Basic Operations
This section provides an overview of the watch
and explains operations that are common to
all modes.
Watch Face Items
①
② ③ ④
A e mark
When the watch is connected with a phone,
the second hand points to e.
B R mark
When the watch is standing by for connection
with a phone, the second hand points to "R".
C ON mark
When the watch is in the Alarm Mode and the
alarm is enabled, the second hand points to
"ON".
D OFF mark
When the watch is in the Alarm Mode and the
alarm is disabled, the second hand points to
"OFF".
E Day of week
In the Calendar Mode, the mode hand points
to the current day of the week.
F AL mark
When the watch is in the Alarm Mode, the
mode hand points to "AL".
G l mark
The mode hand will point to "l" when your
phone has new mail.
H ¢ mark
The mode hand will point to "¢" when your
phone has no new mail.
I Speedometer
When the watch is in the Stopwatch Mode, the
mode hand will point to a speed value after an
elapsed time measurement is complete.
* Requires specification of the distance
traveled and a distance unit with CASIO
WATCH+.
Viewing Speed Data
l
J Airplane Mode
When the watch is in the Airplane Mode, the
mode hand points to h.
Operation Guide 5419
Navigating Between Modes
Your watch has the modes shown below.
(Approximately
⑤
⑥
⑦
⑧
⑨
⑩
A
Alarm Mode
Use (A) to navigate between modes. Hold
down (A) for about two seconds to enter the
Calendar Mode. To connect with a phone,
hold down (C) for about 0.5 seconds.
Mode Overview
Calendar Mode
In this mode, the main hour and minute hands
indicate the current time, while the small hour
and minute hands show another time (Dual
Time).
Airplane Mode
(Hold down about
4 seconds.)
A Dual Time minute
*
B Current time second
C Dual Time hour
D Dual Time 24-hour hand
E Day of the week at current location
* The A-side of the dial indicates an a.m. time,
while the P-side indicates a p.m. time.
Bluetooth connection
C C
0.5 seconds)
Calendar Mode
A
Stopwatch Mode
A
① ②
③ ④ ⑤
*
Stopwatch Mode
In this mode, the main hour and minute hands
indicate the current time, while the small hour
and minute hands show elapsed time as
measured by the stopwatch.
Airplane Mode
① ②
(Hold down about
4 seconds.)
Start/Stop
Split/Reset
③ ④ ⑤
A Stopwatch minutes
B Stopwatch seconds
C Stopwatch hours
D Stopwatch 24-hour hand *
E Split speed
* The A-side of the dial indicates hours 0
through 12, while the P-side indicates hours
12 through 24.
Alarm Mode
In this mode, the main hour and minute hands
indicate the current time, while the small hour
and minute hands show the alarm time setting.
Airplane Mode
① ② Enabling/Disabling
(Hold down about
4 seconds.) the Alarm
③ ④ ⑤
A Alarm minute
B Alarm enable/disable
C Alarm hour
D Alarm 24-hour hand *
E Mode
* The A-side of the dial indicates an a.m. time,
while the P-side indicates a p.m. time.
