- Page 1 Sun Ultra 2 Series Reference Manual Sun Microsystems Computer Company A Sun Microsystems, Inc. Business 901 San Antonio Road Palo Alto, CA 94303-4900 USA 650 960-1300 fax 650 969-9131 Part No.: 802-2562-11 Revision A, May 1996...
- Page 2 FAR 52.227-19(6/87), or DFAR 252.227-7015(b)(6/95) and DFAR 227.7202-3(a). Sun, Sun Microsystems, the Sun logo, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and in other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc. in the United States and in other countries.
-
Page 3: Table Of Contents
Contents Preface ix How This Book Is Organized x Using UNIX Commands x Typographic Conventions xi Shell Prompts xi Related Books xiii Sun Documentation on the Web xiii Sun Welcomes Your Comments xiii Back Panel Connectors 1-1 Connector Layout 1-1 Serial Connectors 1-3 Parallel Connector 1-4 Keyboard/Mouse Connector 1-5... - Page 4 Modem Switch Settings (AT Commands) 3-3 Main Logic Board Jumpers 4-1 Identifying Jumpers 4-3 Flash PROM Jumpers 4-3 Serial Port Jumpers 4-4 System Specifications 5-1 Power 5-1 Environment 5-2 Physical Specifications 5-3 Memory Mapping 5-3 Sun Ultra 2 Series Reference Manual • May 1996...
- Page 5 Figures Ultra 2 Series Nameplates ix FIGURE P-1 Ultra Enterprise 2 Nameplate x FIGURE P-2 Back Panel Switches and Connectors 1-2 FIGURE 1-1 DB-25 Serial Connectors 1-3 FIGURE 1-2 DB-25 Parallel Connector 1-4 FIGURE 1-3 DIN-8 Keyboard/Mouse Connector 1-5 FIGURE 1-4 40-Pin Miniature-D MII Connector 1-6 FIGURE 1-5 RJ-45 TPE Connector 1-7...
- Page 6 Sun Ultra 2 Series Reference Manual • May 1996...
- Page 7 Tables Typographic Conventions xi TABLE P-1 Shell Prompts xi TABLE P-2 Related Books xiii TABLE P-3 Serial Connector Pinouts, RS-423/RS-232 1-3 TABLE 1-1 Parallel Connector Pinouts 1-4 TABLE 1-2 Keyboard/Mouse Connector Pinouts 1-5 TABLE 1-3 MII Connector Pinouts 1-6 TABLE 1-4 TPE Connector Pinouts 1-7 TABLE 1-5 68-Pin SCSI Connector Pinout 1-8...
-
Page 8: Table
Physical Clearances 5-3 TABLE 5-5 Main Logic Board Memory Mapping 5-3 TABLE 5-6 viii Sun Ultra 2 Series Reference Manual • May 1996... -
Page 9: Preface
Preface The Sun Ultra 2 Series Reference Manual contains useful information about the use and maintenance of a Sun Ultra 2 Series system. ™ ™ This book is for use with Ultra 2, Ultra 2 Creator, Ultra 2 Creator 3D, and Ultra Enterprise 2 systems only. -
Page 10: How This Book Is Organized
Chapter 2 presents a full tutorial about connecting the system to a 10BASE-T twisted-pair Ethernet (TPE} local area network (LAN). Chapter 3 gives modem settings for Sun Ultra 2 Series systems used in specific network telecommunication applications. Chapter 4 gives the locations and pin definitions of user-configurable main-logic board jumpers. -
Page 11: Typographic Conventions
See one or more of the following for this information: Solaris 2.x Handbook for SMCC Peripherals (If you are incorporating Solaris 2.x software commands in your document, delete this sentence.) AnswerBook™ online documentation for the Solaris™ 2.x software environment Other software documentation that you received with your system Typographic Conventions Typographic Conventions TABLE P-1... -
Page 12: Table P-2 Shell Prompts
Shell Prompts TABLE P-2 Shell Prompt C shell superuser machine_name# Bourne shell and Korn shell Bourne shell and Korn shell superuser Sun Ultra 2 Series Reference Manual • May 1996... -
Page 13: Related Books
The following documents contain topics that relate to the information in the Sun Ultra 2 Series Reference Manual. Related Books TABLE P-3 Application Title Part Number Installation Sun Ultra 2 Series Hardware Setup Instructions 802-5933 Installation Sun Ultra 2 Series Installation Guide 802-5934 Service Sun Ultra 2 Series Service Manual 802-2561 Sun Documentation on the Web The docs.sun.com web site enables you to access Sun technical documentation on... - Page 14 Sun Ultra 2 Series Reference Manual • May 1996...
-
Page 15: Back Panel Connectors
C H A P T E R Back Panel Connectors Connector Layout See the following figure. -
Page 16: Figure 1-1 Back Panel Switches And Connectors
Output — UPA Slot Parallel Connector Connector SCSI Connector Power On/Standby Switch Connector Audio Connectors Headphones — Line Out — Line In — Microphone Back Panel Switches and Connectors FIGURE 1-1 Sun Ultra 2 Series Reference Manual • May 1996... -
Page 17: Serial Connectors
Serial Connectors DB-25 Serial Connectors FIGURE 1-2 Serial Connector Pinouts, RS-423/RS-232 TABLE 1-1 Function Signal Description none none Not connected Transmit Data Receive Data Ready To Send Clear To Send Data Set Ready Signal Ground Data Carrier Detect 9-14 none none Not connected TRxC... -
Page 18: Parallel Connector
Data[1] nFault Data[2] nInit Data[3] nSelectln Data[4] Signal Ground Data[5] Signal Ground Data[6] Signal Ground Data[7] Signal Ground Data[8] Signal Ground nAck Signal Ground Busy Signal Ground PError Signal Ground Select Sun Ultra 2 Series Reference Manual • May 1996... -
Page 19: Keyboard/Mouse Connector
Keyboard/Mouse Connector DIN-8 Keyboard/Mouse Connector FIGURE 1-4 Keyboard/Mouse Connector Pinouts TABLE 1-3 Description Description Ground Keyboard Out Ground Keyboard In +5 VDC Power Key In Mouse In +5 VDC Note – All signals are standard TTL levels. The +5V supply is fuse-protected. Chapter 1 Back Panel Connectors... -
Page 20: Media Independent Interface (Mii) Connector
Signal Ground RXD<0> Signal Ground RX_DV Signal Ground RX_CLK Signal Ground RX_ER Signal Ground TX_ER Signal Ground TX_CLK Signal Ground TX_EN Signal Ground TXD<0> Signal Ground TXD<1> Ground TXD<2> Ground TXD<3> Ground Sun Ultra 2 Series Reference Manual • May 1996... -
Page 21: Twisted-Pair Ethernet (Tpe) Connector
MII Connector Pinouts (Continued) TABLE 1-4 Function Function Signal Ground Signal Ground Twisted-Pair Ethernet (TPE) Connector RJ-45 TPE Connector FIGURE 1-6 TPE Connector Pinouts TABLE 1-5 Description Description Transmit Data + Common Mode Termination Transmit Data - Receive Data - Receive Data + Common Mode Termination... -
Page 22: Scsi Connector
Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground -DB<12> Ground -DB<13> TERMPWR -DB<14> TERMPWR -DB<15> Not connected -PAR<1> Ground -DB<0> -DB<1> -REQ -DB<2> Reserved Sun Ultra 2 Series Reference Manual • May 1996... -
Page 23: Scsi Implementation
68-Pin SCSI Connector Pinout (Continued) TABLE 1-6 Signal Name Signal Name -DB<3> Ground -DB<4> -ATN -DB<5> Ground -DB<6> -BSY -DB<7> -ACK -PAR<0> -RST Ground -MSG TERM.DIS TERMPWR -DB<8> TERMPWR -DB<9> -SEL -DB<10> -DB<11> Note – All signals shown in are active low. TABLE 1-6 1.7.1 SCSI Implementation... -
Page 24: Scsi Cabling And Configuration
Ultra 2 Non-Sun series device device device 68—68 68—68 68—68 Ultra 2 Non-Sun 50-pin series device device device 68—68 68—50 68—68 Terminator Adapter cable Connecting External Mass Storage Devices FIGURE 1-8 1-10 Sun Ultra 2 Series Reference Manual • May 1996... -
Page 25: Audio Ports
Audio Ports Audio Ports: Headphones — Line Out — Line In — Microphone Audio Port Locations FIGURE 1-9 All audio ports use EIA standard 3.5-mm (0.125-inch) jacks. Audio Port Signals TABLE 1-7 Headphones Line Out Line In Microphone Left Channel Left Channel Left Channel Left Channel... -
Page 26: Audio Specifications
TABLE 1-10 Speaker Specifications Power Output 1.5W ave., 3W peak Distortion 0.02 percent typical at 1 kHz Impedance 16 ohms +/- 20 percent Frequency Response 150 Hz-17 kHz +/- 0.5 dB 1-12 Sun Ultra 2 Series Reference Manual • May 1996... -
Page 27: Graphics Card 13W3 Video Connector
1.10 Graphics Card 13W3 Video Connector 13W3 Video Connector FIGURE 1-10 The graphics card for your system provides the 13W3 video connector for transmitting video output signals from the system unit to the monitor. See the following table for 13W3 video connector pinouts. 13W3 Video Connector Pinouts TABLE 1-11 Function... - Page 28 1-14 Sun Ultra 2 Series Reference Manual • May 1996...
-
Page 29: 10Base-T Twisted-Pair Ethernet Link Test
C H A P T E R 10BASE-T Twisted-Pair Ethernet Link Test Read this chapter if you are connecting your Ultra 2 Series system to a 10BASE-T twisted-pair Ethernet (TPE) network. This chapter contains important information for getting your system to communicate correctly over a TPE network. If you have no experience with TPE networks, ask your system or network administrator to perform the procedures in this chapter. -
Page 30: Figure 2-1 Hosts And Hub In A Local Area Network
Host Host Host Ultra 2 Series (Host) Host Host Hosts and Hub in a Local Area Network FIGURE 2-1 Sun Ultra 2 Series Reference Manual • May 1996... -
Page 31: Technical Discussion
Link Test Two-Way Communication Link Test Enabled Enabled (Default) Ultra 2 Series Link Test Ultra 2 Series may boot Link Test Enabled successfully, but with “lost Disabled (Default) carrier” or “no carrier” error messages. Ultra 2 Series Ultra 2 Series may boot Link Test successfully, but other hosts Link Test... -
Page 32: Troubleshooting
Check to see if your hub is hardwired for link test disabled. If it is, you must follow the “Checking or Disabling the Link Test” procedure elsewhere in this chapter to disable the link test at your Ultra 2 Series host. Sun Ultra 2 Series Reference Manual • May 1996... -
Page 33: Moves And Changes
Moves and Changes If the Ultra 2 Series host is physically moved to another network location or if the hub is reconfigured, remember to refer back to . Unless the new network FIGURE 2-2 relationship between the host and the hub is functional (that is, 1-1 link test enabled- link test enabled or 0-0 link test disabled-link test disabled), there will be no full, regular two-way communication between the host and the hub. -
Page 34: Enabling The Link Test
= true ok reset-all 2. Boot the host and verify that the transceiver cable problem messages do not appear. Type either boot net or boot disk and press Return. Sun Ultra 2 Series Reference Manual • May 1996... -
Page 35: Modem Setup Specifications
C H A P T E R Modem Setup Specifications Setting Up the Modem Any modem compatible with U.S. Robotics‘ or CCITT V.24 can be connected to the Ultra 2 Series serial ports. Modems can be set up to function in one of three ways: Dial out only Dial in only Bidirectional Calls... -
Page 36: Serial Port Speed Change
4. Press Esc and type :wq to save your file change(s) and to exit from the vi text editor. Recommendations 3.3.1 Cable For a modem-to-host (system) connection, use an RS-423/RS-232 straight-through cable with DB-25 male connectors at both ends. Sun Ultra 2 Series Reference Manual • May 1996... -
Page 37: Modem Switch Settings (At Commands)
3.3.2 Modem Switch Settings (AT Commands) Enable transmit flow control (AT&H1) [suggested setting] (Required for sending binary/8-bit data) Set link rate to fixed (Will not track modem data rate, AT&Bn; n = menu choice in modem manual.) Set display result codes (ATQ0) Set verbal result codes (ATV1) Set result code subset (ATXn;... - Page 38 Sun Ultra 2 Series Reference Manual • May 1996...
-
Page 39: Main Logic Board Jumpers
C H A P T E R Main Logic Board Jumpers Jumper settings given in this chapter refer to etchings on the main logic board. Jumpers are labeled with the letter “J” followed by a four-digit number. See the following figure. - Page 40 0601,0701,0401,U0501 Disk drive sd0 0602, 0702, 0402, 0502 0603, 0703, 0403, 0503 0604, 0704, 0404, 0504 Disk drive sd1 Speaker Front panel Jumper Locations on the Main Logic Board FIGURE 4-1 Sun Ultra 2 Series Reference Manual • May 1996...
-
Page 41: Identifying Jumpers
Identifying Jumpers Jumpers are marked on the main logic board with part numbers. For example, the serial port jumpers are marked J2104 and J2105. Jumper pins are located immediately adjacent to the part number. Pin 1 is marked with an asterisk in any of the positions shown in the following figure. -
Page 42: Serial Port Jumpers
Default Jumper Jumper Pins 1 + 2 Select Pins 2 + 3 Select on Pins Signal Controlled J2104 RS-232 RS-423 2 + 3 RS232/RS423 J2105 RS-232 RS-423 2 + 3 RS232/RS423 Sun Ultra 2 Series Reference Manual • May 1996... -
Page 43: System Specifications
C H A P T E R System Specifications Power The following table lists power specifications. Power Specifications TABLE 5-1 Input/Output Specifications AC Power Input 100-240 VAC nominal, 47-63 Hz. DC Power Output 350 W maximum... -
Page 44: Environment
Vibration 0.5 G, 5 to 500 Hz, swept sine — IEC 68-2-06 Temperature 20 degrees C to 55 degrees C (-4 degrees F to 131 degres F) — IEC 68-2-01, 68-2-0 Sun Ultra 2 Series Reference Manual • May 1996... -
Page 45: Physical Specifications
Physical Specifications Dimensions and Weight TABLE 5-4 Height Width Depth Weight 13.0 cm (5.12 in.) 45.0 cm (17.72 in.) 45.2 cm (17.94 in.) 15.88 kg (35.0 lb) Physical Clearances TABLE 5-5 Clearance Specification Compact Disc/Diskette 16.51 cm (6.5 in.) System Unit Parallel Placement 7.6 cm (3.0 in.) 1. - Page 46 Sun Ultra 2 Series Reference Manual • May 1996...
