- Page 1 User Manual Freezer/Refrigerator HVF325DW HVF325DS HVF325DC...
- Page 2 Thank You Thank you for purchasing a Haier Product. Please read these instructions carefully before using this appliance. The instructions con- tain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.
-
Page 3: Table Of Contents
Content 1 - Safety ..............................4 2 - Intended Use ............................11 3 - Product Description ........................12 4 - Control panel ..........................13 5 - Use ..............................14 6 - Energy saving ..........................17 7 - Equipment ............................. 17 8 - Care and Cleaning ........................18 9 - Troubleshooting ........................... -
Page 4: Safety
1 - Safety Before switching on the appliance for the first time, read the following safety hints! WARNING! Before first use ▶ Make sure there is no transport damage. ▶ Remove all packaging and keep out of children´s reach. ▶ Wait at least six hours before installing the appliance in order to ens- ure the refrigerant circuit is fully efcient. - Page 5 1 - Safety WARNING! WARNING: Do not damage the refrigerant circuit. Daily use This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and under- stand the hazards involved.
- Page 6 1 - Safety WARNING! ▶ Do not pull on the door shelves. The door may be pulled slant, the bot- tle rack, may be pulled away, or the appliance may topple. ▶ Open and close the door only with the handles. The gap between the door and the cabinet is very narrow.
- Page 7 1 - Safety WARNING! Maintenance / cleaning ▶ Make sure children are supervised if they carry out cleaning and maintenance. ▶ Disconnect the appliance from the electrical supply before un- dertaking any routine maintenance. Allow at least 7 minutes be- fore restarting the appliance, as frequent starting may damage the compressor.
- Page 8 1 - Safety Refrigerant gas information WARNING! (R600a). Make sure the refrigerant circuit is not damaged during transportation or installation. Leaking refrigerant may cause eye sources, thoroughly ventilate the room, do not plug or unplug the power cords of the appliance or any other appliance. Inform the customer service.
- Page 9 1 - Safety Intended use This appliance is intended to be used in household and similar ap- plications such as - staff kitchen areas in shops, offices and other working environ- ments; - farm houses and by clients in hotels, motels and other residen- tial type environments;...
- Page 10 1 - Safety - One-, two- and three-star compartments are not suitable for the freezing of fresh food. - If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to pre- vent mould developing within the appliance.
-
Page 11: Intended Use
2-Intended use 2.1 Intended Use “This appliance is intended to be used in household and similar applications such as – farm houses and by clients in hotels, motels and other residential type environments; – bed and breakfast type environments; – catering and similar non-retail applications. This appliance is intended for freezing food. -
Page 12: Product Description
3-Product description Picture of appliance (Fig. 3) 1 Control panel 5 Drawers 2 LED light 6 Adjustable feet 7 Removable door racks 4 Glass shelves 8 Door handle... -
Page 13: Control Panel
4-Control panel Control panel (Fig. 4) Key description A Fridge temperature adjustment key: press to select between 2, 4 and 6 Freezer and fridge convertible function: Press the ‘Freezer and fridge convertible’ key(B) for 3 seconds to achieve freezer and fridge convertible function Freezer temperature adjustment key: press to sel- ect the temperature between - 16, - 18, - 20, - 24/ press and hold 3 seconds to enter or exit super... -
Page 14: Use
5 - Use Remove all packaging materials, keep them out of children reach and dispose them in an environmentally friendly manner. Clean the inside and outside of the appliance with water and a mild detergent before putting any food in it. After the appliance has been levelled and cleaned, wait for at least 6 hours before connecting it to the power supply. - Page 15 5 - Use Notice: Display lock When display is locked, functions such as temperature setting or super freeze are di- sabled. When above operation is attempted, The lock indicator will blink for 3 times, to remind that the display is locked. 5.5 Freezer and fridge convertible function (B) When the display is unlocked, press the ‘Freezer and fridge convertible’...
- Page 16 5 - Use 5.9 Eco mode (-16°C) (C) When display is unlocked, by touching (‘Freezer Temp’ key) (C) the appliance is set into Eco mode. In this mode the energy consumption is lower, while appropriate freezing performance is still guaranteed. To exit the Eco mode select other temperature. 5.10 Power-of memory tion.
-
Page 17: Energy Saving
6-Energy saving tips Energy saving tips ▶ Make sure the appliance is properly ventilated (see INSTALLATION). ▶ Do not install the appliance in direct sunlight or in the near of heat sources (e.g. stoves, heaters). ▶ Avoid unnecessarily low temperature in the appliance. The energy consumption in- creases the lower the temperature in the appliance is set. -
Page 18: Care And Cleaning
4. In case some small part or component gets stucked inside of the fridge (bet- ween shelves or drawers), use small soft brush to release it. If you could not re- ach the part, please contact Haier service. - Page 19 8- Care and Cleaning 8-Care and Cleaning 8.2 Non-use for a longer period If the appliance is not used for an extended period of time: ▶ Take out the food. ▶ Unplug the power cord. ▶ Clean the appliance as described above. ▶...
-
Page 20: Troubleshooting
9-Troubleshooting Many occuring problems could be solved by yourself without specific expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE. The acoustic alarm can be switched of by pressing any button. 9.1 Troubleshooting Problem Possible Cause... - Page 21 9 - Troubleshooting Problem Possible Cause Possible Solution The appliance makes a • • The refrigeration unit has just • - motor sound turned itself on. This is normal It is not cold enough • The temperature is set too high. •...
- Page 22 9-Troubleshooting Problem Possible Cause Possible Solution The door is diffucult • • Once the appliance runs, it has an • Open the door seal gently to let to open. internal vacuum. air enter the appliacne. The door can’t be • Because of the appliances’s low •...
-
Page 23: Installation
10 - Installation 10.1 Unpacking ▶ Take the appliance out of the packaging. ▶ Remove all packaging materials. 10.2 Environmental conditions The room temperature should always be between 18 °C and 43 °C, since it can influence the temperature inside the appliance and its energy consumption. Do not install the appli- ance near other heat-emitting appliances (ovens, refrigerators) without isolation. - Page 24 10 - Installation 10.6 Using adjustable feet 10.6 If the freezer is unstable, the feet can be adjusted: Ro- tate the adjustable feet according to the direction of arrow (Fig. 10.6) to turn them up or down: Turning the feet clockwise raises the appliance. Turning the feet counterclockwise lowers it.
- Page 25 10 - Installation 10.9 Door Reversibility Before connecting the appliance to the power supply you should check, whether the door swing must changed from left (as delivered) to right, if this is required by the installation location and the usability. Assembly steps (Fig.
- Page 26 10 - Installation 15. Mount the door. 16. Fix upper right upper hinge with 3 screws. 17. Connect the cable connectors: 18. Fix hinge hole cover and upper left hinge cover. 19. Finished. 10.10 Handel Reversibility Assembly steps (Fig. 10.10): 10.10 Use a flat-headed screwdriver to prise off...
-
Page 27: Technical Data
11-Technical Data Trade mark Haier Model No. HVF325DW Category of the model Freezer/Refrigerator Energy Star Freezer:3.5 star/Fefrigerator:5.0 star Product group Storage volume Cooling /Freezing (L) */*** Frostfree system Climate class Voltage / Frequency 220-240V ~/ 50Hz Rated Current (A) Refrigerant R600a 44g 171/59.5/67.5... - Page 28 0060533303...
