Page 1: Parts List
PART NO. 624870 NORCOLD 04/16/2008 PARTS LIST * WHITE WRAPPED MODELS NO LONGER PRODUCED N1095 SERIES PANEL DOOR MODELS N1095 N1095IM N1095IMV N1095V WRAPPED DOOR MODELS N1095BK M1095BKV N1095IMBK N1095SS N1095IMSS N1095WH *... - Page 2 UPPER DOOR (FREEZER) - MODEL SERIES N1095 - PANEL TYPE PART # DESCRIPTION 619558 PANEL RETAINER-UPPER DOOR/BLACK/WDL 623943 PANEL RETAINER-UPPER DOOR/PANEL/BLACK/SDL 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL 619671 HINGE BUSHING-DOOR/WARM GRAY/WDL/SDL 619627 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/WDL 623945 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/SDL...
- Page 3 LOWER DOOR (FRESH FOOD) - MODEL SERIES N1095 - PANEL TYPE PART # DESCRIPTION 619560 PANEL RETAINER-LOWER DOOR/8'/BLACK/WDL 623760 PANEL RETAINER-LOWER DOOR/8'/BLACK/SDL 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL 619671 HINGE BUSHING-DOOR/WARM GRAY (2 PER DOOR) 619631 DOOR LINER ASSY-LOWER/8'/PANEL/BLACK FRAME/WDL 623942...
- Page 4 UPPER DOOR (FREEZER) - MODEL SERIES N1095 - WRAP TYPE PART # DESCRIPTION 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL 619671 HINGE BUSHING-DOOR/WARM GRAY/WDL/SDL 625874 DOOR LINER ASSY-UPPER/WRAP/BLACK/WDL 627121 DOOR LINER ASSY-UPPER/WRAP/BLACK/SDL 623272 DOOR LINER ASSY-UPPER/WRAP/STAINLESS STEEL/WDL 630091 DOOR LINER ASSY-UPPER/WRAP/STAINLESS STEEL/SDL...
- Page 5 LOWER DOOR (FRESH FOOD) - MODEL SERIES N1095 - WRAP TYPE PART # DESCRIPTION 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL 619671 HINGE BUSHING-DOOR/WARM GRAY/WDL/SDL 625875 DOOR LINER ASSY-LOWER/8'/WRAP/BLACK/WDL/POWDER COAT 627129 DOOR LINER ASSY-LOWER/8'/WRAP/BLACK/SDL 623273 DOOR LINER ASSY-LOWER/8'/WRAP/STAINLESS STEEL/WDL 630093 DOOR LINER ASSY-LOWER/8'/WRAP/STAINLESS STEEL/SDL...
- Page 6 CABINET AREA (FRONT VIEW) - MODEL SERIES N1095 N1095 SERIES PARTS LIST - PAGE 6...
- Page 7 CABINET AREA (FRONT VIEW) - MODEL SERIES N1095 PART # DESCRIPTION 620915 KIT-INSTALLATION/BLACK (TRIM PIECES/SCREWS) 625184 BRACKET FOAM TAPE ASSY-TOP/MOUNTING 623550 HINGE-CABINET/TOP/BOTTOM/(PANEL/WDL)(WRAP/SDL) 626659 HINGE-CABINET/TOP/BOTTOM/PANEL/SDL 619335 HINGE-CABINET/3 POINT/TOP RH/BTM LH/BLACK/WDL 623771 HINGE-CABINET/3 POINT/TOP RH/BTM LH/PANEL/BLACK/SDL 624785 HINGE-CABINET/3 POINT/TOP RH/BTM LH/WRAP/BLACK/SDL 619336...
- Page 8 CABINET AREA (REAR VIEW/COOLING UNIT) - MODEL SERIES N1095 PART # DESCRIPTION 632316 NSC SYSTEM PACK-COOLING UNIT/N1095/ (BACKER HEATER) 2M0802 KIT-THERMAL SWITCH/BRACKET ASSY (SEE NOTE) 618111 BAFFLE DIFFUSER/WIRE ASSY-COOLING UNIT (NOT SHOWN) 622391 DRAIN HOSE ASSY 622546 DRIP CUP-REAR/PLASTIC 61712637...
- Page 9 CONTROLS (REAR VIEW) - MODEL SERIES N1095 PART # DESCRIPTION 618186 BASE-POWER BOARD (9045737 & BELOW) 628674 BASE-POWER BOARD (9045738 & ABOVE) 621269001 KIT-POWER BOARD (9045737 & BELOW) 628661 POWER BOARD (9045738 & ABOVE) 618185 COVER-POWER BOARD (9045737 & BELOW) 628677 COVER-POWER BOARD (9045738 &...
- Page 10 INTERIOR LIGHT AND THERMISTER ASSY - MODEL SERIES N1095 PART # DESCRIPTION 61629722 LAMP BRACKET ASSY 61628922 LAMP-GE #214-2/DC LIGHT BULB 621827 COVER-LAMP BRACKET 620875 CLIP-THERMISTER MOUNTING/ADHESIVE BACK 620871 LAMP THERMISTER WIRE ASSY N1095 SERIES PARTS LIST - PAGE 10...
- Page 11 SLEEVE-BALL/.25"/TUBE COMPRESSION RING/BRASS (NOT SHOWN) 620240 THERMOSTAT-IM HEATER ASSY (NOT SHOWN) 622835 INSERT-BRASS/.040"/OEM WATER LINE/IM (NOT SHOWN) 623181 SLEEVE-BALL/.25"/TUBE COMPRESSION RING/PLASTIC (NOT SHOWN) 623182 KIT-OEM WATER TUBE FITTINGS/IM (ICE MAKER MODELS) NS = NOT SHOWN N1095 SERIES PARTS LIST - PAGE 11 N1095IM MODELS...
- Page 12 FAN SYSTEM COMPONENTS - MODEL SERIES N1095 NOTE: LOWER FAN POSITION - MODELS WITH SERIAL # BELOW 9056492 P A R T # D E S C R IP T IO N 6 18 8 5 7 B R A C KE T - D C F A N...
