Samsung Electronics owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited. Trademarks other than Samsung Electronics are
Table of contents Before Using the Product Appendix Safety Precautions Responsibility for the Pay Service (Cost to Customers) Safety symbols Not a product defect Electricity and Safety A Product damage caused by customer's fault 14 Installation Others Operation Cleaning License Preparations Ports Connecting Devices...
Chapter 01 Before Using the Product Safety Precautions The following safety instructions are to ensure your personal safety and prevent property CAUTION damage. Please read the following to ensure the proper use of the product. RISK OF ELECTRIC SHOCK. DO NOT OPEN. Safety symbols CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
Warning The product may become damaged by an electric shock. Only use the power cord provided with your product by Samsung. Do not use the power Do not use a damaged power cord or plug, or a loose power socket.
Have a technician install the wall-mount hanger. seriously affect its performance. • Installation by an unqualified person can result in an injury. Be sure to consult Samsung Customer Service Center if you want to install the • Only use approved cabinets. product at such a place.
Be sure to power off the product and disconnect the power cord when water Warning or other foreign substances have entered the product. Then contact Samsung Customer Service Center. There is a high voltage inside the product. Never disassemble, repair or modify the •...
For IW008R: 0.84 x 3.5 m = a distance of at least 2.9 m is recommended (The installation manual is available for download at www.samsung.com/displaysolutions.) Do not use humidifiers or stoves around the product. Contact Customer Service Center if the inside of the product needs cleaning (service fee will be A fire or electric shock may result.
Chapter 02 Preparations Ports " The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Parts Description POWER OUT / 6.6A SWITCH SERVICE SWITCH SERVICE DATA OUT2 Press for 5 seconds to view the system information or for 10 seconds SWITCH to reset to factory settings.
Chapter 03 Connecting Devices Precautions when handling the cabinets [Caution to prevent external shock and dropping of the [Caution to prevent damage to the LED] product] After removing the protective brackets, do not place After removing the protective brackets, be careful not the product on the floor with the LED facing down.
For more information about how to install the frame kit, refer to the user manual that comes with it. • Samsung Electronics shall not be liable for any damage to the product and any injury to the users or others that may be incurred while the users install the product by themselves. Removing the protective brackets...
Connecting to cabinets Connect the HDBT terminals on the M-Box and BRIDGE BOX using a LAN cable. " Use a cable of CAT 6 (*STP type) or higher. *STP: Shielded Twisted Pair Connect the M-Box (SBB-MBOX) and the cabinet (IW008R) to the installed cabinet for video "...
Make sure that the number of connected devices does not exceed the recommended maximum number. " Samsung Electronics is not liable for any problems incurred by connecting devices that exceed the recommended maximum number.
Chapter 04 Specifications General " For detailed device specifications, visit the Samsung Electronics website. Model Name IW008R Pixel Pitch 0.84 mm (USA only) LED pixel configuration Flip Chip LED Dispose unwanted electronics through an approved recycler. Cabinet To find the nearest recycling location, go to our website:...
External impact or drop. " When the service is requested, in spite of in warranty, we may charge you for a visit from a • Use of supplies or separately sold product unspecified by Samsung. service technician in the following cases. •...
GPL/LGPL etc. You may obtain the complete Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to: oss. request@samsung.com If you want to obtain the complete Corresponding Source code in the physical medium such as CD-ROM, the cost of physically performing source distribution may be charged.
