Installation and Operation Manual
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN
THE AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD INSERT. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
ESCAPE 1500-I
insert
(Model DB03137)
Safety tested according to
ULC S628, UL 1482 and
UL 737 by an accredited
laboratory.
US Environmental Protection
Agency phase II certified
wood insert compliant with
2020 cord wood standard.
EPA
< ≤
2.5
g/h
45997A

Advertisement

Table of Contents
loading

Related Manuals for Drolet DB03137

Summary of Contents for Drolet DB03137

  • Page 1 Installation and Operation Manual ESCAPE 1500-I insert (Model DB03137) Safety tested according to ULC S628, UL 1482 and UL 737 by an accredited laboratory. US Environmental Protection Agency phase II certified wood insert compliant with 2020 cord wood standard. < ≤...
  • Page 3 It is also highly recommended to register the warranty online at https://www.drolet.ca/en/warranty/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS PART A - OPERATION AND MAINTENANCE ................7 1. Safety Information ........................7 2. General Information ........................ 8 2.1 Performances ......................... 8 2.2 Specifications ......................... 9 2.3 Dimensions ........................10 2.4 Materials ........................12 2.5 Zone Heating .........................12 2.6 Emissions and Efficiency ....................13 3.
  • Page 5 Appendix 4: Optional Fire Screen Installation ................43 Appendix 5: Air Tubes and Baffle Installation ................44 Appendix 6: Removal Instructions .................... 46 Appendix 7: Exploded Diagram and Parts List ................ 47 DROLET Limited Lifetime Warranty ..................50 Dealer: Installer: Phone Number:...
  • Page 6 CERTIFICATION PLATE Page 6 Installation and Operation Manual - Escape 1500-I...

  • Page 7: Part A - Operation And Maintenance

    PART A - OPERATION AND MAINTENANCE 1. Safety Information • This insert has been tested for use with an open door in conjunction with a fire screen, sold separately. The door may be opened, or fire screen removed only during lighting procedures or reloading.

  • Page 8: General Information

    2. General Information Performances Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output. Models Escape 1500-I (DB03137) Combustion Technology Non-catalytic Fuel Type Dry Cordwood Recommended heating area (sq. ft.

  • Page 9: Specifications

    Specifications Maximum log length 18 in (457 mm) east-west Flue outlet diameter 6 in (150 mm) Recommended connector pipe diameter 6 in (150 mm) Type of chimney ULC S635, CAN/ULC-S640, UL 1777 Vermiculite Baffle material Approved for alcove installation Not applicable Approved for mobile home installation Type of door Simple, glass with cast iron frame...

  • Page 10: Dimensions

    Dimensions 2 7/8" 13 5/8" 74mm 348mm MIN. 27 1/4" 692mm 25 1/2" 648mm 12 3/4" 324mm 5 3/4" 145mm 6" Ø 150mm Figure 1: Top View Figure 2: Side View - Minimum Insert Projection 3 5/8" 12 7/8" 93mm 328mm MAX.
  • Page 11 8 3/4" 221mm 17 1/4" 438mm Figure 5: Door Opening 5/16" 3/16" 11 7/8" 19 5/8" 301mm 498mm 13 1/2" 343mm Figure 6: Front View - Combustion Chamber Figure 7: Side View - Combustion Chamber Installation and Operation Manual - Escape 1500-I Page 11...

  • Page 12: Materials

    Materials The SBI team is committed to protecting the environment, so they do everything they can to use only materials in their products that will have no lasting negative impact on the environment. The body of this insert, which is most of its weight, is carbon steel. Should it ever become necessary many years in the future, almost the entire insert can be recycled into new products, thus eliminating the need to mine new materials.

  • Page 13: Emissions And Efficiency

    Although the insert may be able to heat the main living areas of the house to an adequate temperature, it is strongly recommended to also have a conventional oil, gas or electric heating system to provide backup heating. The success of zone heating will depend on several factors, including the correct sizing and location of the insert, the size, layout and age of the home and the climate zone.

  • Page 14: Tree Species

    Tree Species The tree species the firewood is produced from is less important than its moisture content. The main difference in firewood from various tree species is the density of the wood. Hardwoods are denser than softwoods. Homeowners with access to both hardwood and softwood use both types for different purposes. Softer woods make good fuel for mild weather in spring and fall because they light quickly and produce less heat.

  • Page 15: Drying Time

    Drying Time Firewood that is not dry enough to burn is the cause of most complaints about wood inserts. Continually burning green or unseasoned wood produces more creosote and involves lack of heat and dirty glass door. Firewood with a moisture content between 15% and 20% will allow the insert to produce its highest possible efficiency.

  • Page 16: Operating The Insert

    4. Operating the Insert This wood heater has a manufacturer-set minimum low burn rate that must not be altered. It is against federal regulations to alter this setting or otherwise operate this wood heater in a manner inconsistent with operating instructions in this manual.

  • Page 17: Blower

    Blower A blower is already installed on this insert. It is located underneath the ash lip, in front of the insert. Its function is to increase airflow through the heat exchanger and improve hot air circulation in the room. When used regularly, the blower can provide a small increase in efficiency, up to 2%.

  • Page 18: Burning Wood Efficiently

    5. Burning Wood Efficiently First Use Two things happen when burning the first few fires; the paint cures and the internal components are conditioned. As the paint cures, some of the chemicals vaporize. The vapors are not poisonous, but they smell bad. Fresh paint fumes can also trigger false alarms in smoke detectors. When lighting the heater for the first few times, it may be wise to open doors and windows to ventilate the house.

  • Page 19: Combustion Cycles

    Use four or five sheets of paper tied together and put them on top and around the kindling. Open the air intake control completely, ignite the paper and close the door. The top down fire method has two advantages over the traditional method: first, the fire does not collapse on itself, and it is not necessary to add wood gradually since the combustion chamber is full before the fire is lit.

  • Page 20: Rekindling A Fire

    Rekindling a Fire When the temperature of the room is lower and all that remains is embers, it is time to reload. Remove excess ash from the front of the firebox and bring the ashes forward. Place a new load of wood on, and at the back of the embers.

  • Page 21: Air Intake Control

    Air Intake Control Once the firewood, firebox and chimney are hot, air intake can be reduced to achieve a steady burn. As the air intake is reduced, the burn rate decreases. This has the effect of distributing the thermal energy of the fuel over a longer period of time.
  • Page 22 5.7.3 High Output Fires When heating needs are high during cold weather, the fire should burn steadily and brightly. This is the time to use larger pieces of hardwood. Place the biggest pieces at the back of the firebox and place the rest of the pieces compactly. A densely built fire like this will produce the longest combustion this insert is capable of.

  • Page 23: Maintenance

    5.7.6 Carbon Monoxide When there is no more flame in the firebox and there are still some unburned logs, check outside if there is smoke coming out of the chimney. If this is the case, it means that the fire is out of air to burn properly.
  • Page 24 When brown streaks are coming from the edge of the glass, it is time to replace the gasket around the glass. Always replace the gasket with a genuine one. see «Appendix 7: Exploded Diagram and Parts List». Do not clean the glass when the insert is hot. Do not abuse the glass door by striking or slamming shut.

  • Page 25: Door

    Cut the gasket to the required length. Pinch the gasket onto the glass in a U shape, all around the glass. Door In order for the insert to burn at its best efficiency, the door must provide a perfect seal with the firebox.

  • Page 26: Exhaust System

    6.3.2 Gasket It is important to replace the gasket with another having the same diameter and density to maintain a good seal. Remove the door and place it face-down on something soft like a cushion of rags or a piece of carpet. Remove the old gasket from the door.
  • Page 27 Establish a routine for the fuel, wood burner and firing technique. Check daily for creosote build-up until experience shows how often you need to clean to be safe. Be aware that the hotter the fire, the less creosote is deposited and weekly cleaning may be necessary in mild weather even though monthly cleaning may be enough in the coldest months.

  • Page 28: Part B - Installation

    PART B - INSTALLATION 7. Masonry Fireplace Requirements The masonry fireplace must meet the minimum requirements found in the building code enforced locally, or the equivalent, for a safe installation. Contact the local building inspector for requirements in the area. An inspection of the fireplace should include the following: Fireplace and Chimney Condition The masonry fireplace and chimney should be inspected prior to installation, to confirm that they are free from cracks, loose mortar, creosote deposits, blockage, or other signs of deterioration.

  • Page 29: Safety Information And Standards

    8. Safety Information and Standards • The information given on the certification label affixed to the appliance always overrides the information published, in any other media (owner’s manual, catalogues, flyers, magazines and web sites). • Mixing of appliance components from different sources or modifying components may result in hazardous conditions.

  • Page 30: Clearances To Combustible Material

    9. Clearances to Combustible Material When the insert is installed so that its surfaces are at or beyond the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions. NO PART OF THE INSERT MAY BE LOCATED CLOSER TO THE COMBUSTIBLE THAN THE MINIMUM CLEARANCE FIGURES GIVEN.
  • Page 31 To determine the need to add floor protection (D) beyond the hearth extension (A), the following calculation must be done using the data in «Table 4 : Data for Floor Protection Calculation» this section: D = B - G, where G = A-C. HEARTH SLAB: HEARTH SLAB: NON-COMBUSTIBLE MATERIAL...
  • Page 32 9.2.3 R Value There are two ways to calculate the R-value of the floor protection. First, by adding the R-values of materials used, or by the conversion if the K factor and thickness of the floor protection are given. To calculate the total R value from R values of the materials used, simply add the R-values of materials. If the result is equal to or greater than the R-value requirements, the combination is acceptable.

  • Page 33: Minimum Masonry Opening And Clearances To Combustibles

    Minimum Masonry Opening and Clearances to Combustibles COMBUSTIBLE MANTEL SHELF COMBUSTIBLE TOP SURROUND FLOOR PROTECTION Figure 24: Masonry Opening and Clearances MINIMUM CLEARANCES MAXIMUM THICKNESS 16" (406 mm) 5" (127 mm) 9" (229 mm) 12" (305 mm) 27" (686 mm) 27"...

  • Page 34: The Venting System

    The Venting System 10.1 General The venting system, made of the chimney and the liner inside the chimney, acts as the engine that drives the wood heating system. Even the best insert will not function safely and efficiently as intended if it is not connected to a suitable chimney and liner system. The heat in the flue gases that pass from the insert into the chimney is not waste heat.

  • Page 35: Chimney Liner Installation

    10.4 Chimney Liner Installation The use of a chimney liner (rigid or flexible) is RAIN CAP recommended to ensure the best performance. ensure an optimal draft, it is also strongly recommend RIGID LINER adding a minimum of 12" rigid liner between the top of 12"...
  • Page 36 The dealer may offer a liner fastening system, sold separately. Follow the installation instructions provided with the liner fastening system. Figure 29: Liner fastening system 10.5.2 Liner Offset Adapter A liner offset adapter, sold separately, can also be installed. This should only be installed if no other option is possible and if the total height of the fireplace and chimney is at least 20 feet.

  • Page 37: Minimum Chimney Height

    10.6 Minimum Chimney Height The top of the chimney should be tall enough to be above the air turbulence caused when wind blows against the house and its roof. The chimney must extend at least 3 ft. (1 m) above the highest point of contact with the roof, and at least 2 ft.(60 cm) higher than any roof line or obstacle within a horizontal distance of 10 ft.

  • Page 38: Supply Of Combustion Air

    10.8 Supply of Combustion Air In Canada, wood inserts are not required to have a combustion air supply from outside. Research has shown that outside air supply do not compensate for the depressurization of the house and may not be sufficient to provide a supply of combustion air in windy weather. However, to reduce the risks against smoke spillage due to house depressurization, a carbon monoxide (CO) detector is required in the room where the insert is installed.

  • Page 39: Appendix 1: Blower And Ash Lip Installation

    APPENDIx 1: BLOWER AND ASH LIP INSTALLATION Install the ash lip (A) on the insert with three screws (B). Center the blower on the ash lip and push it against the firebox. Then push it until it clips. Installation and Operation Manual - Escape 1500-I Page 39...

  • Page 40: Appendix 2: Faceplate Installation

    APPENDIx 2: FACEPLATE INSTALLATION Remove the faceplate extension (K) secured between the firebox and the convection air jacket. Lay the panels on a flat and non abrasive surface. Align the top panel holes (L) with the left (N) and right (M) panels. Secure together using the four bolts (P) and nuts (O) provided. Page 40 Installation and Operation Manual - Escape 1500-I...
  • Page 41 Align the holes of the faceplate extension (X) with the holes in the faceplate panels and screw them using bolts (P) and nuts (O) provided. Center the insert into the fireplace opening. If necessary, adjust the height of the insert using the levelling bolts (T) on each side of the insert until the faceplate is properly seated on the floor of the hearth extension.

  • Page 42: Appendix 3: Optional Fresh Air Intake Kit Installation

    APPENDIx 3: OPTIONAL FRESH AIR INTAKE KIT INSTALLATION Note : The fresh air intake kit may be installed on the right or left end side of the unit. The unused side must be covered by the plate provided in the user manual kit. Install the fresh air intake adapter (E) with four screws (F) then secure the flexible pipe (H) (not included) to the adapter using one of the pipe clamps (G).

  • Page 43: Appendix 4: Optional Fire Screen Installation

    APPENDIx 4: OPTIONAL FIRE SCREEN INSTALLATION Open the door. Hold the fire screen by the two handles and bring it close to the door opening. Lean the upper part of the fire screen against the top door opening making sure to insert the top fire screen brackets behind the primary air deflector.

  • Page 44: Appendix 5: Air Tubes And Baffle Installation

    APPENDIx 5: AIR TUBES AND BAFFLE INSTALLATION Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel. Align the notch in the left end of the tube with the key of the left air channel hole.
  • Page 45 Note that secondary air tubes (A) can be replaced without removing the baffle board (B) and that all tubes are identical. Installation and Operation Manual - Escape 1500-I Page 45...

  • Page 46: Appendix 6: Removal Instructions

    APPENDIx 6: REMOVAL INSTRUCTIONS For inspecting purposes, the insert may need to be removed. To remove the insert, follow these instructions: Unscrew the faceplate fastener (B) holding the faceplate (C) on the insert. Remove faceplate (C) by pulling on it. Remove the blower assembly (D).

  • Page 47: Appendix 7: Exploded Diagram And Parts List

    APPENDIx 7: ExPLODED DIAGRAM AND PARTS LIST DETAIL B DETAIL A Installation and Operation Manual - Escape 1500-I Page 47...
  • Page 48 IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for this unit, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrades or availability. Contact an authorized dealer to obtain any of these parts.
  • Page 49 Item Description 29015 4'' X 9'' X 1 1/4'' REFRACTORY BRICK 29010 4 1/2" X 9" X 1 1/4" REFRACTORY BRICK PL36031 3 5/8" X 9'' X 1 1/4'' REFRACTORY BRICK PL70516 SECONDARY AIR TUBE 21586 VERMICULITE BAFFLE SE70696 ESCAPE 1500 INSERT FACEPLATE PL70696 FACEPLATE 29 X 44 TOP PANEL PL70695...

  • Page 50: Drolet Limited Lifetime Warranty

    Shall your unit or a component be defective, contact immediately your DROLET dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: •...
  • Page 52 Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 418-908-8002 of information contained in any document obtained from https://www.drolet.ca/en/ unauthorized sources. tech@sbi-international.com...
