Thiel CS3.7 Unpacking Instructions

THIEL
Ultimate Performance Loudspeakers
Please save these instructions and all packaging material for future use
1. With speaker lying on either side, open bottom of carton and fold all four carton
flaps out. It will be necessary to lift the bottom of the carton off the floor in order to
fold the bottom flap completely out and under the carton.
2. Stand the speaker upright on the plywood bottom pack.
3. Open top carton flaps and remove top plywood, styrofoam pack, and 4 long
cardboard corner protectors.
4. Lift the carton off the speaker.
5. Lift the speaker off the plywood and foam bottom pack assembly.
6. Remove the plastic bag.
Note: The stabilizer pins should be removed before repacking the speaker.
1. Place speaker in plastic bag and tape bag closed.
2. Place the speaker in the bottom pack.
3. Place the carton over the speaker with the finish and serial number information
located at the back of the speaker.
4. Carefully insert 4 long cardboard corner protectors into the carton. They should be
positioned between the foam bottom pack and the carton.
5. Position top styrofoam pack, then place plywood on top. Close and tape top carton
flaps.
6. Gently lay the speaker on its side while holding the bottom pack in place up in the
carton.
7. Stand carton upside down. Close and tape bottom carton flaps.
8. Return packed speaker to upright position before storing or shipping.
Unpacking Instructions for CS3.7
Repacking Instructions for CS3.7
1026 Nandino Blvd
Lexington, Kentucky 40511 USA
Telephone: 859-254-9427
Fax: 859-254-0075
Email: mail@thielaudio.com
www.thielaudio.com
PLEASE NOTE!
The stabilizer pins
are packed in the
styrofoam pack,
under the top
plywood piece.
8/07
