Yamaha X-MAX 400 ABS 2018 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
X-MAX 400 ABS
MOTORCYCLE
Read this manual carefully before oper-
ating this vehicle.
YP400RA
BL1-F8199-E1

Advertisement

Table of Contents
loading

Related Manuals for Yamaha X-MAX 400 ABS 2018

Summary of Contents for Yamaha X-MAX 400 ABS 2018

  • Page 1 OWNER’S MANUAL X-MAX 400 ABS MOTORCYCLE Read this manual carefully before oper- ating this vehicle. YP400RA BL1-F8199-E1...
  • Page 2 XMTR COMP. (Hand Unit) Frequency band: 433.92 MHz The maximum radio frequency power: 10 mW Manufacturer: MITSUBISHI ELECTRIC CORPORATION HIMEJI WORKS 840, Chiyoda-machi, Himeji, Hyogo 670-8677, Japan Importer: YAMAHA MOTOR EUROPE N.V. Koolhovenlaan 101, 1119 NC Schiphol-Rijk, 1117 ZN, Schiphol, the Netherlands...
  • Page 3 If you have any further questions, do not hesitate to con- tact your Yamaha dealer. The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first! Yamaha continually seeks advancements in product design and quality. There-...
  • Page 4 Important manual information EAU63350 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury haz- ards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 5: Table Of Contents

    Table of contents Safety information ......1-1 For your safety – pre-operation Further safe-riding points....1-5 checks ..........5-1 Description ........2-1 Operation and important riding Left view ..........2-1 points..........6-1 Right view........2-2 Starting the engine......6-2 Controls and instruments....2-3 Starting off ........6-3 Acceleration and deceleration ..
  • Page 6 Table of contents Checking and lubricating the cables........7-25 Checking and lubricating the throttle grip and cable....7-26 Lubricating the front and rear brake levers....... 7-26 Checking and lubricating the centerstand and sidestand ..7-27 Checking the front fork....7-27 Checking the steering....

  • Page 7: Safety Information

    Safety information an accident or equipment damage. EAU1026B See page 5-1 for a list of pre-operation checks. Be a Responsible Owner  This scooter is designed to carry As the vehicle’s owner, you are re- the operator and a passenger. sponsible for the safe and proper oper- ...
  • Page 8 Safety information  This scooter is designed for on- • Know your skills and limits. Staying within your limits may road use only. It is not suitable for help you to avoid an accident. off-road use. • We recommend that you prac- tice riding your scooter where Protective Apparel there is no traffic until you have...
  • Page 9 Safety information engine exhaust. Deadly levels of car- The total weight of the operator, pas- bon monoxide can collect rapidly and senger, accessories and cargo must you can quickly be overcome and un- not exceed the maximum load limit. able to save yourself. Also, deadly lev- Operation of an overloaded vehicle els of carbon monoxide can linger for could cause an accident.
  • Page 10 Genuine not in any way reduce ground Yamaha accessories, which are avail- clearance or cornering clearance, able only from a Yamaha dealer, have limit suspension travel, steering been designed, tested, and approved travel or control operation, or ob- by Yamaha for use on your vehicle.

  • Page 11: Further Safe-Riding Points

    Safety information Aftermarket Tires and Rims EAU57600 Further safe-riding points The tires and rims that came with your  Be sure to signal clearly when scooter were designed to match the making turns. performance capabilities and to pro-  Braking can be extremely difficult vide the best combination of handling, on a wet road.

  • Page 12: Description

    Description EAU63371 Left view 1. Storage compartment A (page 4-21) 2. Owner’s tool kit (page 7-2) 3. Grab bar (page 6-3) 4. Shock absorber assembly spring preload adjusting ring (page 4-26) 5. Air filter element (left) (page 7-15) 6. Final transmission oil filler cap (page 7-12) 7.

  • Page 13: Right View

    Description EAU63391 Right view 1. Rear storage compartment (page 4-21) 2. Fuel tank cap (page 4-18) 3. Storage compartment B (page 4-21) 4. Windshield (page 4-23) 5. Battery (page 7-29) 6. Fuses (page 7-30) 7. Centerstand (page 7-27) 8. Air filter element (right) (page 7-15) 9.

  • Page 14: Controls And Instruments

    Description EAU63401 Controls and instruments 13 12 1. Rear brake lever (page 4-14) 2. Left handlebar switches (page 4-12) 3. Rear brake fluid reservoir (page 7-23) 4. Speedometer (page 4-2) 5. Multi-function display (page 4-3) 6. Tachometer (page 4-3) 7. Front brake fluid reservoir (page 7-23) 8.

  • Page 15: Smart Key System

    Smart key system  If you have an electric medical EAU76444 Smart key system device, consult a doctor or the The smart key system enables you to device manufacturer before us- operate the vehicle without using a ing this vehicle. mechanical key.

  • Page 16: Operating Range Of The Smart Key System

    Smart key system In such situations, move the smart EAUM3960 Operating range of the smart key to another location and perform key system the operation again. If it still does The operating range of the smart key not work, operate the vehicle in system is about 80 cm (31.5 in) from emergency mode.

  • Page 17: Handling Of The Smart Key And Mechanical Keys

    Smart key system tem does not operate, see page EAU78623 Handling of the smart key and 3-5 and confirm that the smart key mechanical keys is turned on.  Placing the smart key in the front or rear storage compartment may block communication between the smart key and the vehicle.
  • Page 18  Do not submerge the smart key Yamaha dealer check the vehicle.  If the smart key continually re- in water or other liquids.  Do not place heavy items or ex- ceives radio waves, the smart key battery will discharge quickly.

  • Page 19: Smart Key

     You can register up to six smart EAU76471 Smart key keys for the same vehicle. See a Yamaha dealer regarding spare smart keys.  If a smart key is lost, contact a Yamaha dealer immediately to prevent the vehicle from being stolen.

  • Page 20: Replacing The Smart Key Battery

    Smart key system This feature is convenient for locating EAU76482 Replacing the smart key bat- your vehicle in a parking lot and other tery areas. Replace the battery in the following sit- uations. To turn the answer-back beeper on  The smart key system indicator or off light flashes for about 20 seconds The beeper, which sounds when the...
  • Page 21 Smart key system  Do not expose smart key to ex- cessive heat, such as sunshine or fire. Chemical Burn Hazard - do not in- gest the battery.  If the battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.

  • Page 22: Main Switch

    Smart key system EAU76892 trical systems will be switched off, Main switch which may result in loss of control or an accident. Do not push the main switch knob re- peatedly or turn the main switch back and forth beyond normal use. Other- wise, to protect the main switch from damage, the smart key system will temporarily disable and the smart key...
  • Page 23 Smart key system 2. Push the main switch knob and the smart key indicator light will When the main switch is turned to come on for approximately 4 sec- “OFF” but the smart key cannot be onds. confirmed (the smart key is either out- 3.
  • Page 24 Smart key system 2. While the smart key system indi- “OPEN” position, the smart key system cator light is on, turn the main beeper will sound under the following switch to “OPEN”. conditions.  When the main switch has been in 3.
  • Page 25 Smart key system To lock the steering To use the “ ” position 1. Turn the handlebar all the way to 1. With the main switch in the “ ” the left. position and the smart key turned 2. With the smart key turned on and on and within operating range, within operating range, push the push the main switch knob.
  • Page 26 Smart key system Make sure that fuel tank cap lid is se- curely closed before starting off. 3-12...

  • Page 27: Instrument And Control Functions

    If the warning light does not come on initially when the main switch is turned to “ON”, or if the warning light remains on, have a Yamaha dealer check the vehicle. EAU78171 ABS warning light “ ”...

  • Page 28: Speedometer

    Instrument and control functions braking. Have a Yamaha dealer EAU63544 Speedometer check the brake system and electri- cal circuits as soon as possible. The ABS warning light may come on while accelerating the engine with the vehicle on its centerstand, but this does not indicate a malfunction.

  • Page 29: Tachometer

    Instrument and control functions EAU63551 EAU78485 Tachometer Multi-function display ZAUM1480 ZAUM1481 1. Tachometer 1. Fuel meter 2. Tachometer red zone 2. Information display 3. Coolant temperature meter The electric tachometer allows the rid- 4. Clock er to monitor the engine speed and 5.
  • Page 30  If a problem is detected in the fuel The clock uses a 24-hour time system. meter, the all segments will flash repeatedly. If this occurs, have a To set the clock Yamaha dealer check the vehicle. 1. Turn the main switch to “OFF”.
  • Page 31 If serve tripmeter “F Trip” and start this occurs, have a Yamaha dealer counting the distance traveled from check the vehicle as soon as pos- that point.
  • Page 32 Instrument and control functions Odometer “Odo” tripmeter Fuel reserve tripmeter “F Trip” “Trip” The odometer shows the total distance traveled by the vehicle. The tripmeter shows the distance trav- eled since it was last reset. To reset the tripmeter, select it by pushing the “TRIP”...
  • Page 33 Instrument and control functions Oil change tripmeter “Oil Trip” V-belt replacement tripmeter “V- Belt Trip” ZAUM1488 1. Oil change indicator “Oil” ZAUM1489 2. Oil change tripmeter 1. V-belt replacement indicator “V-Belt” 2. V-belt replacement tripmeter The oil change tripmeter shows the distance traveled since the oil was last V-belt replacement...
  • Page 34 Instrument and control functions L/100 km → Consumption_ _._ km/L Information display → Consumption_ _._ L/100 km → Av- erage → Air-temp For the UK: Push the “TRIP” switch to change the display between the air temperature display “Air-temp”, battery voltage dis- play “Battery”, traction control system display “TCS ON”...
  • Page 35 2. Icy road warning indicator “ ” when using the start switch, have This display shows the air temperature a Yamaha dealer charge the bat- from –10 °C to 50 °C in 1 °C incre- tery. ments.  If “---” appears in the battery volt- The icy road warning indicator “...
  • Page 36 If only “TCS” is displayed, there is a After resetting the average fuel con- communication error within the vehi- sumption, “_ _._” will be shown until cle. Have a Yamaha dealer check the the vehicle has traveled 1 km (0.6 mi). vehicle as soon as possible. Instantaneous...
  • Page 37 Instrument and control functions “H TEMP”: Appears when the top seg- ment of the coolant temperature meter If traveling at speeds under 10 km/h (6 starts flashing. If “H TEMP” is dis- mi/h), “_ _._” is displayed. played, stop the vehicle, then stop the engine, and let the engine cool.

  • Page 38: Handlebar Switches

    Instrument and control functions ter position. To cancel the turn signal EAU1234M Handlebar switches lights, push the switch in after it has re- turned to the center position. Left EAU12501 Horn switch “ ” Press this switch to sound the horn. EAU54212 Stop/Run/Start switch “...

  • Page 39: Front Brake Lever

    Instrument and control functions To use the “TRIP” switch, move the EAU12902 Front brake lever “TRIP/INFO” switch in direction (a). To use the “INFO” switch, move the “TRIP/INFO” switch in direction (b). 1. Front brake lever The front brake lever is located on the 1.

  • Page 40: Rear Brake Lever

    Instrument and control functions EAU12952 EAU12964 Rear brake lever Rear brake lock lever 1. Rear brake lever 1. Rear brake lock lever The rear brake lever is located on the This vehicle is equipped with a rear left side of the handlebar. To apply the brake lock lever to prevent the rear rear brake, pull this lever toward the wheel from moving while stopped at...

  • Page 41: Abs

    Instrument and control functions the vehicle is stopped before mov- EAU78200 ing the rear brake lock lever to the The Yamaha ABS (Anti-lock Brake left. System) features a dual electronic con- trol system, which acts on the front and rear brakes independently.

  • Page 42: Traction Control System

    ABS is operating. How- ating on slippery surfaces, such as un- ever, special tools are required, so paved or wet roads. If sensors detect please consult your Yamaha deal- that the rear wheel is starting to slip (uncontrolled spinning), the traction ECA20100...
  • Page 43 The traction control system will auto- ble. matically disable under certain condi- 4. Have a Yamaha dealer check the tions; such as when a sensor fault is vehicle and turn off the “ ”...

  • Page 44: Fuel Tank Cap

    Instrument and control functions EAU78502 Fuel tank cap To remove the fuel tank cap 1. Turn the main switch to “ ” to open the fuel tank cap lid. 1. Install mark “ ” 2. Close the fuel tank cap lid. EWA11092 WARNING Make sure that the fuel tank cap is...

  • Page 45: Fuel

    Instrument and control functions EAU13213 dry, soft cloth, since fuel may Fuel deteriorate painted surfaces or Make sure there is sufficient gasoline in plastic parts. [ECA10072] the tank. 4. Be sure to securely close the fuel EWA10882 tank cap. WARNING EWA15152 Gasoline and gasoline vapors are WARNING...

  • Page 46: Fuel Tank Overflow Hose

    Your Yamaha engine has been de-  Make sure that the fuel tank over- signed to use premium unleaded gas- flow hose is not blocked, and oline with a research octane number of clean it if necessary.

  • Page 47: Catalytic Converters

    Instrument and control functions EAU13447 EAU78514 Catalytic converters Storage compartments This vehicle is equipped with catalytic converters in the exhaust system. This model is equipped with 3 storage compartments. The front storage com- EWA10863 WARNING partments and rear storage compart- The exhaust system is hot after op- ment are located as shown.
  • Page 48 Instrument and control functions Storage compartment A To open storage compartment A, turn the main switch to “OPEN” and then push the “LID” button. To close storage compartment A, push the storage compartment lid until it is closed. Storage compartment B To open storage compartment B, push 1.

  • Page 49: Windshield

    Instrument and control functions  Since the storage compartment EAU78521 Windshield accumulates heat when ex- To suit the rider’s preference, the wind- posed to the sun and/or the en- shield height can be changed to one of gine heat, do not store anything two positions.
  • Page 50 Instrument and control functions 1. Bolt 1. Bolt 3. Remove the bolts, and then install Tightening torque: the bolts in the desired position. Windshield bolt: 8 N·m (0.8 kgf·m, 5.9 lb·ft) 5. Place the bolt access covers, and then install the quick fasteners. 1.
  • Page 51 Instrument and control functions Tightening torque: Windshield bolt: 8 N·m (0.8 kgf·m, 5.9 lb·ft) 5. Place the bolt access covers, and then install the quick fasteners. 1. Bolt 1. Bolt 4. Install the windshield to the low position by installing the bolts, and then tighten the bolts to the spec- ified torque.

  • Page 52: Handlebar Position

    The handlebar can be adjusted to one assemblies of two positions to suit the rider’s pref- EWA10211 WARNING erence. Have a Yamaha dealer adjust the position of the handlebar. Always adjust both shock absorber assemblies equally, otherwise poor handling and loss of stability may re- sult.

  • Page 53: Sidestand

    Therefore, check this system regularly and have a Yamaha dealer repair it if it does not function properly. 4-27...

  • Page 54: Ignition Circuit Cut-Off System

    Instrument and control functions EAU78690 Ignition circuit cut-off system The ignition circuit cut-off system works with the sidestand switch and brake light switches. It has the follow- ing functions.  It prevents the engine from start- ing when the sidestand is down. ...
  • Page 55 3. Keep the front or rear brake applied. • If a malfunction is noted, have a Push the start switch. Yamaha dealer check the system Does the engine start? before riding. The sidestand switch may not be working correctly.

  • Page 56: Auxiliary Dc Jack

    Instrument and control functions 5. Insert the accessory plug into the EAU78213 Auxiliary DC jack auxiliary DC jack. EWA14361 WARNING To prevent electrical shock or short- circuiting, make sure that the cap is installed when the auxiliary DC jack is not being used. ECA15432 NOTICE The accessory connected to the...

  • Page 57: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 58 • Tighten if necessary. Instruments, lights, • Check operation. — • Correct if necessary. signals and switches • Check operation of ignition circuit cut-off system. Sidestand switch • If system is not working correctly, have Yamaha dealer 4-27 check vehicle.

  • Page 59: Operation And Important Riding Points

    This model is equipped with a lean an- there is a control or function you do not gle sensor to stop the engine in case of understand, ask your Yamaha dealer. a turnover. In this case, the engine EWA10272 trouble warning light will come on but WARNING this is not a malfunction.

  • Page 60: Starting The Engine

    Operation and important riding points EAU78231 Starting the engine If the engine does not start, release the ECA10251 NOTICE start switch after 5 seconds. Before pressing the start switch again, wait 10 See page 6-5 for engine break-in in- seconds to allow battery voltage to re- structions prior to operating the ve- store.

  • Page 61: Starting Off

    Operation and important riding points EAU45093 EAU16782 Starting off Acceleration and deceleration 1. While pulling the rear brake lever with your left hand and holding the grab bar with your right hand, push the scooter off the center- stand. The speed can be adjusted by opening and closing the throttle.

  • Page 62: Braking

    Operation and important riding points EAU16794 Front Braking EWA10301 WARNING  Avoid braking hard or suddenly (especially when leaning over to one side), otherwise the scooter may skid or overturn.  Railroad crossings, streetcar rails, iron plates on road con- struction sites, and manhole Rear covers become extremely slip-...

  • Page 63: Tips For Reducing Fuel Consumption

    The vehicle can now be operated nor- mally. ECA10311 NOTICE  Keep the engine speed out of the tachometer red zone.  If any engine trouble should oc- cur during the engine break-in period, immediately have a Yamaha dealer check the vehi- cle.

  • Page 64: Parking

    “OFF” or “ ”. Otherwise, the battery may discharge.  The sidestand alarm beeper can be set to not activate. Please con- tact your Yamaha dealer. EWA10312 WARNING  Since the engine and exhaust system can become very hot,...

  • Page 65: Periodic Maintenance And Adjustment

    Con- considered as a general guide under sult a Yamaha dealer for proper normal riding conditions. However, de- maintenance intervals. pending on the weather, terrain, geo-...

  • Page 66: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 67: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EAU71071...

  • Page 68: General Maintenance And Lubrication Chart

    X 1000 km X 1000 mi • Perform dynamic inspection Diagnostic system √ √ √ √ √ √ using Yamaha diagnostic tool. check • Check the error codes. √ √ 2 * Air filter element • Replace. Air filter case √ √...
  • Page 69 Periodic maintenance and adjustment ODOMETER CHECK OR READINGS MAINTENANCE JOB ITEM X 1000 km X 1000 mi • Check bearing assemblies for √ √ √ looseness. 14 * Steering bearings • Moderately repack with lithium- √ √ soap-based grease. • Make sure that all nuts, bolts √...
  • Page 70 Periodic maintenance and adjustment ODOMETER CHECK OR READINGS MAINTENANCE JOB ITEM X 1000 km X 1000 mi Moving parts and √ √ √ √ √ 27 * • Lubricate. cables • Check operation and free play. • Adjust the throttle cable free Throttle grip hous- √...

  • Page 71: Removing And Installing Panels

    Periodic maintenance and adjustment EAU18773 Removing and installing pan- The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. ZAUM1459 1.

  • Page 72: Checking The Spark Plug

    Do not attempt to diagnose such problems ZAUM1507 yourself. Instead, have a Yamaha deal- 1. Panel B er check the vehicle. If the spark plug shows signs of elec- To install the panel...

  • Page 73: Canister

    Periodic maintenance and adjustment EAU36112 Canister 1. Spark plug gap 1. Canister Spark plug gap: 2. Canister breather hose 0.7–0.8 mm (0.028–0.031 in) Clean the surface of the spark plug gasket and its mating surface, and then wipe off any grime from the spark plug threads.

  • Page 74: Engine Oil And Oil Filter Element

    Periodic maintenance and adjustment 4. If the engine oil is not between the EAUM3940 Engine oil and oil filter ele- tip of the dipstick and the maxi- ment mum level mark, add sufficient oil The engine oil level should be checked of the recommended type to raise before each ride.
  • Page 75 Periodic maintenance and adjustment ment cover, the compression spring will fall out. Take care not Make sure that the O-rings are properly to lose the compression spring. seated. [ECA12912] 8. Install the engine oil drain bolt and its new gasket, and then tighten the bolt to the specified torque.

  • Page 76: Final Transmission Oil

    If any leakage is found, have a and check for the cause. Yamaha dealer check and repair the 11. Reset the oil change indicator. scooter. In addition, the final transmis- (See page 4-7.)

  • Page 77: Coolant

    Periodic maintenance and adjustment 6. Install the final transmission oil EAU20071 Coolant drain bolt and its new gasket, and The coolant level should be checked then tighten the bolt to the speci- before each ride. In addition, the cool- fied torque. ant must be changed at the intervals specified in the periodic maintenance Tightening torque:...
  • Page 78 If water has been left floorboard mat by pulling it up. added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced.

  • Page 79: Air Filter Elements And Check Hoses And V-Belt Case Air Filter Element

    Periodic maintenance and adjustment EAUM3051 Right Air filter elements and check hoses and V-belt case air filter element The air filter elements and the V-belt case air filter element should be ser- viced at the intervals specified in the periodic maintenance and lubrication chart.
  • Page 80 Periodic maintenance and adjustment 5. Install the air filter case cover by Right installing the screws. NOTICE: Make sure that each filter ele- ment is properly seated in its case. Always replace both air fil- ter elements at the same time, otherwise poor engine perfor- mance or damage to the engine may result.

  • Page 81: Checking The Throttle Grip Free Play

    Throttle grip free play: 3.0–5.0 mm (0.12–0.20 in) Periodically check the throttle grip free play and, if necessary, have a Yamaha dealer adjust it. 6. Check the V-belt case air filter ele- ment for damage and replace it if necessary.

  • Page 82: Valve Clearance

    Therefore, it must be adjusted by a Yamaha dealer is essential to maintain the tires in good at the intervals specified in the periodic condition at all times and replace them maintenance and lubrication chart.
  • Page 83 Old and aged tires shall be wall is cracked, have a Yamaha dealer checked by tire specialists to ascertain replace the tire immediately. their suitability for further use.

  • Page 84: Cast Wheels

    If any damage is found, have model by Yamaha. a Yamaha dealer replace the wheel. Do not attempt even the Front tire: smallest repair to the wheel. A de-...

  • Page 85: Checking The Front And Rear Brake Lever Free Play

    ZAUM1050 1. No brake lever free play There should be no free play at the brake lever ends. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 86: Adjusting The Rear Brake Lock Cable

    (page 4-14) functions prop- erly and that the rear wheel rotates freely when unlocked. EWA20290 WARNING ZAUM1514 1. Brake pad wear indicator groove If proper adjustment cannot be ob- tained as described, have a Yamaha dealer make this adjustment. 7-22...

  • Page 87: Checking The Front And Rear Brake Pads

    Specified brake fluid: EAU34211 DOT 4 Rear brake pads Have a Yamaha dealer check each rear EWA16011 brake pad for damage and measure WARNING the lining thickness and if necessary, Improper maintenance can result in replace them as a set.

  • Page 88: Changing The Brake Fluid

     Clean the filler cap before re- EAU22734 Changing the brake fluid moving. Use only DOT 4 brake Have a Yamaha dealer change the fluid from a sealed container. brake fluid every 2 years. In addition,  Use only the specified brake flu- have the seals of the master cylinders id;...

  • Page 89: Checking The V-Belt

    EAU23098 Checking the V-belt Checking and lubricating the The V-belt must be checked and re- cables placed by a Yamaha dealer at the inter- The operation of all control cables and vals specified periodic the condition of the cables should be maintenance and lubrication chart.

  • Page 90: Checking And Lubricating The Throttle Grip And Cable

    The operation of the throttle grip Front brake lever should be checked before each ride. In addition, the cable should be lubricat- ed by a Yamaha dealer at the intervals specified in the periodic maintenance chart. The throttle cable is equipped with a rubber cover.

  • Page 91: Checking And Lubricating The Centerstand And Sidestand

    If the centerstand or sidestand does ECA10591 not move up and down smoothly, NOTICE have a Yamaha dealer check or re- If any damage is found or the front pair it. Otherwise, the centerstand or fork does not operate smoothly,...

  • Page 92: Checking The Steering

    If there is play in the wheel ward and backward. If any free hub or if the wheel does not turn play can be felt, have a Yamaha smoothly, have a Yamaha dealer dealer check or repair the steer- check the wheel bearings.

  • Page 93: Battery

    ZAUM1527 1. Negative battery lead (black) To charge the battery 2. Positive battery lead (red) Have a Yamaha dealer charge the bat- 3. Battery tery as soon as possible if it seems to have discharged. Keep in mind that the The battery is located behind panel B.

  • Page 94: Replacing The Fuses

    Periodic maintenance and adjustment 3. Fully charge the battery before in- EAU78242 Replacing the fuses stallation. NOTICE: When install- The main fuse and the fuse boxes, ing the battery, be sure to turn which contain the fuses for the individ- the main switch off, then con- ual circuits, are located under panel B.
  • Page 95 2. Remove the blown fuse, and then 4. If the fuse immediately blows install a new fuse of the specified again, have a Yamaha dealer amperage. WARNING! Do not check the electrical system. use a fuse of a higher amperage...

  • Page 96: Headlights

    This model is equipped with LED-type headlights. auxiliary lights. If a headlight does not come on, have If an auxiliary light does not come on, a Yamaha dealer check its electrical have a Yamaha dealer check it. circuit. ECA16581 NOTICE Do not affix any type of tinted film or stickers to the headlight lens.

  • Page 97: Brake/Tail Light

    This model is equipped with an LED- If a front turn signal light does not type brake/tail light. come on, have a Yamaha dealer check If the brake/tail light does not come on, its electrical circuit or replace the bulb.

  • Page 98: Rear Turn Signal Light Bulb

    Replacing the license plate If a rear turn signal light does not come light bulb on, have a Yamaha dealer check the 1. Remove the license plate light unit electrical circuit or replace the bulb. by removing the bolts and plate,...

  • Page 99: Troubleshooting

    Please have the vehi- self. However, should your vehicle re- cle battery charged or replaced. quire any repair, take it to a Yamaha (See page 7-29.) dealer, whose skilled technicians have If the smart key system does not work...

  • Page 100: Troubleshooting Charts

    Check the vehicle. compression. 4. Compression The engine does not start. There is compression. Have a Yamaha dealer check the vehicle. Operate the electric starter. There is no Have a Yamaha dealer check the vehicle. compression. 7-36...
  • Page 101 Start the engine. If the engine overheats again, The coolant level is have a Yamaha dealer check and repair the cooling system. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 102: Emergency Mode

    Periodic maintenance and adjustment EAU76561 Emergency mode When the smart key is lost or dam- aged, or its battery has discharged, the 868588 vehicle can still be turned on and the 868588 engine started. You will need the smart key system identification number. To operate the vehicle in emergency mode 1.
  • Page 103 Periodic maintenance and adjustment Release the knob after the smart key system indicator light flashes twice. ↓ The second digit has been set as “2”. ↓ Repeat the above procedure until all digits of the identification num- ber have been set. The smart key system indicator light will flash for 10 seconds if the correct identifi- cation number was entered.

  • Page 104: Scooter Care And Storage

    Rust and corrosion can develop even if matte colored finished parts. Be high-quality components are used. A sure to consult a Yamaha dealer for rusty exhaust pipe may go unnoticed advice on what products to use be- on a car, however, it detracts from the fore cleaning the vehicle.
  • Page 105 Scooter care and storage structed. Also, thoroughly rinse compounds for plastic may the area off with water, immedi- leave scratches on the wind- ately dry it, and then apply a cor- shield. Test the product on a rosion protection spray. small hidden part of the wind- ...
  • Page 106 3. To prevent corrosion, it is recom- mended to apply a corrosion pro-  Consult a Yamaha dealer for ad- tection spray metal, vice on what products to use.

  • Page 107: Storage

    Scooter care and storage head so that the electrodes are EAU36564 Storage grounded. (This will limit spark- ing during the next step.) Short-term d. Turn the engine over several Always store your scooter in a cool, dry times with the starter. (This will place and, if necessary, protect it coat the cylinder wall with oil.) against dust with a porous cover.
  • Page 108 Scooter care and storage Make any necessary repairs before storing the scooter.

  • Page 109: Specifications

    Specifications Dimensions: Final transmission oil: Overall length: Type: 2185 mm (86.0 in) YAMALUBE 10W-40 or SAE 10W-30 type Overall width: SE motor oil 766 mm (30.2 in) Quantity: Overall height: 0.25 L (0.26 US qt, 0.22 Imp.qt) 1415/1465 mm (55.7/57.7 in) Coolant quantity: Seat height: Coolant reservoir (up to the maximum level...
  • Page 110 Specifications Trail: Rear brake: 95 mm (3.7 in) Type: Front tire: Hydraulic single disc brake Type: Specified brake fluid: Tubeless DOT 4 Size: Front suspension: 120/70-15 M/C 56S Type: Manufacturer/model: Telescopic fork MICHELIN/CITY GRIP Spring: Rear tire: Coil spring Type: Shock absorber: Tubeless Hydraulic damper...
  • Page 111 Specifications High beam indicator light: Turn signal indicator light: Engine trouble warning light: ABS warning light: Smart key system indicator light: Traction control system indicator/warning light: Fuse(s): Main fuse: 30.0 A Main fuse 2: 10.0 A Terminal fuse 1: 2.0 A Signaling system fuse: 10.0 A Signaling system fuse 2:...

  • Page 112: Consumer Information

    4-21.) Record the information on this label in the space provided. This information will be needed when order- 1. Vehicle identification number ing spare parts from a Yamaha dealer. The vehicle identification number is stamped into the frame. 10-1...

  • Page 113: Diagnostic Connectors

    Privacy Policy. Privacy Policy https://www.yamaha-motor.eu/eu/ privacy/privacy-policy.aspx Yamaha will not disclose this data to a third party except in the following cas- es. In addition, Yamaha may provide vehicle data to a contractor in order to outsource services related to the han- dling of vehicle data.

  • Page 114: Index

    Index Hazard switch........4-12 Headlights ..........7-32 ABS............4-15 High beam indicator light ....... 4-1 ABS warning light ........4-1 Horn switch .......... 4-12 Acceleration and deceleration ....6-3 Air filter elements and check hoses and V-belt case air filter element....7-15 Identification numbers......10-1 Auxiliary DC jack........4-30 Ignition circuit cut-off system....
  • Page 115 Index Storage........... 8-4 Storage compartments ......4-21 Tachometer ..........4-3 Throttle grip and cable, checking and lubricating .......... 7-26 Throttle grip free play, checking... 7-17 Tires............7-18 Tool kit............ 7-2 Traction control system......4-16 Traction control system indicator light... 4-2 TRIP/INFO switch.........
  • Page 118 Original instructions MBK Industrie Z.I. de Rouvroy 02100 Saint Quentin SAS au capital de 14 000 000 € PRINTED IN FRANCE 2018.05 (E)
