation,然后点击各软件图标。 3. 根据屏幕上的指令完成安装。 启动软件 安装程序完成后,桌面上将出现软件图标。请双击图标启动软件工具。 » 所有软件的相关信息和内容若有变更 ,恕不另行通知。为使系统性能更佳,软件会不断升级。 » 下面的图片和信息仅供参考, 此主板的实际信息和设置可能与手册稍有差异。 BIOScreen 工具 此实用工具可以将开机画面个性化。您可以选择BMP格式来自定义计算机开机画面。 请参照以下步骤来更新开机画面: • 加载画面(Load Image):选择图片作为开机画面。 • 转换(Transform):转换图片并预览 。 • 更新BIOS(Update Bios): 将图片写入BIOS内存,然后完成更新。 24 | 第三章: UEFI BIOS和软件...
  • Page 67 B250GT6 & B250GT5 & H270GT5 eHot-Line eHot-Line是有助于您联系技术支持系统的便捷工具。此工具将收集系统信息,当您遇 到问题时,可提供有利分析,并发送这些信息至我们的技术支持部门,从而帮助解决此 问题。 填好表格信息后,点击“Send”发送邮件。将 出现一个确认信息对话框;点击“Send”确认 发送点击“Do Not Send”则取消操作。 如您想保存此信息到文本文件里,点击“Save As…”,出现一个保存对话框,输入文件名即 可。 第三章: UEFI BIOS和软件 | 25...
  • Page 68 输入文件名,点击“Save”,系统信息将被保 存至文本文件里。 打开已保存的文本文件,显示相关系统信息(包 括主板/BIOS/CPU/视频设备/OS)。这些信息 当然也在已发送的邮件里。 » 在使用此工具前, 请将Outlook Express设置为您的默认电子邮件连接程序。 » 我们将为用户资料保密,所以使用eHot-Line服务时 , 请放心提供您的系统信息。 » 若您未将Outlook Express设置为默认电子邮件连接程序, 也可保存您的系统信息到文件里,然 后用其它电子邮件工具发送此文件到我们的技术支持。 请访问网站http://www.biostar.com.tw/app/en/about/contact.php获取我们的联系信息。 26 | 第三章: UEFI BIOS和软件...
  • Page 69 B250GT6 & B250GT5 & H270GT5 RACING GT Utility RACING GT軟件集成几个映泰的实用程序並十分易于使用,允许用户同时无缝地配置这 些实用程序。 系统信息 提供您的基本系统信息的概述。 1� 时钟频率:显示核心频率,倍频和总线速度。 2� 主板:显示主板信息。 3� 处理器:显示处理器信息。 4� 内存:显示内存信息。 第三章: UEFI BIOS和软件 | 27...
  • Page 70 耳放调控 耳放调控允许您控制系统音量,调整阻抗设置(低/高增益),以优化您的耳机性能。 讓您可以轻松享受高品质的声音。 设置需求: 1. 带有前置音频输出插孔的机箱。 2. 耳机或头戴式耳机。 3. Windows 7 (32/64bit) / 8.1(64bit) /10(64bit)操作系统。 安装指南: 1. 确保机箱前置音频线正确连接至主板上的前置音频接头。 2. 从驱动DVD上安装RACING GT软件。 3. 将耳机或头戴式耳机连接至机箱前置或后部的音频输出接口,並启用RACING软 件。 » 如果您想使用AC’ 97前置音频输出线, 请禁用 “前置面板插孔检测功能” 。此功能在系统音频工 具中可见。 1� 音量:可调节音量大小。 2� 静音:可切换到静音状态。 3� 增益开关:使用低阻抗耳机时调至低(LO),使用高阻抗耳机时调至高(HI)。 28 | 第三章: UEFI BIOS和软件...
  • Page 71 B250GT6 & B250GT5 & H270GT5 炫彩LED 炫彩LED可调整板载LED灯、MOSFET散热片LED灯以及RGB LED装置的配色方案。 1� 普通模式(Normal):自动平衡系统性能与电源消耗。 2� 默认设置:所有设置都恢复为默认。 3� 节能模式(ECO):稍微地降低系统性能以节省能源。 4� 高性能模式(Sport):以最大限度地提高系统性能。 » ECO及Sport板载按钮以及LED灯仅限于Windows环境下运行RACING GT软件时才可以使用。 » Normal 、 ECO和Sport模式的配色方案可以通过下面的设置项目进行调整。 5� LED分区调控:选择LED开启区块。 • 烈火战车 : 所有区块的LED灯全亮。 • 系统 : 显示烈火战车区块LED灯。(MOSFET 散热片LED灯、板载LED灯 ) • LED接头1 : 显示LED接头 1 区块LED灯。(RGB LED 装置) •...
  • Page 72 硬件监测 允许您监控硬件电压,风扇转速和温度。 1� 温度信息:显示当前CPU和系统温度。 2� 风扇转速:显示当前风扇速度。 3� 电压信息:显示CPU和内存的当前电压。 4� CPU风扇/系统风扇:选择你的设置风扇。 5� 校准:校准风扇转速。 6� 关闭:关闭智能风扇功能。 7� 自动:启用智能风扇功能。 30 | 第三章: UEFI BIOS和软件...
  • Page 73: 第四章:帮助信息

    B250GT6 & B250GT5 & H270GT5 第四章:帮助信息 4�1 驱动程序安装注意事项 为获得更好的系统性能,在操作系统安装完成后,请插入您的系统驱动到光驱并安装。 插入DVD后,将出现如下所示窗口。 此设置向导将自动检测您的主板和操作系统。 A� 驱动程序安装 安装驱动程序,请点击驱动器图标。设置向导将列出主板兼容驱动和操作系统。点击各 设备驱动程序,以开始安装进程。 B� 软件安装 安装软件,请点击软件图标。设置向导将列出系统可用软件,点击各软件名称,以开始 安装进程。 C� 使用手册 除了书本形式的手册,我们也提供光盘形式的使用指南。点击Manual图标,浏览可用 相关使用指南。 » 在插入驱动之后,如此窗口未出现, 请用文件浏览器查找并执行SETUP.EXE文件。 » 若需要Acrobat Reader打开manual文件。请从网站http://get.adobe.com/reader/下载最新 版本的Acrobat Reader软件。 第四章:帮助信息 | 31...
  • Page 74: Ami Bios 哔声代码

    4�2 AMI BIOS 哔声代码 引导模块哔声代码 哔声次数 含义 持续哔声 持续哔声 BIOS 开机自检哔声代码 哔声次数 含义 系统引导成功 显存错误(系统视频适配器) 4�3 AMI BIOS 开机自检代码 代码 含义 PEI核心启动 CPU Pre-memory初始化启动 北桥Pre-memory初始化启动 南桥Pre-memory初始化启动 内存初始化,读取SPD数据 内存初始化,检测Memory presence 2D 内存初始化,编程内存时序信息 内存初始化,配置内存 内存初始化(其他) 内存安装完成 CPU post-memory初始化启动 CPU post-memory初始化,Cache初始化 CPU post-memory初始化,应用处理器初始化 CPU post-memory初始化,选择BSP CPU post-memory初始化,系统管理模式初始化...
  • Page 75 B250GT6 & B250GT5 & H270GT5 代码 含义 南桥DXE初始化启动 南桥DXE SMM初始化启动 南桥设备初始化 南桥DXE初始化 ACPI模组初始化 引导设备选择阶段启动 驱动连接启动 PCI总线初始化启动 PCI总线热拔插控制器初始化 PCI总线列举 PCI总线请求资源 PCI总线分配资源 控制台输出设备连接 控制台输入设备连接 高级IO初始化 USB初始化启动 USB复位 USB检测 9D USB启用 IDE初始化启动 IDE复位 IDE检测 IDE启用 SCSI初始化启动 SCSI复位 SCSI检测 SCSI启用 设置校对密码 设置开始 设置输入等待 AD 准备启动环境...
  • Page 76: 问题解答

    4�4 问题解答 问题 解决方法 1. 系统没有电,电源指示灯不亮,电源风 1. 确定电源线是否接好。 扇不转动。 2. 更换线材。 2. 键盘上的指示灯不亮。 3. 联系技术支持。 系统不起作用。键盘指示灯亮,电源指示 用力按压内存两端,确保内存安置于插槽 灯亮,硬盘正常运作。 中。 1. 检查硬盘与主板的连线,确定各连线是 否确实接好,检查标准CMOS设置中的驱 系统不能从硬盘启动,能从光盘启动。 动类型。 2. 硬盘随时都有可能坏掉,所以备份硬盘 数据是很重要的。 1. 备份数据和应用程序。 系统只能从光盘启动。硬盘能被读,应用 2. 重新格式化硬盘。用后备盘重新安装应 程序能被使用,但是不能从硬盘启动。 用程序和数据。 屏幕提示“Invalid Configuration” 或 “CMOS Failure”。 再次检查系统设备,确定设定是否正确 再次检查系统设备,确定设定是否正确...
  • Page 77: Raid 功能

    B250GT6 & B250GT5 & H270GT5 4�5 RAID 功能 RAID 定义 创建带区集,在同一时间内向多块磁盘写入数据,通过 把数据分成多个数据块(Block)并行写入/读出多个磁 盘以提高访问磁盘的速度分散到所有的硬盘中同时进 行读写,在整个磁盘阵列建立过程中,以系统环境为基 础,指数的大小决定了每块磁盘的容量。此技术可减少 整个磁盘的存取时间和提供高速带宽。 性能及优点 • 驱动器: 最少2块硬盘 , 最多达6块或8块, 取决于平台。 • Uses: 使用RAID 0来提高磁盘的性能和吞吐量 ,但没有冗余或错误修复能力。 • 优点: 增加磁盘的容量。 • 缺点: 整个系统是非常不可靠的,如果出现故障, 无法进行任何补救.整个数据都会丢 失。 • 容错: 否。 每次读写实际上是在磁盘阵列系统中(RAID 1),通过2个...
  • Page 78 RAID 10模式是对RAID 0/ RAID 1两种不同 模式的结合,可以同时支持带区集和镜像, 这样既可以提升速度又可以加强数据的安全 性。 性能及优点 • 驱动器: 最少4块硬盘 , 最多6或8块。 • 优点: 容量和性能的优化允许冗余的自动化。在一个阵列, 可以同时使用其它的RAID, 并允许剩余的磁盘。 • 缺点: 数据冗余需要两倍可用磁盘空间,与RAID1相同。 • 容错: 是。 RAID 5数据块和奇偶块信息跨3块或更多块 驱动器。奇偶校验数据分散分布在磁盘阵列 的全部硬盘。容错的维护是由确保数据块传 输奇偶块信息实现的,此信息被放置在不同 于那些自身可以储存信息的驱动盘里。 性能及优点 • 驱动器: 最少3块硬盘。 • 使用: RAID 5被推荐用于处理交易和普通操作服务。 • 优点: 一个理想的最佳性能的结合 , 最佳容错, 大容量和最快存储效率。 •...
  • Page 79: 英特尔® Optane™ 技术

    B250GT6 & B250GT5 & H270GT5 4�6 英特尔 Optane 技术 (由3D XPoint内存供电) ® 透过英特尔® Optane™技术,您可以完全释放处理器的威力,而不只是运用一小部分 而已。要突破这个瓶颈,则需要更佳的储存记忆体,具备快速、价格实惠、非挥发性的 特色。 英特尔® Optane 技术具有为大数据、高效能运算、虚拟化、储存、云端、游戏 与其他多种应用带来革命性改变的潜力。 性能及优点 : • 大容量内存数据库 • 快速系统恢复 • 低延迟 • 高耐力 英特尔 Optane 技术的需求简介: ® • 英特尔® Optane 内存或存储。 • 英特尔® 第7代核心中央处理器。...
  • Page 80: 附录I:产品中有毒有害物质或元素的名称及含量

    附录I:产品中有毒有害物质或元素的名称及含量 有毒有害物质或元素 部件名称 六价铬 多溴联苯 多溴二苯醚 铅 (Pb) 汞 (Hg) 镉 (Cd) (Cr(VI)) (PBB) (PBDE) PCB板 结构件 芯片及其它 主动零件 连接器 被动电子元 器件 焊接金属 线材 助焊剂,散 热 膏,标签 及其它耗材 O:表示该有毒有害物质在该部件所有均质材料中的含量在SJ/T11363-2006标准规定的限量要求以下。 X:表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T11363-2006标准规定的限量要求。 备注:在芯片及其它主动零件、连接器、被动电子元器件Pb栏位中有打X,表示Pb在该部件的某一均质材料中的含量超出 SJ/T11363-2006标准规定的限量要求,但均符合欧盟ROHS指令豁免条款。 38 | 附录I:产品中有毒有害物质或元素的名称及含量...
