- Page 1 TB15FR Compact Excavator Serial No. 11810004~ Book No. AC5E001 OPERA TOR’S MANUAL WARNING Read and understand these instructions. Failure to do so can cause injury or death.
- Page 2 Always store this manual near at hand preferably on the machine itself. If it should be lost or damaged, immediately order a new one from your Takeuchi dealer. When transferring ownership of this machine, be sure to provide this manual to the next owner.
- Page 3 It is your responsibility to observe all pertinent laws and regulations and to follow the manufacturer’s instructions on machine operation, inspection and maintenance. Virtually all accidents occur as the result of a failure to observe basic safety rules and precautions. An accident can often be avoided by recognizing potentially hazardous situations beforehand.
- Page 4 If you have any questions about the machine, please contact a Takeuchi sales or service outlet. Serial numbers Manual storage compartment Check the serial numbers of the machine and...
- Page 5 MACHINE DESCRIPTlON Front, rear, Ieft and right FRONT This manual refers the front, rear, left and right of the machine as seen when sitting in the operator’s seat with the dozer blade visible to the front. Dozer blade Designated operations Use this machine primarily for the following LEFT RIGHT...
- Page 6 CONTENTS Introduction ........2 Machine Description ...... 3 Safety ..........7 Controls .........35 Operation ........49 Transport ........77 Maintenance ........81 Troubleshooting ......123 Specifications ......133 Options ........141 Index ..........155...
- Page 7 SAFETY General precautions ........8 Preparing precautions ........ 12 Starting precautions ........14 Operating precautions ........ 16 Stopping precautions ......... 23 Transporting precautions ......24 Maintenance precautions ......25 Safety signs (Decals) ........32...
- Page 8 SAFETY General Precautions ¡Use hearing protection when operating the Observe all safety rules machine. Loud prolonged noise can cause ¡Operation, inspection and maintenance of hearing impairments, even the total loss this machine must be performed only by a of hearing. trained and qualified person.
- Page 9 SAFETY General Precautions Be sure to lock the safety lock lever Use a signal person and flagman before leaving the operator’s seat Know and use the hand signals required for ¡Before leaving the operator’s seat, set the particular jobs and make sure who has the safety lock lever securely to the lock responsibility for signaling.
- Page 10 SAFETY General Precautions Avoid fire and explosion hazards Exhaust fumes from the engine can kill ¡Do not operate the engine in an enclosed Keep flames away from fuel, hydraulic fluid, oil, grease and antifreeze. Fuel is particularly area without adequate ventilation. ¡If natural ventilation is poor, install flammable and dangerous.
- Page 11 Takeuchi or a Takeuchi dealer. Doing so may compromise safety or adversely affect the machine’s operation or service life. ¡Takeuchi will not be held responsible for any injuries, accidents or damage to its products caused by the use of a non- approved attachment.
- Page 12 SAFETY Preparing Precautions Know the working area Alway keep the machine clean Before starting operation, know the working area to ensure safety. ¡ Check the topography and ground condition of the working area, or the structure of the building when working indoors, and take the necessary safety measures in dangerous spots.
- Page 13 SAFETY Preparing Precautions Perform inspection and maintenance daily Failure to notice or repair machine irregularities or damage can lead to accidents. ¡Before operating, perform the prescribed inspections and make repairs immediately should any irregularities be found. ¡If a failure that causes loss of control such as steering, service brakes or engine occurs, stop the machine motion as quickly as possible, follow the shutdown...
- Page 14 SAFETY Starting Precautions Maintain three point contact when ¡Check for any “DO NOT OPERATE” tags or similar warning notices on the cab door, mounting and dismounting controls or starter switch. ¡Do not jump on or off the machine. Never ¡Sound horn to alert everyone around the attempt to mount or dismount a moving machine.
- Page 15 SAFETY Starting Precautions Starting with jumper cables In cold weather ¡Be careful of slippery conditions on Use jumper cables only in the recommended manner. Improper use of jumper cables can freezing ground, steps and hand holds. ¡In severe cold weather, do not touch any result in battery explosion or unexpected machine motion.
- Page 16 SAFETY Operating Precautions Check for safety in the Ensure good visibility surrounding area before starting ¡When working in dark places, turn on the machine’s working lights and headlights and/or provide extra stationary lighting if necessary. ¡When visibility is poor due to severe weather (fog, snow or rain), stop operating the machine and wait until conditions improves.
- Page 17 SAFETY Operating Precautions Travel safety (12 to 16 in.) ¡Travel with the dozer blade up, the hoe attachment folded as shown on the diagram, and the bucket raised 30 to 40 cm (12 to 16 in.) from the ground. ¡Do not slew (swing) while traveling. If you must operate the hoe attachment while traveling, operate at speeds slow enough so you have complete control at all times.
