Option Menu; Status; All Reset; Closed Caption - Sharp TLM5200 Operation Manual

Selectable
Description
items
IP Address Factory default setting:
192.168.150.002
Enter an IP address appropriate for
the network.
Subnet Factory default setting:
Mask 255.255.255.000
Set the subnet mask to the same as
that of the computer and equipment
on the network.
Gateway Factory default setting:
000.000.000.000
* When not in use, set to
"000.000.000.000".
Note
• Confi rm the existing network's segment (IP address
group) to avoid setting an IP address that duplicates the
IP addresses of other network equipment or computers.
If "192.168.150.002" is not used in a network with an IP
address of "192.168.150.XXX", you don't have to change
the monitor IP address.
• For details about each setting, consult your network
administrator.
Confi rming the monitor information

(Status)

You can confi rm the following information.
• DHCP Client
• IP Address
• Subnet Mask
• Gateway
• MAC Address
• Monitor Name
• Serial Number
Note
• For information on how to change the monitor name, see
"SETUP MANUAL" contained in the supplied CD-ROM.
Returning to the default settings

(All Reset)

This function allows you to initialize the settings you
have made in the monitor.
Press ▲/▼ to select "All Reset" and press
1
ENTER.
Press ▲/▼ to select "Yes" and press ENTER.
2
Menu operations

Option menu

Option

Closed Caption

Audio Output
Video System
Signal Type
Color Space
Dynamic Range
Language
HDMI Setup
Resize
Timer
Picture Flip
Multi Screen
Power On Delay
LED
Background
Selecting Closed Caption
(Closed Caption)
This monitor is equipped with an internal Closed
Caption decoder. It allows you to view conversations,
narration and sound effects as subtitles on your
monitor. Closed Captions are available on some TV
programs and on some VHS home video tapes at
the discretion of the program provider.
Note
• 4 kinds of closed caption service (CC1, CC2, Text1, Text2)
are potentially available, but a broadcast may contain
none or only some of these services at the discretion of the
program provider.
• While displaying on-screen displays, Closed Caption
information disappears.
39
