TRENDnet TEG-S224M Specifications

TEG-S224M
22-port 10/100/1000Mbps Management Stackable Fast Ethernet Master Switch
The TEG-S224M is a high-capacity management stackable Fast
Ethernet master switch that provides the scalability and flexibility
to deploy a cost-effective network environment. The TEG-
S224M has three slots. Slot 1 is a 2-port 10/100Base-TX module
(switched), which it can be replaced with either a 2-port
100Base-FX (MT-RJ) module (optional) or a 1-port 100Base-FX
(SC) module (optional). Slot 2 is dedicated for a 3-port stacking
module (optional extension port). Slot 3 provides an optional 1 or
2-port 1000Base-SX (SC) Gigabit Ethernet module. The TEG-
S224M stacks with up to three TEG-S224S. Using the optional
switched modules, they support a maximum configuration of 94
10/100Mbps Ethernet/Fast Ethernet ports and two Gigabit
Ethernet ports.
FEATURES
Complies with IEEE 802.3, IEEE 802.3µ, IEEE 802.1p/Q, IEEE 802.3x standards
22 N-way auto-negotiation UTP/STP ports
Port-based VLAN
Half- and full-duplex modes
Store-and-forward switching method
Data filtering eliminates bad packets and runts
Back-plane bandwidth up to 21.32Gbps
Supports IEEE 802.1d Spanning Tree Protocol
12K MAC address table per device
IEEE 802.1q VLAN tagging and extended Port/MAC based VLAN
Integrated flow control
Port aggregation support
IGMP snooping - Multimedia Applications support
Broadcast Storm Filtering monitors the broadcast traffic
Console or Telnet configuration
Flash memory for software upgrade
Web-based network management to monitor and configure the device
Front panel port status LEDs
EIA-19 rack mountable
5 Year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Performance:
The full-duplex Gigabit switch brings
high bandwidth with 2000Mbps speed.
Expandability:
Provides up to 94-port 10/100Base-TX
ports and two Gigabit ports.
Reliability:
Supports IEEE 802.1p Traffic
Prioritization for time-sensitive and
mission-critical traffic.
Flexibility:
With different optional modules, the
switch can be easily connected to
other networks.
Manageability:
Provides the benefit of extensive and
simple management through SNMP,
HTTP, and four RMON groups.
TEG-S224M (11-17-2002)
