T
ABLE OF
ABOUT THIS GUIDE ........................................................................... 4
GETTING STARTED............................................................................ 5
............................................................................ 6
........................................................................... 7
V
.................................................................................... 8
LEDs ............................................................................................... 8
Buttons ..........................................................................................10
Fan and Ventilator.........................................................................10
Using the Base Holder ..................................................................10
INSTALLING AND CONNECTING ....................................................11
................................................................11
HDD.........................................................................12
Connecting to the Network ...........................................................14
Connecting to a Client Workstation ..............................................14
Expanding the USB Devices.........................................................14
.............................................................15
Configuring a Fixed IP Address ....................................................15
Accessing the Storage server.......................................................18
....................................................................................19
Using Easy Search .......................................................................19
WEB CONFIGURATION ....................................................................23
............................................................23
....................................................................25
LAN .................................................................................25
Global..............................................................................26
Time Zone.......................................................................27
.............................................................28
- 2 -
C
ONTENTS
.....................................................14
Advertisement
Table of Contents
Related Manuals for TRENDnet TS-I300
Summary of Contents for TRENDnet TS-I300
-
Page 1: Table Of Contents
ABLE OF ONTENTS ABOUT THIS GUIDE ... 4 GETTING STARTED... 5 ... 6 ENERAL EATURES ... 7 ACKAGE ONTENTS ... 8 RODUCT LEDs ... 8 Buttons ...10 Fan and Ventilator...10 Using the Base Holder ...10 INSTALLING AND CONNECTING ...11 ...11 ETWORKING PPLICATION HDD...12... -
Page 2: About This Guide
Advanced Account...28 Advanced Session ...30 Advanced Wireless(For Wireless Model) ...34 Advanced Performance ...35 Advanced FTP Server ...36 Advanced E-mail Alerts ...38 Advanced Disk Utility ...39 Advanced Time Zone...40 Advanced UPnP AV...41 Advanced Status...42 ...43 ONFIGURATION AINTENANCE Maintenance Firmware Upload...43 Maintenance Configuration...44 ...45 ONFIGURATION... -
Page 3: Getting Started
ETTING Congratulations on purchasing your Network Storage Enclosure (with Wireless AP/Client), the easiest and fastest way to share data, file, and resource in your SOHO or home network. You can choose the wireless model or wired model to deploy the network according to your need. -
Page 4: Package Contents
Package Contents Unpack the package and check all the items carefully, and be certain that you have: ♦ One TS-I300 or TS-I300W ♦ One External Antenna (for wireless model). ♦ One AC adapter and power cord. ♦ One Base Holder. -
Page 5: Leds
LEDs There are six LEDs on the front panel: LEDs on the Front Panel • Power – A steady Green light indicates the storage server is powered on. • LAN – A steady Green light indicates the storage server has a good connection to your network. -
Page 6: Installing And Connecting
NSTALLING AND ONNECTING Networking Application The following diagram explains the application of your storage server. Storage Server in Your Network Environment - 11 - Installing the HDD 1. Disconnect the power cord. Remove two screws on the rear panel to detach the cover. 2. -
Page 7: Installing The Storage Server
3. Place the HDD onto the metal bracket, and secure it to the storage server with four mounting screws. 4. Replace the cover and secure with two screws. NOTE: 1. Make sure to adjust the HDD’s jumper to “Master” position. 2. -
Page 8: Using The Storage Server
Using the Storage server Configuring a Fixed IP Address When you connect your computer to the storage server directly to configure the storage server, you need to check the computer’s IP address, and set up the IP address within the storage server’s IP address range. -
Page 9: Accessing The Storage Server
5. To configure a fixed IP address, check the “Use the following IP address” option. Then, enter an IP address into the empty field. Suggested IP Address is 192.168.1.x (x is 3~254), and suggested Subnet Mask is 255.255.255.0. 6. Click OK to complete the configuration. - 17 - Accessing the Storage server Since you have made the connection between your computer and the... -
Page 10: Easy Search
Enter the User name and password, and select one option to proceed. To enter the configuration utility, type admin in Password box, and then click the Config button. Clicking the admin Download Schedule button allows you to enter the Download page. NOTE: Only the administrator can access the Configuration Utility by clicking the Config button. - Page 11 Search Device – When launching the utility, it will search the connected storage server(s) automatically, and display the 2. Click the Easy Search Utility button to launch the utility. The results in the list. To refresh the list, click the Search device control panel will appear as below.
-
Page 12: Web Configuration
ONFIGURATION You can access and manage the storage server through a web browser. This chapter provides you with instructions of the Web Configuration Utility, and explains how to set up your storage server with the web browser. Web Configuration Utility You must have do P.15-Using the Storage Server step first, then open IE and type the default storage IP:192.168.1.2.Login the web configuration utility as described in the previous section. -
Page 13: Configuration - Basic
Configuration - Basic The Basic menu contains three steps that will guide you through the basic configuration for the storage server. Click Basic in the top menu bar to start the step-by-step configuration. Basic Menu – LAN Basic The first step is to configure the LAN settings. These options in this step display the current IP address and DHCP service of the storage server, and can be modified manually. -
Page 14: Basic Time Zone
Basic Time Zone This screen displays the current time setting of the storage server. For system management purpose, a correct time setting is critical to have accurate time stamps on the system logs. Basic Menu – Time Zone The Method pull-down menu allows you to set up the correct time by getting time from the computer or time server (need an Internet connection). -
Page 15: Advanced Session
Remove user: You can delete an existing user’s account in this option. Check the box associated to the user you want to delete and click Apply. Modify user: You can change the password of an existing user’s account. Select the radio button associated to the user you want to modify and click Apply. - Page 16 Modify Session: You can modify the tasks by selecting the corresponding radio button and click Apply (see the illustration on page 32). Remove Session: You can remove the tasks by selecting the corresponding check box and click Apply (see the illustration on page 32).
-
Page 17: Advanced Wireless(For Wireless Model)
Security settings - 33 - Advanced Wireless (For Wireless Model) The Wireless submenu appears only in wireless model. If you use a wireless-enabled storage server, you can configure the respective settings in this submenu. Advanced Menu –Wireless Wireless Setting: In this field, set up the respective settings according to your wireless network environment, the options includes: Access Point or Station mode, Enable/Disable wireless function, SSID, Channel, Enable/Disable 802.11g Only Mode,... -
Page 18: Advanced Performance
Advanced Performance The Performance submenu contains the options that allow you to adjust the wireless performance by configure the related settings for the Access Point, including TX Rate, Transmit Power, Beacon Interval, RTS Threshold, Fragmentation, DTIM Interval, Preamble Type, and CTS Mode. Advanced Menu –... -
Page 19: Advanced E-Mail Alerts
Setting: This option contains the relative FTP server settings. - User: S elect a user from the drop-down menu or check All Accounts. - Path: Click Open and select the destination folder from the internal/USB drive for FTP server. - Root: Check the Root box to select the root level of all the drives at once. -
Page 20: Advanced Disk Utility
Advanced Disk Utility The Disk utility submenu contains the options that allow you to format and scan the HDD. Advanced Menu – Disk utility To format the HDD, select the desired disk first, and select one file system (EXT3/EXT2/FAT/FAT32 for external USB drive, EXT2 for embedded IDE HDD) from the pull-down list. -
Page 21: Advanced Upnp Av
Advanced UPnP AV The UPnP AV submenu allows you to assign the destination folder on the storage server to store/play the captured images from the external video player. Advanced Menu – UPnP AV Click the Open button to configure the destination folder on your storage server. -
Page 22: Configuration - Maintenance
Configuration - Maintenance The Maintenance menu contains two submenus: Firmware upload and Configuration. Maintenance Firmware Upload The Firmware upload submenu allows you to update the firmware of your storage server once you obtained a latest version of firmware. Click Browse to point to the firmware file, and then click Upload. Maintenance Menu –... -
Page 23: Configuration - Logout
Restore: You can restore the saved configuration of the storage server. Log: You can view the System Log or E-mail Log. Configuration - Logout Click Logout to exit the web configuration utility, and it will return to the login screen of the utility. You can re-login using the admin User name. -
Page 24: Download Scheduling
2. The Main menu of Download page will display as below. Home – main screen of the download page, providing the brief instructions of the buttons on menu bar. Download Scheduling – clicks to set up your download schedule. Schedule List – contains the information of scheduled download tasks. -
Page 25: Schedule List
Save to: Click open to bring up the following window that allows you to assign the destination folder to save the downloaded files. When completed, click OK. When: You have to set up the start-up time to download files from the pull-down menu of the Date and Time options. Option: When the downloaded files have the same filename as the files in the destination folder, checking the Overwrite option will overwrite the old file in the folder. -
Page 26: Logout
Logout Click Logout to exit the download page, and it will return to the login screen of the utility. NOTE: If you are denied to enter the Configuration Utility or Download page, the following warning message will appear on the screen. -
Page 27: Leds
LEDs Power (Green) LAN (Green) HDD (Green) HDD Full (Orange) USB (Green/Orange) WLAN (Green) Management Web-based administrative program Operating System Support Windows 98/ME, Windows NT, Windows 2000/XP Mac OS X Linux SMB Environmental and Physical Power Supply: 12VDC, 3.0 Amp Operating Temperature: 5 ~ 40°C Storage Temperature: -20 ~ 50°C Humidity: 5 ~ 90%, non-condensing:5 ~ 95%Operating... -
Page 28: Limited Warranty
TS-I300 / TS-I300W 2 Years If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or deliver to customer an equivalent product to replace the defective item. All products that are replaced will become the property of TRENDnet. - Page 29 - 57 -...
