System Upgrades and Repairs
CELSIUS H7613
Version date
Category
Version number
Classification
Contents
Page 1 of 48
14.06.2023
System Upgrades and Repairs
1.0
Non-classified - public
3
4
5
6
7
8
9
10
12
14
15
16
17
18
19
20
21
22
23
24
25
26
28
29
30
31
32
33
34
35
36
37
38
39
41
Advertisement
Table of Contents
Related Manuals for Fujitsu CELSIUS H7613
Summary of Contents for Fujitsu CELSIUS H7613
-
Page 1: Table Of Contents
System Upgrades and Repairs CELSIUS H7613 Version date 14.06.2023 Category System Upgrades and Repairs Version number Classification Non-classified - public Contents System Upgrades and Repairs Information on the installation and removal of components Screws Tools Remove the service door Remove the battery... - Page 2 Remove LCD back cover Spare parts CELSIUS H7613 Additional information CELSIUS H7613 Disposal information for recycling companies Version history Page 2 of 48...
-
Page 3: System Upgrades And Repairs
System Upgrades and Repairs We recommend printing out the relevant sections of this chapter prior to installation as the device for installing/removing hardware components needs to be switched off. The following illustrations may differ from your device, depending on its configuration and features. If you have received any further documents with your device, you should read these through carefully. -
Page 4: Information On The Installation And Removal Of Components
Information on the installation and removal of components These instructions provide information on disassembling the device in addition to upgrading or exchanging components. The steps in these instructions describe the removal of a component. Installation is carried out in the reverse order. Specifics are separately described after the removal. -
Page 5: Screws
Screws Screw: M2.5XL6 (D4.5) Screwdriver: Phillips PH00 (ISO 8764) Screw: M2.0XL2.5 Screwdriver: Phillips PH00 (ISO 8764) Screw: M2.5XL4 Screwdriver: Phillips PH00 (ISO 8764) Return to Table of Contents Page 5 of 48... -
Page 6: Tools
Tools Screwdriver: Phillips PH00 (ISO 8764) Plastic tool (from iFixit: Part # 922-5065) Plastic tool (from iFixit: Part # SKU: EU145335-1) Return to Table of Contents Page 6 of 48... -
Page 7: Remove The Service Door
Remove the service door Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Close the notebook ■ Remove cables and components ► Undo the screw (1). ► Remove the service door (2). Please note that the screw is firmly anchored and cannot be removed. Return to Table of Contents Page 7 of 48... -
Page 8: Remove The Battery
Remove the battery Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door The improper exchanging of the lithium battery can result in a danger of explosions! The lithium battery may be replaced only by a battery recommended by the manufacturer. Do not dispose of lithium batteries in the household waste. -
Page 9: Insert The Battery
Insert the battery Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ► Insert the battery (1). ► Plug in the cable (2). ► Tighten the screws (3). Once the battery has been replaced, the AC adapter needs to be connected to the device so the battery is once again ready for use. -
Page 10: Remove The 3 Rd And 4 Th Memory
Remove the 3 and 4 memory Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery Make sure the screws are tightly fastened and cannot be removed. ► Undo the screws (1). ►... - Page 11 ► Attach the cover (5). ► Tighten the screw (6). Return to Table of Contents Page 11 of 48...
-
Page 12: Insert The 3 Rd And 4 Th Memory
Insert the 3 and 4 memory Required work steps: Required tools: ■ ■ none Remove the service door ■ Remove the battery Make sure the screws are tightly fastened and cannot be removed. ► Undo the screws (1). ► Remove the cover (2). Please note the coding. - Page 13 ► Attach the cover (5). ► Tighten the screws (6). Return to Table of Contents Page 13 of 48...
-
Page 14: Remove The 3 Rd M.2 Module
Remove the 3 M.2 module Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery The model can be provided with three M.2 modules. ► Undo the screw (1). ► Remove the cover (2). ►... -
Page 15: Insert The 3 Rd M.2 Module
Insert the 3 M.2 module Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery The model can be provided with three M.2 modules. ► Undo the screw (1). ► Remove the cover (2). ►... -
Page 16: Mandatory Support Bulletins
Mandatory Support Bulletins SB-M-10030 Minimum requirements to properly finalise hardware repairs on mobile systems SB-M-15007 WIN8x & WIN10 - Spare product key for repaired devices For any information about ESD, please refer to the web-based training course “ESD in electronics“ SB-M-22005 Creating a new Maintenance USB Stick FjAHDT. -
Page 17: Remove The Lower Assy
Remove the lower assy Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ ■ Plastic tool Remove the battery ► Remove the screws (1, 2). ► Remove the cover (3). Return to Table of Contents Page 17 of 48... -
Page 18: Remove The Wwan Module
Remove the WWAN module Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Plastic tool ■ Remove the battery ■ Remove the lower assy (Example picture (Example picture for 4G WWAN) for 5G WWAN) Antenna colour ►... -
Page 19: Remove The Fan
Remove the fan Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ► Remove the cables (1). ► Remove the screws (2). ► Remove the fans (3). Return to Table of Contents Page 19 of 48... -
Page 20: Remove The Usb Sub Board
Remove the USB sub board Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ► Open the connector lock and remove the cable (1). ► Remove the screws (2). ►... -
Page 21: Remove The Sd Card/Smartcard Reader Sub Board
Remove the SD card/SmartCard reader sub board Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ► Open the connector lock and remove the cable (1). ►... -
Page 22: Remove The Bio Secure Fingerprint Sensor
Remove the Bio Secure fingerprint sensor Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove the USB sub board ► Open the connector lock and remove the cable (1). ►... -
Page 23: Remove The Fingerprint Sensor
Remove the fingerprint sensor Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove the USB sub board ■ Remove the Bio Secure fingerprint sensor ►... -
Page 24: Remove The Palm Vein Sensor
Remove the palm vein sensor Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ► Remove the screws (1). ► Remove the cover (2). ► Open the connector lock and remove the cable (3). ►... -
Page 25: Remove The Touchpad Button Sub Board
Remove the touchpad button sub board Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ► Open the connector locks and remove the cables (1). ► Remove the screws (2). -
Page 26: Remove The Keyboard
Remove the keyboard Required work steps: Required tools: ■ ■ none Remove the service door ■ Remove the battery ■ Remove the lower assy ► Lift the upper assy (1), and press the catch down (2). ► Turn the device over. ►... - Page 27 ► Open the connector locks and remove the cables (7). ► Remove the keyboard. Return to Table of Contents Page 27 of 48...
-
Page 28: Remove The 1 St And 2 Nd Memory
Remove the 1 and 2 memory Required work steps: Required tools: ■ ■ none Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ► Undo the screws (1). ► Remove the cover (2). ►... - Page 29 Remove the 1 and 2 M.2 module Required work steps: Required tools: ■ ■ none Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard SSD 2 SSD 1 ► Undo the screws (1). ►...
-
Page 30: Remove The Mainboard/Wlan
Remove the mainboard/WLAN Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove the fans ■ Remove keyboard ■ Remove the 1st and 2nd memory ■... -
Page 31: Remove The Speaker
Remove the speaker Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ■ Remove the fans ■ Remove the mainboard/WLAN ► Remove the screws (1). ►... -
Page 32: Remove The Sub Board Switch
Remove the sub board switch Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ■ Remove the fans ■ Remove the mainboard/WLAN ► Remove the screws (1). -
Page 33: Remove The Cmos Battery
Remove the CMOS battery Required work steps: Required tools: ■ ■ Plastic tool Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ■ Remove the fans ■ Remove the mainboard/WLAN ► Press the battery in the direction of the arrow (1). ►... -
Page 34: Remove The Dc-In Connector
Remove the DC-in connector Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ■ Remove the fans ■ Remove the mainboard/WLAN ► Remove the screws (1). ►... -
Page 35: Remove The Lcd Assy
Remove the LCD assy Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ■ Remove the fans ■ Remove the mainboard/WLAN ► Remove the cables (1). ►... -
Page 36: Remove The Upper Assy
Remove the upper assy Required work steps: Required tools: ■ ■ none Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ■ Remove the fans ■ Remove the mainboard/WLAN ■ Remove the USB sub board ■... -
Page 37: Remove The Lcd Cover
Remove the LCD cover Required work steps: Required tools: ■ ■ Plastic tool Remove the service door ■ Remove the battery ■ Remove the lower assy ► Open the LCD assy (1). ► Disconnect the covers in the direction of the arrow (2). ►... -
Page 38: Remove The Hinges
Remove the hinges Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ■ Remove the fans ■ Remove the mainboard/WLAN ■ Remove LCD assy ►... -
Page 39: Remove The Lcd Panel
Remove the LCD panel Required work steps: Required tools: ■ ■ Tweezers Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove the LCD front cover ► Lift the adhesive foil (1). ► Pull the adhesive foil in the direction of the arrow (2). ►... - Page 40 ► Loosen the adhesive tape (4). ► Open the connector lock and remove the cable (5). ► Remove the panel. Return to Table of Contents Page 40 of 48...
-
Page 41: Remove The Webcam
Remove the webcam Required work steps: Required tools: ■ ■ Plastic tool Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove the LCD front cover ■ Remove the LCD panel ► Open the connector lock and remove the cable (1). ►... - Page 42 Remove LCD back cover Required work steps: Required tools: ■ ■ Screwdriver: Phillips PH00 Remove the service door ■ Remove the battery ■ Remove the lower assy ■ Remove keyboard ■ Remove the fans ■ Remove the mainboard/WLAN ■ Remove LCD assy ■...
- Page 43 Spare parts CELSIUS H7613 Pos. Spare part Internal designation Mechanical parts: Service door Case: Lower assy lower assy Upper assy upper assy LCD back cover LCD back cover assy LCD front cover LCD front cover SSD cover 14.15 Memory cover 25.26...
- Page 44 Processor - only by replacing the mainboard Graphics card: integrated in the main processor - only by replacing the mainboard WLAN module - can be replaced by replacing the mainboard Return to Table of Contents Page 44 of 48...
- Page 45 5 years after end of product life Spare parts can be obtained from our approved and certified service partners: Spare parts - Fujitsu Technical Support pages from Fujitsu EMEA The exploded diagram is available at the following link: Exploded diagram - Fujitsu Technical Support pages from Fujitsu EMEA...
- Page 46 Disposal information for recycling companies These instructions are for the complete dismantling of a Fujitsu product. All materials can thereby be disposed of according to their provision in the EC directive 2012/19/EC (Waste Electrical and Electronic Equipment (WEEE)). Product group:...
- Page 47 Materials which must be disposed of in a special manner Designation Remarks Quantity Plastics which contain brominated flame This product may contain plastic parts with retardant Brominated flame retardants but to the best of our knowledge we provide this information to sort them out.
- Page 48 Version history Version Date Name Change 05.06.2023 Bielichen Page 48 of 48...
