- Page 1 Quick Installation Guide TV-IP512WN 1.31...
- Page 2 Table of Contents English 1. Before You Start 2. Hardware Installation and Configuration Troubleshooting Version 02.08 .2010...
-
Page 3: System Requirements
VGA Resolution: 800 x 600 or above Web Brower: Internet Explorer (6.0 or higher) Wireless router or access point An available DHCP Server –routers usually have a built-in DHCP server. Package Contents TV-IP512WN Utility CD-ROM Multi-Language Quick Installation Guide 2 x 2dBi Detachable Antenna RJ-45 Cable Mounting Kit AC Power Adapter (12V, 1.5A) - Page 4 2. Hardware Installation and Configuration Note: 1. It is recommended that you configure the IP Camera from a wired computer. 2. If you would like to use IPViewPro 2.0 software, please install the software by clicking the Install IPView Pro 2.0 in the Autorun window and refer to the User's Guide on the CD for more information.
- Page 5 5. Click Next. 6. Double click on the SetupWizard icon on your desktop. 7. Attach the 2 antennas to the IP camera. 8. Connect a RJ-45 network cable from a Switch/Router to the Ethernet port on the IP Camera. 9. Connect the AC Power Adapter to the IP Camera and then to a power outlet.
- Page 6 11. Select the IP camera and click Next. 12. Enter your ID and password. Then click Next. By default: ID: admin Password: admin 13. If you would like to change the administrator password, click Change Password, enter a new password, retype the new password and then click Next.
- Page 7 20. Disconnect the RJ-45 cable and unplug the power. Then plug the power back in. Then verify the Power and Link LEDs are on. Note: The TV-IP512WN will not work wirelessly until you disconnect the Ethernet cable from the back of the camera.
- Page 8 21. Click on the following URL or click Link to open up the browser configuration. 22. Right click on the yellow bar and select Install ActiveX Control. 23. Click Install. 24. Right click on the yellow bar and select Install ActiveX Control.
- Page 9 27. Use the command icons to control the camera. Your Configuration is complete For detailed information regarding the TV-IP512WN configuration and advanced settings, please refer to the Troubleshooting section, User's Guide on the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com.
- Page 10 Follow the instructions in section 2: Hardware Installation and Configuration to configure the camera with the SSID and encryption key. 7. After I successfully configured the TV-IP512WN to match my wireless network settings, I can not connect to the camera.
- Page 14 Copyright ©2010. All Rights Reserved. TRENDnet.
