Page 2
3. USB connector of receiver....................3 1. Product brief descreption This is product user’s manual of SK-7361 wireless keyboard and receiver. It is a multi-channe ls radio (27 MHZ), supports 11 optional channels. Keyboard function includes standard keyboard function and WIN2000 hot key function.
Page 3
LiteON Technology *Keyboard: Operation Voltage: Voltage supplied to device: 3 VDC (AA battery *2) *Receiver: Operation Voltage: USB bus power +5Vdc 2 Hot key function of keyboard This product offer hot key function of WIN2000. 3. USB connector of receiver The USB interface meets the USB version 1.1specification.
Page 4
LiteON Technology Channel 11 channels (Maximum) RF channel: – 11 channels (programmable) 26.995, 27.020, 27.045, 27.070 27.095, 27.120, 27.145, 27.170 27.195, 27.225, 27.255 (MHZ) Antenna Type A single wire loop ,put in keyboard inside, along with side edge of enclosure.
