HIGH EFFICIENCY CONDENSING
99,000 & 125,000 Btu/hr Models
160,000 & 199,000 Btu/hr Models
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury, or loss of life.
Do not store or use gasoline or other flammable vapors and liquids or other
combustible materials in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified licensed installer,
service agency or the gas supplier.
COMBI BOILER
(Natural Gas or Propane)
Advertisement
Table of Contents
Related Manuals for Rheem RCBH-L199i
Summary of Contents for Rheem RCBH-L199i
- Page 1 HIGH EFFICIENCY CONDENSING COMBI BOILER 99,000 & 125,000 Btu/hr Models 160,000 & 199,000 Btu/hr Models (Natural Gas or Propane) WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. Do not store or use gasoline or other flammable vapors and liquids or other combustible materials in the vicinity of this or any other appliance.
