Liquid-Fuel Stove
Instructions for use
© 2006 The Coleman Company, Inc.
www.coleman.com
Model 9760 Series
U.S. Pat. No. 5,370,527
Canada Pat. No. 2,089,804
and other patents pending.
IMPORTANT
Read this manual carefully before assembling, using or servicing these stoves. Keep
this manual for future reference. If you have questions about assembly, operation,
servicing or repair of these stoves, please call Coleman at 1-800-835-3278 or TDD:
316-832-8707. In Canada call 1-800-387-6161.
Apollo™
CSA B140.9.2
Portable Pressurized Type Liquid
Petroleum Fuelled Camp Stoves
Reflector disc and
windscreen not shown.
®
Advertisement
Table of Contents
Related Manuals for Coleman Apollo 9760-A25
Summary of Contents for Coleman Apollo 9760-A25
- Page 1 Read this manual carefully before assembling, using or servicing these stoves. Keep this manual for future reference. If you have questions about assembly, operation, servicing or repair of these stoves, please call Coleman at 1-800-835-3278 or TDD: 316-832-8707. In Canada call 1-800-387-6161.
-
Page 2: For Your Safety
Safety precautions are essential when any 3. Disconnect from Coleman® fuel or liquid fueled equipment is involved. These precautions are necessary when fuel supply. using, storing, and servicing. Using this equipment with the respect and caution demanded will reduce the possibilities of personal injury or property damage. - Page 3 Be sure stove has no flame before opening fuel canister. • EXPLOSION - FIRE HAZARD • Coleman® stove Model 9760 is designed for use only with fuel bottles marked “Model • During lighting and operation, this product can 9760”.
-
Page 4: Technical Characteristics
• Clean stove frequently to avoid grease heater. Never leave stove accumulation and possible grease fires. unattended while burning. • During Coleman® fuel set-up, check all connections for leaks. Liquid Coleman® fuel 9. Keep stove away from flammables. present at connections indicates a leak. - Page 5 Becoming Familiar with your Coleman® liquid fuel Stove Thank you for purchasing your new Coleman® liquid fuel stove. The stove is a high performance liquid fuel cooking appliance. We recommend operating the the stove in a safe location outside your home to familiarize yourself with its liquid fuel operation before your next outdoor experience.
- Page 6 Identification READ AND FOLLOW NOTE: The reflector disc and windscreen are not illustrated in ADDITIONAL the set up instructions. This is so the features of the stove may be clearly visible and identified. Read about the reflector disc INSTRUCTIONS ON and windscreen in Sections 1 and 9.
-
Page 7: Stove Set Up
FIG. 7 FIG. 6 ■ Use a funnel or suitable filling device and fill with clean, fresh Coleman® fuel. ■ Fill bottle no more than 2/3 full (16 Fl. Oz.). Overfilling can result in fuel leakage and flare up during lighting. Your index finger can be used to check the fuel level. - Page 8 To Attach Fuel Bottle ■ Make sure FUEL VALVE is fully “OFF” (Fig 12). ■ Connect hose to threaded fitting on fuel bottle, making sure the bottle is lying on its side with the fuel valve up. Hand tighten the connection (Fig. 13). FIG.
-
Page 9: Fuel Valve
To Pump ■ Make sure FUEL VALVE is fully “OFF” (Fig 17). ■ Place thumb over hole in PUMP KNOB and pump 25 full strokes (Fig 18). Adequate air pressure is important, do not over pump. FUEL VALVE FIG. 17 FIG. - Page 10 To Light NEVER FILL OR LIGHT STOVE INSIDE HOUSE, CAMPER, OR TENT. ■ Make sure fuel bottle is lying level on its side with the FUEL VALVE up (Fig. 20). ■ Turn flame adjuster back and forth several times to clean generator tip (Fig. 21). ■...
-
Page 11: Explosion - Fire Hazard
DANGER • EXPLOSION - FIRE HAZARD • Always attach or detach fuel canisters outdoors; never while stove is lighted, near flame, pilot lights, other ignition sources or while stove is hot to touch. • This stove is very hot during use and can ignite flammables too close to the burners. - Page 12 To Store ■ Make sure stove is cool. ■ Move stove away from flame (including pilot lights) and other ignition sources. ■ Disconnect the fuel hose at the threaded fitting attached to the fuel bottle. ■ If some liquid fuel remains in the fuel hose, drain the excess fuel before placing the stove in your backpack or storage container.
-
Page 13: Troubleshooting
Burner will not Fuel bottle empty. Refill fuel bottle 2/3 full with clean and light or flame fresh Coleman® fuel or unleaded fuel. self- extinguished. Burner will not Little or no pressure in fuel Check connections for leaks and light or flame is bottle. -
Page 14: Replacement Parts List
Replacement Parts List Item Part No. Description 9770-5051 Plunger Assembly 9770-5551 Pump and Valve Assembly R9760-501 Stove Maintenance Kit (includes one item on the next page) 9770-5611 Service Parts Kit (includes one item on the next page) 9760-5081 Fuel Bottle Assembly (22 fl. oz. capacity) “O”... - Page 15 Replacement Parts List Item Part No. Description 9780-5271 Burner Assembly Complete w/ Hdwe 9760-5201 Stove Leg Kit (3 pk) 9760-5251 Valve Assembly 9770-5151 Hose Assembly with Cap R9770-120 Windscreen and Reflector Disc “O” Ring English-14...
-
Page 16: Warranty
Coleman, at its option, will repair or replace this yellow flame. This can be corrected by product or any component of the product found to be defective adjusting the flame to a slightly higher level during the warranty period. - Page 17 © 2006 The Coleman Company, Inc. Tous droits réservés. Coleman®, Exponent®, et sont des marques déposées alors que Apollo™ est une marque de commerce de The Coleman Company, Inc. © 2006 The Coleman Company, Inc. Todos los derechos reservados. Coleman®, Exponent®, y son marcas registradas y Apollo™...
