- Page 1 Quick Installation Guide TEW-432BRP H/W: v.D1.0R...
-
Page 2: Table Of Contents
Table of Contents English ... 1. Before You Start 2. Install Router ... 3. Replacing an existing router ... 4. Adding the router behind an existing router ... Troubleshooting ... Version 02.13.2009... -
Page 3: English
Cable or DSL modem to your computer. Also verify that you are connected to the Internet by browsing to a website, such as http://www.trendnet.com. Package Contents TEW-432BRP Easy Go CD-ROM Quick Installation Guide RJ-45 Cat.5 Cable AC Power Adapter (7.5V, 1A) Internet... -
Page 4: Install Router
8. Unplug the existing Ethernet cable from your cable or DSL modem and plug it into yellow port number 1 on the TEW-432BRP. Then click Next. Warning!!: DO NOT plug the cable or DSL modem power supply into the TEW-432BRP. English... - Page 5 9. Connect the included power supply from an available outlet to the TEW-432BRP. 10. Please wait while the TEW- 432BRP is being configured. 11. Connect one end of the included grey Ethernet cable to the grey port labeled WAN on the back of your new router.
- Page 6 Your installation is now complete. For detailed information regarding the TEW-432BRP configuration and advanced settings, please refer to the User's Guide included on the Easy Go Installation CD-ROM or TRENDnet's website at www.trendnet.com...
-
Page 7: Replacing An Existing Router
5. Disconnect all remaining Ethernet cables from the back of your old router and plug them into the yellow ports on the TEW-432BRP. Warning! DO NOT plug the cable or DSL modem power supply into the TEW-432BRP. 6. Connect the included power supply from an available outlet to the TEW-432BRP. - Page 8 9. Please wait while the TRENDnet Router Setup configures your router. 10. Select the type of Internet Service, and then click Next. Follow the wizard instructions for configuring the Internet. Please verify your settings with your Internet Service Provider. 11. Please wait while the TRENDnet Router Setup configures your router.
-
Page 9: Adding The Router Behind An Existing Router
1 on your new TRENDnet router. Then click Next. Warning! DO NOT plug the cable or DSL modem power supply into the TEW-432BRP. 3. Connect the included power supply from an available outlet to the TEW-432BRP. 4. Connect one end of the... - Page 10 URL (e.g. www.trendnet.com) to see if you are online. Register Your Product To ensure the highest level of customer service and support, please take a moment to register your product Online at: www.trendnet.com/register Thank you for choosing TRENDnet English...
-
Page 11: Troubleshooting
How can I get into the TEW-432BRP web configuration page? After you install the TEW-432BRP Wireless Router, you can access the web configuration page by opening your web browser and entering http://192.168.10.1 into the web browser's address bar, where http://192.168.10.1 is the default IP address of the TEW-432BRP Wireless Router. The default user name and password is admin. - Page 12 All the settings are correct, but I can not make a wireless connection to the Router. What should I do? First, double check that the WLAN light on the Router is lit. Second, power cycle the TEW-432BRP. Unplug the power to the TEW-432BRP. Wait 15 seconds, then plug the power back in to the TEW-432BRP.
- Page 13 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 14 Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register 20675 Manhattan Place Torrance, CA 90501 Copyright ©2009. All Rights Reserved. TRENDnet.
