TRENDnet TEG-S80TXE Quick Installation Manual
Trendnet teg-s80txe: install guide
Hide thumbs
Also See for TEG-S80TXE:
- User manual (25 pages) ,
- Specifications & instructions (2 pages) ,
- Specifications (2 pages)
Related Manuals for TRENDnet TEG-S80TXE
Summary of Contents for TRENDnet TEG-S80TXE
- Page 1 Quick Installation Guide TEG-S50TXE TEG-S80TXE...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English ... 1. Before You Start 2. Hardware Installation ... Technical Specifications ... Troubleshooting ... Version 04.19.2006... -
Page 3: English
An environment that is fairly cool and dry Leave at least 10 cm of space at the front and rear of the Switch for ventilation Sturdy, level surface that can support the weight of the Switch Application 5-Port /8-Port 10/100/1000Mbps... -
Page 4: Hardware Installation
2. Hardware Installation 1. Connect the AC Power Adapter to the TEG-S50TXE/TEG-S80TXE and then to a power outlet. 2. Connect a CAT. 5e or CAT. 6 RJ-45 network cable from the computer to an available Ethernet port on the TEG-S50TXE/TEG-S80TXE Your installation is now complete. -
Page 5: Technical Specifications
Gigabit Ethernet: 2000Mbps (Full-Duplex) Protocol CSMA/CD Topology Star 5 10/100/1000Mbps Auto-MDIX RJ-45 Ports (TEG-S50TXE) Interface 8 10/100/1000Mbps Auto-MDIX RJ-45 Ports (TEG-S80TXE) 112Kbyte per device(TEG-S50TXE) Data RAM Buffer 144Kbyte per devicee(TEG-S80TXE) Filtering Table 8K entries per device Power 5 watts max. (TEG-S50TXE) Consumption 7.5 watts max. -
Page 6: Troubleshooting
Fourth, verify that you have file and printer sharing enabled. Please contact Microsoft support for more information. After I connect my PCs to the Switch, I can only get onto the Internet from one computer. The Switch was not designed to share Internet between multiple computers. - Page 7 TEG-S50TXE/TEG-S80TXE - 5-Year Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
- Page 8 PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR USE OF TRENDNET’S PRODUCTS. TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY...
- Page 9 English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com 3135 Kashiwa Street Torrance, CA 90505 Copyright ©2006. All Rights Reserved. TRENDnet.
