- Page 1 GETTING STARTED GUIDE NI 9230 3 AI, ±30 V, 24 Bit, 12.8 kS/s/ch Simultaneous...
-
Page 2: Safety Guidelines
This document explains how to connect to the NI 9230. In this document, the NI 9230 with screw terminal and the NI 9230 with BNC are referred to inclusively as the NI 9230. Before you begin, complete the software and... -
Page 3: Safety Voltages
Such voltage measurements include signal levels, special equipment, limited-energy parts of equipment, circuits powered by regulated low-voltage sources, and electronics. NI 9230 Getting Started Guide | © National Instruments | 3... -
Page 4: Safety Guidelines For Hazardous Locations
CAT III, or CAT IV. Safety Guidelines for Hazardous Locations The NI 9230 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 and Ex nA IIC T4 hazardous locations; and nonhazardous locations only. - Page 5 AI+ to AI- voltage from exceeding 42 V if there is a transient overvoltage condition. For Division 2 and Zone 2 applications, Caution connected signals must be within the following limits. Capacitance 0.08 μF max NI 9230 Getting Started Guide | © National Instruments | 5...
-
Page 6: Special Conditions For Hazardous Locations Use In Europe And Internationally
Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9230 in Gas Group IIC hazardous locations, you must use the device in an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment. -
Page 7: Electromagnetic Compatibility Guidelines
To minimize interference with radio and television reception and prevent unacceptable performance degradation, install and use this product in strict accordance with the instructions in the product documentation. NI 9230 Getting Started Guide | © National Instruments | 7... - Page 8 To ensure the specified EMC performance Caution for the NI 9230 with screw terminal, you must install clamp-on ferrite beads (part number 782802-01) in accordance with the product installation instructions. 8 | ni.com | NI 9230 Getting Started Guide...
-
Page 9: Cable Requirements For Emc Compliance
I/O cables must be no longer than 30 m (100 ft). Cable Requirements for EMC Compliance Select and install cables for the NI 9230 in accordance with the following requirements: • Connect the cable shield to the chassis ground (grounding screw of the chassis). -
Page 10: Special Conditions For Marine Applications
Some products are Lloyd’s Register (LR) Type Approved for marine (shipboard) applications. To verify Lloyd’s Register certification for a product, visit ni.com/certification and search for the LR certificate, or look for the Lloyd’s Register mark on the product. 10 | ni.com | NI 9230 Getting Started Guide... -
Page 11: Preparing The Environment
EMC performance is attained. Preparing the Environment Ensure that the environment in which you are using the NI 9230 meets the following specifications. Operating temperature -40 °C to 70 °C... - Page 12 Refer to the device datasheet on ni.com/manuals Note for complete specifications. Connecting the NI 9230 The NI 9230 provides connections to three simultaneously sampled analog input channels. 12 | ni.com | NI 9230 Getting Started Guide...
- Page 13 Each channel has a terminal to which you can connect a signal source. The AI+ terminal of the connector provides the DC excitation, when enabled, and the positive input signal NI 9230 Getting Started Guide | © National Instruments | 13...
-
Page 14: Connecting Signal Sources
NI 9230. If you make a ground-referenced connection between the signal source and the NI 9230, make sure the voltage on the AI+ and the AI- connections are in the channel-to-earth safety voltage range to ensure proper operation of the NI 9230. Refer to the device datasheet on ni.com/manuals... - Page 15 AI– – NI 9230 Integrated Electronic Piezoelectric (IEPE) Sensors The NI 9230 provides an IEPE excitation current for each channel to measure the IEPE sensors. Typical IEPE sensors have NI 9230 Getting Started Guide | © National Instruments | 15...
-
Page 16: Wiring For High-Vibration Applications
IEPE electronics. As a result, connecting the sensor to the NI 9230 results in a floating connection even though the case of the sensor is grounded. Wiring for High-Vibration Applications If your application is subject to high vibration, NI recommends... -
Page 17: Where To Go Next
NI 9230 Datasheet NI-RIO Help NI-DAQmx Help LabVIEW FPGA Help LabVIEW Help RELATED INFORMATION C Series Documentation Services & Resources ni.com/services ni.com/info cseriesdoc Located at ni.com/manuals Installs with the software NI 9230 Getting Started Guide | © National Instruments | 17... -
Page 18: Worldwide Support And Services
(EMC) and product safety. You can obtain the DoC for your product by visiting ni.com/certification. If your product supports calibration, you can obtain the calibration certificate for your product at ni.com/calibration. 18 | ni.com | NI 9230 Getting Started Guide... - Page 19 United States, visit the Worldwide Offices section of ni.com/niglobal to access the branch office websites, which provide up-to-date contact information, support phone numbers, email addresses, and current events. NI 9230 Getting Started Guide | © National Instruments | 19...
