USER MANUAL FOR YOUR
HUZ107.1 107 litre
Built-under freezer
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference, for
you or any person not familiar with the operation of the appliance.
DD 26/08/14

Advertisement

Table of Contents
loading

Related Manuals for Baumatic HUZ107.1

Summary of Contents for Baumatic HUZ107.1

  • Page 1 USER MANUAL FOR YOUR HUZ107.1 107 litre Built-under freezer NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.

  • Page 2: Table Of Contents

    Contents Environmental note Important safety information 4–5 Specifications of your freezer Dimensions Description of the appliance Using your freezer Before switching on During first use Turning on the appliance and setting the thermostat Arranging and storing food in the fridge section 9-10 Making ice-cubes Cleaning and maintenance...

  • Page 3: Environmental Note

    Environmental note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance.

  • Page 4: Important Safety Information

    Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please...
  • Page 5 Child safety o Packaging material should be kept away from children. o Children should not be allowed to touch the controls or play with the appliance. General safety o Do not pull on the power supply cable to remove the plug from your mains supply socket.

  • Page 6: Specifications Of Your Freezer

    Specifications of your freezer o Total gross capacity: 107 litres o Total net capacity: 95 litres o Manual defrost o Freezing capacity: 9 kg / 24 hours o Adjustable thermostat o 3 Freezer drawers o Reversible door o Door-on-door fittings Dimensions of appliance Height: 818 - 889 mm...

  • Page 7: Description Of The Appliance

    Description of the appliance 1) Thermostat dial 2) Freezer drawers Using your freezer Before switching on o Make sure that it has been installed by a suitably qualified person, as per the information contained in the installation instructions. o After delivery, wait for eight hours before connecting the appliance to your mains supply.

  • Page 8: During First Use

    During first use o When you first switch on the appliance, the compressor will run continuously for approximately 24 hours or until the freezer reaches a cool enough temperature. o During this period of time, you should try not to open the door frequently or place a large amount of food within the appliance.

  • Page 9: Arranging And Storing Food In The Fridge Section

    o On the maximum settings (position <5>), your fridge will work harder to maintain a lower temperature and will increase the energy usage. There is no need to run your appliance on this setting for prolonged periods and you should return the thermostat knob to between <3>...

  • Page 10: Making Ice-Cubes

    o The storage time and the recommended temperature for storing frozen foods are indicated on the packaging. For storing and using, follow the manufacturer’s instructions. If no information is provided the food should not be stored for longer than 3 months. o Place the frozen food in the freezer compartment as soon as possible after buying it.

  • Page 11: Cleaning And Maintenance

    Cleaning and maintenance WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO CLEAN IT. o Do not clean the appliance by pouring water onto it or spraying water over it. o The freezer should be cleaned periodically, using a solution of bicarbonate of soda and lukewarm water.
  • Page 12 o During defrosting, frozen foods should be wrapped in several layers of paper and kept in a cool place. The inevitable rise in temperature will shorten their storage life. Remember to use these foods within a relatively short period of time. o Set the thermostat dial to position <0>...

  • Page 13: Installation

    Installation IMPORTANT: Before installation usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found on the front left edge of the inside of the freezer.

  • Page 14: Positioning

    Positioning o It is advisable that your appliance is only installed in a location where the ambient temperature of the room, corresponds with the climate classification that is stated on the rating plate of your appliance. Your appliance may not function correctly if the ambient temperature falls outside of the following ranges.

  • Page 15: Aperture And Appliance Dimensions

    Aperture and appliance dimensions o The diagram above shows the aperture size that you will need to be able to install your appliance. Supplied installation components o The diagrams below show the contents of the supplied installation kit and the tools you will require to carry out the installation process.

  • Page 16: Installing Your Freezer

    Tools required 7) Water gauge 8) Wrench 9) Setsquare 10) Screwdriver Installing your freezer If you need the appliance door to open from the other side, then please reverse the door before commencing the installation process. (See “Reversing the door” section). o Remove the screw (5) at the top of the appliance and place the top bracket (6) in its place.
  • Page 17 o Fix the bracket with the screw (5). o Take out the gasket (11) located on the side panel and remove the protective tape. o Stick the gasket on the reverse side of the door hinges of the appliance. o You should use a water gauge (7) to ensure the appliance is level.
  • Page 18 o Slide the appliance into the kitchen unit and align the hinge surface with the front surface of the kitchen unit using a setsquare (9). o Screw the hinges and metal bracket to the kitchen unit using screws (1). o Unscrew and remove the nuts and washers from the appliance door.
  • Page 19 o Dimension B: Measure from the underside surface of the kitchen unit to the bottom of the door hang. o Dimension C: Measure from the underside surface of the kitchen unit to the top of the next unit door. o Subtract measurement C from measurement B. Place the door hang (2) using this dimension for the vertical position and place it in the centre for the horizontal position.
  • Page 20 o Close the door and check the alignment with the other cabinet doors. Make the adjustment of the unit door by screwing or unscrewing the adjustment bolts using a screwdriver (10) for vertical adjustment and by the help of the slots on the door hang for other directions.

  • Page 21: Ventilation Requirements

    o Slide the hang cover (4) onto the door hang. o Position the plinth providing a minimum 25 mm gap between the cabinet door, and fix it. NOTE: There are ventilation slots in the front of this appliance. If the height of the plinth covers any of the ventilation slots, then a cut-out must be made in the plinth to ensure that all of the ventilation slots are exposed.

  • Page 22: Reversing The Door Of Your Appliance

    Reversing the door of your appliance Caution! After unscrewing any of the fixing hinges, hold the door to prevent it from falling and causing damage. Any parts that you remove from the appliance whilst reversing the door, should be retained for later use. o Unscrew the screws on the front surface of the appliance door.

  • Page 23: Troubleshooting

    Troubleshooting IMPORTANT: If your freezer appears not to be operating properly, before contacting the Customer Care Department, please refer to the checklist below. My freezer does not appear to be working/there is no power to my appliance. o Check that the plug is fully inserted into the power socket. o Check that there is power to your mains supply (e.g.
  • Page 24 IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Customer Care Department. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.

  • Page 25: Technical Data

    Technical Data Manufacturer IBERNA Model Number HUZ107.1 Product Category 8 – Upright Freezer Energy Efficiency Class (1) Annual Energy Consumption (2) 178 kWh Storage Volume of Fridge Compartment Storage Volume of Freezer 95 litres Compartment Star Rating Frost Free Compartments...

  • Page 28: Contact Details
