Service Manual
Models
OLF46-AM 6911540100 X-136786
OLF66-AM 6911540200 X-136793
OLF86-AM 6911540300 X-136809
7401160100R00
Advertisement
Table of Contents
Related Manuals for Dimplex 6911540100
Summary of Contents for Dimplex 6911540100
- Page 1 Service Manual Models OLF46-AM 6911540100 X-136786 OLF66-AM 6911540200 X-136793 OLF86-AM 6911540300 X-136809 IMPORTANT SAFETY INFORMATION: Read this manual first before attempting to install or use this electric fireplace. Always comply with the warnings and safety instructions contained in this manual to prevent personal injury or property damage.
-
Page 2: Table Of Contents
NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNING: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, or death. www.dimplex.com... -
Page 3: Exploded Parts Diagrams
Exploded Parts Diagrams Module (2) Reference page 6 for the module OLF46-AM Replacement Parts List replacement parts list . 1. Remote Control ....X-9602730100RP 15. -
Page 4: Exploded Parts Diagrams
13. Module Wire Harness Set ..X-9602790100RP 29. Inline Water Filter ....X-9602950100RP 14. Temperature Sensor (NTC) ... . . 500002352 www.dimplex.com... -
Page 5: Exploded Parts Diagrams
Exploded Parts Diagrams Module (4) Reference page 6 for the module replacement parts list . OLF86-AM Replacement Parts List 15. Front Glass ....X-9602650300RP 1. -
Page 6: Exploded Parts Diagrams
19. Floats and Stopper Kit ... X-9602550100RP 9. Power Supply ....X-9601300100RP 10. Fan Assembly (Flame effect)..X-9602890100RP www.dimplex.com... -
Page 7: Wiring Diagrams
Wiring Diagrams Module A secondary transducer is optional. Only one transducer is needed for operation. -
Page 8: Wiring Diagrams
Wiring Diagrams OLF46-AM Firebox Wiring Diagram WARMUP HEATER To Module 1 To Module 1 Plumbing Diagram To Module To Module www.dimplex.com... -
Page 9: Wiring Diagrams
Wiring Diagrams OLF66-AM Firebox Wiring Diagram WARMUP HEATER To Module 1 To Module 1 Plumbing Diagram To Module To Module To Module... -
Page 10: Wiring Diagrams
Wiring Diagrams OLF86-AM Firebox Wiring Diagram WARMUP HEATER To Module 1 To Module 1 Plumbing Diagram To Module To Module To Module To Module www.dimplex.com... -
Page 11: Replacement Part Procedures
Replacement Part Procedures Preparing for Service WARNING: If the firebox was operating prior to servicing, allow at least 10 minutes for the heating elements to cool off to avoid accidental burning of skin. WARNING: Disconnect power before attempting any maintenance to reduce the risk of electric shock or injury to persons. -
Page 12: Heater Assembly Replacement
7. Tilt the new heater assembly up and secure it using the 4 screws previously removed. 8. Connect the LED wire(s), secure the LED holder(s), and reassemble any brackets removed previously. Figure 3 Remove supporting brackets to allow access. Figure 4 Socket Connectors www.dimplex.com... -
Page 13: Extractor Fan Replacement
Replacement Part Procedures Extractor Fan Replacement Tools Required: Phillips-Head Screwdriver 1. Follow instructions for preparing for service. (Page 11) 2. Remove the 2 screws on the air deflector (Figure 6). NOTE: The side panel is supported by hooks in the back. 3. -
Page 14: Main Control Board Replacement
6. Replace with new board and reconnect all wire harnesses removed previously at the same locations. 7. Secure the panel using the 7 screws removed previously. Pinch standoffs using Power Adaptor pliers to release board Figure 7 LED Driver Board Main Control Board Hidden Touch Controls www.dimplex.com... -
Page 15: Hidden Touch Controls/Housing Replacement
Replacement Part Procedures Hidden Touch Controls/Housing Replacement NOTE: A new QR code sticker comes with the new Hidden Touch Control. The unit will need to be resynced with the app if applicable. Tools Required: Phillips-Head Screwdriver 1. Follow the instructions for preparing for service. (Page 11) 2. -
Page 16: Power Adaptor Replacement
10. Reconnect the lead wires from the power cord to the terminal block (reference the previous connection locations). 11. Secure the top right panel using the 7 screws that were previously removed. Power Cord Figure 9 Power Adaptor Mounting Bracket Power Adaptor Figure 10 Screws for power adaptor bracket www.dimplex.com... -
Page 17: Sound Board And Speaker Replacement
Replacement Part Procedures Sound Board and Speaker Replacement Tools Required: Philips Screwdriver Side cutters (for sound board replacement) 1. Follow the instructions for preparing for service. (Page 11) 2. Remove the 7 screws that secure the electronics panel (right panel). Carefully lower the electronics panel. (Figure 8) NOTE: The electronics panel is supported by hooks in the back. -
Page 18: Top Leds Replacement
6. Install the new splitter board on these standoffs. 7. Transfer the connections from the defective LIN splitter board to the new board. 8. Reinstall the media and media tray. 9. Reinstall the front glass. Figure 13 Splitter Board www.dimplex.com... -
Page 19: Module Replacement
Replacement Part Procedures Module Replacement Tools Required: Phillips Screwdriver and Flat Head Screwdriver. 1. Follow the Preparing for Service instructions. (Page 11) 2. Remove the fill cap by turning it clockwise. 3. Remove the top cover assembly by gently pushing the tabs on both sides until they snap in place. (Figure 14) 4. -
Page 20: Module Terminal Block Replacement
7. Place the electronics cover in its original position in the module and secure the 4 screws. 8. Re-assemble the remainder of the components in reverse order from the Preparing for Service instructions. (Page 11) Access Cover Figure 16 Electronics Cover Figure 17 Terminal Block www.dimplex.com... -
Page 21: Module Fan Assembly Replacement
Replacement Part Procedures Module Fan Assembly Replacement Tools Required: Phillips head screwdriver 1. Follow the Preparing for Service instructions. (Page 11) 2. Remove the access cover screw. (Figure 16) 3. Remove the 4 screws and the electronics cover from the unit. (Figure 16) 4. -
Page 22: Module Fused Wire Harness Replacement
9. Reinstall the electronics cover and access cover in their original position in the module and secure the 5 screws. 10. Re-assemble the remainder of the components in reverse order from the Preparing for Service instructions. (Page 11) Figure 19 Wire harness connection www.dimplex.com... -
Page 23: Module Water Level Sensor Replacement
Replacement Part Procedures Module Water Level Sensor Replacement Tools Required: Phillips head screwdriver 1. Follow the Preparing for Service instructions. (Page 11) 2. Remove the access cover screw. (Figure 16) 3. Remove the 4 screws and the electronic cover from the unit. (Figure 16) 4. -
Page 24: Module Main Control Board Replacement
10. Reinstall the electronics cover and access cover in their original position in the module and secure the 5 screws. 11. Re-assemble the remainder of the components in reverse order from the Preparing for Service instructions. (Page 11) Figure 21 www.dimplex.com... -
Page 25: Module Heating Element Replacement
Replacement Part Procedures Module Heating Element Replacement Tools Required: Phillips head screwdriver 1. Follow the Preparing for Service instructions. (Page 11) 2. Remove the access cover screw. (Figure 16) 3. Remove the 4 screws and the electronic cover from the unit. (Figure 16) 4. -
Page 26: Module Power Supply Replacement
11. Reinstall the electronics cover and access cover in their original position in the module and secure the 5 screws. 12. Re-assemble the remainder of the components in reverse order from the Preparing for Service instructions. (Page 11) Figure 23 Power Supply www.dimplex.com... -
Page 27: Module Solenoid Valve Replacement
Replacement Part Procedures Module Solenoid Valve Replacement Tools Required: Short Phillips head screwdriver 1. Follow the Preparing for Service instructions. (Page 11) 2. Remove the fill cap by turning it clockwise. 3. Remove the top cover assembly by gently pushing the tabs on both sides until they snap in place. (Figure 14) 4. -
Page 28: Troubleshooting & Error Codes
10 seconds before turning it back on. If the error persists and cannot be resolved, go to www.dimplex.com/contact-us to contact Technical Support. Ensure the unit is installed with air intakes for adequate air flow. - Page 29 If Condensation in the unit product is installed in accordance to the user manual and no errors came up, please contact Glen Dimplex Americas customer service for further assistance. Check the linking wires from the Lin...
- Page 30 Ensure the brick power supply input power cord is securely fastened by No Heat or Flame Defective extractor fan pushing into power supply. Restore CD44 power at the main panel. The unit should now be restored to last known working state. www.dimplex.com...
- Page 31 For troubleshooting information related to the Flame Connect app, please visit www. dimplex.com/fcapp DATE 03-01-2023 1-888-346-7539 | www.dimplex.com In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice. © 2023 Glen Dimplex Americas A BRAND OF GLEN DIMPLEX AMERICAS...
