Toshiba Portege M750-S7241 Specifications

Portégé M750 Detailed Product Specification
Model Name Description
M750-S7241 Genuine Microsoft Windows Vista® Business, Intel® Core™ 2 Duo Processor
T6570, 2GB DDR2 memory, 160GB 5400rpm (SATA) hard drive, 12.1" LED Backlit
LCD WXGA Display supporting Digital Pen, Intel® Graphics Media Accelerator,
Intel® WiFi® Link 5100AGN, Bridge Media Adapter, 4-year standard limited warranty
(1-year standard limited warranty on battery)
2
C1
Operating System
 Genuine Windows Vista® Business (SP1, 32/64-bit version)
o Recovery media for Windows® XP Tablet PC Edition
Processor and Chipset
Intel® Centrino® processor technology featuring:
 Processor
o Intel® Core™ 2 Duo Processor T6570

2.1GHz, 2MB L2, 800MHz FSB with 64-bit
 Chipset
o Mobile Intel® GM45 Express Chipset
 Wireless LAN
o Intel® Wireless WiFi Link 5100AGN (802.11a/g/n)
 Wired LAN
o Intel® Pro 82567LM Gigabit Network Connection (with AMT 4.0)
5
Memory
 Configured with 2GB PC6400 DDR2 SDRAM
 Total 2 memory slots (1 slot occupied with 2GB memory module)
 2GB (Min)/8GB (Max), with 1GB, 2GB, and 4GB PC6400 DDR2
memory modules
6
Storage Drive
 160GB (5400 RPM) Serial ATA hard disk drive; 9.5mm height
Ultra SlimBay Optical Disk Drive
 No ODD, weight saver installed
8
Display
 12.1" diagonal widescreen LED backlight LCD display at 1280 x 800
native resolution(WXGA) with indoor/outdoor enhanced viewing
supporting digital pen
9
Graphics
 Intel
®
Graphics Media Accelerator 4500MHD with 128MB-820MB
dynamically allocated shared graphics memory
Sound
 Built-in stereo speakers
 Sound Volume Control Dial
 Microphone
Input Devices
 85 key US keyboard
 TouchPad™ pointing device
 TouchPad™ Enable/Disable
 Control Buttons:
o Windows Mobility Center Button
o Toshiba Assist button
o Windows Security button
o Display Rotation button
o Cross-Functional button
o Power Button Lock
Communications
10
 Modem
 Intel® Pro 82567LM 10/100/1000 Ethernet
3
4
7
© Copyright 2008 – 2009 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this in\formation, which is subject to change without notice.
1
 Intel® Wireless WiFi Link 5100AGN (802.11a/g/n)
Expandability
 One PCMCIA – Type II/Type I Card Slot
 Bridge Media Adapter
o Secure Digital, miniSD, Memory Stick™, Memory Stick PRO™,
Memory Stick Duo™, Multi Media Card, xD Picture Card [shared
slots]
o Secure Digital slot supports SDIO
C1
Ports
 Video
o RGB (monitor) output port
 Audio
o Microphone input port
o Headphone output port
 Data
o i.LINK™ IEEE-1394
o Modem RJ-11
o Ethernet RJ-45
o USB v2.0 – 3 ports
 Supported on optional Toshiba Express Port Replicator
o RGB (monitor) output Port
o DVI-D output port
o USB v2.0 – 4 ports
10/100/1000 Ethernet port
o
 Security
o Fingerprint reader
o Reinforced Security Cable Lock Slot
Physical Description
 Dimensions (WxDxH Front/H Rear): 12.0" x 9.41" x 1.47" /1.55" without
feet
 Weight: Starting at 4.2 lbs depending upon configuration
 LCD Cover Color: Titanium Silver
Power
 75W (15V x 5A) 100-240V AC Adapter
 Dimensions (WxDxH): 5" x 2.01" x 1.20"
 Weight: starting at 0.78 lbs
14
Battery
 (4700mAh) Lithium Ion battery pack
 Dimensions (WxDxH): 4.98" x 2.74" x 0.80"
 Weight: starting at 0.71 lbs
 Battery Life (measured by MobileMark™)
o Included 6-cell battery: 5 hours, 4 minutes
Toshiba EasyGuard®
 Protect & Fix
o Toshiba PC Health Monitor
o Shock Absorbing Design
o Hard Disk Drive Protection
Portégé M750-S7241
Part Number UPC
PPM75U-05703G 883974221011
11
2 x USB v2.0
o
1 x eSATA/USB combo port with Sleep and
o
12
Charge
15
16
17

HDD Shock Absorber

LCD Panel Shock Absorber

Chassis Shock Protector

3D Accelerometer
13
Page 1 of 5
