Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
XVS1300AF
12C-28199-28

Advertisement

Table of Contents
loading

Related Manuals for Yamaha XVS1300AF

Summary of Contents for Yamaha XVS1300AF

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XVS1300AF 12C-28199-28...
  • Page 2 EAU46091 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your XVS1300AF. The Owner’s Manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.

  • Page 4: Important Manual Information

    IMPORTANT MANUAL INFORMATION EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10201 XVS1300AF OWNER’S MANUAL ©2014 by Yamaha Motor Co., Ltd. 1st edition, June 2014 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Sidestand ........4-18 Tires ..........7-15 LABELS ..........1-1 Ignition circuit cut-off system ..4-18 Cast wheels ........7-17 Adjusting the clutch lever free SAFETY INFORMATION ....2-1 FOR YOUR SAFETY – play..........7-17 PRE-OPERATION CHECKS .....5-1 Checking the brake lever free DESCRIPTION ........
  • Page 7 TABLE OF CONTENTS Replacing the auxiliary light bulb ..........7-32 Replacing a turn signal light bulb or the tail/brake light bulb ..7-32 Replacing the license plate light bulb ..........7-33 Supporting the motorcycle....7-34 Troubleshooting ......7-35 Troubleshooting charts ....7-36 MOTORCYCLE CARE AND STORAGE ..........8-1 Matte color caution ......8-1 Care ..........8-1 Storage ..........8-3...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 ALWAYS WEAR AN APPROVED MOTORCYCLE HELMET, eye protection, and protective clothing. 1TP-2118K-A1 STATIONARY NOISE TEST INFORMATION TESTED 88 dB(A) 2750 r/min Cold tire normal pressure should be set as follows. SILENCING SYSTEM : YAMAHA IDENTIFICATION : 11C 2.80 12C-2118G-10 2.80 1D7-21668-00...

  • Page 10: Safety Information

    SAFETY INFORMATION  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028B out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 11 SAFETY INFORMATION  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 12 SAFETY INFORMATION  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 13 Yamaha accessories, which are avail- performed to your vehicle that change able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 14 SAFETY INFORMATION  Check that the fuel cock (if operator and may limit control ability, therefore, such accesso- equipped) is in the “OFF” position ries are not recommended. and that there are no fuel leaks.  Use caution when adding electri- ...

  • Page 15: Description

    DESCRIPTION EAU10411 Left view 4,5,6,7 1. Front turn signal light (page 7-32) 9. Rear turn signal light (page 7-32) 2. Headlight (page 7-30) 10.Engine oil drain bolt (page 7-10) 3. Seat lock (page 4-15) 11.Engine oil level check window (page 7-10) 4.

  • Page 16: Right View

    DESCRIPTION EAU10421 Right view 10 9 8 1. Tail/brake light (page 7-32) 9. Rear brake light switch (page 7-19) 2. Rear brake fluid reservoir (page 7-20) 10.Engine oil filter cartridge (page 7-10) 3. Owner’s tool kit (page 7-2) 11.Coolant reservoir (page 7-13) 4.

  • Page 17: Controls And Instruments

    DESCRIPTION EAU10431 Controls and instruments 1. Clutch lever (page 4-11) 2. Left handlebar switches (page 4-9) 3. Multi-function meter unit (page 4-6) 4. Main switch/steering lock (page 4-2) 5. Right handlebar switches (page 4-9) 6. Throttle grip (page 7-15) 7. Brake lever (page 4-12)

  • Page 18: Instrument And Control Functions

     Do not expose any key to exces- cess, take the vehicle along with all three keys to a Yamaha dealer to have sively high temperatures.  Do not place any key close to them re-registered. Do not use the key with the red bow for driving.

  • Page 19: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS  Keep other immobilizer system EAU10473 EAU38531 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate light and auxiliary light come on, and the engine can be start- ed.
  • Page 20 INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU10685 ECA11021 LOCK NOTICE The steering is locked, and all electrical Do not use the parking position for systems are off. The key can be re- an extended length of time, other- moved.

  • Page 21: Indicator Lights And Warning Lights

    2.5 seconds. If this occurs, 4. High beam indicator light “ ” to “ON”. The warning light should have a Yamaha dealer check the 5. Turn signal indicator light “ ” come on for a few seconds, and then vehicle.
  • Page 22 If this occurs, face and positioned upright, oth- light can be checked by turning the key have a Yamaha dealer check the self- erwise the fuel level warning light to “ON”. The warning light should diagnosis system. (See page 4-8 for an...

  • Page 23: Multi-Function Meter Unit

    “ON”, WARNING or if the indicator light remains on, have Be sure to stop the vehicle before a Yamaha dealer check the electrical making any setting changes to the circuit. multi-function meter unit. Changing...
  • Page 24 INSTRUMENT AND CONTROL FUNCTIONS  Push the “RESET” switch for less Speedometer Odometer, tripmeters, fuel reserve tripmeter and clock than one second to display the clock for five seconds, regardless of the currently selected display mode. If the fuel level warning light comes on (see page 4-4), the display will auto- matically change to the fuel reserve tripmeter mode “Trip F”...
  • Page 25 5 km (3 mi). utes. code number, and then have a 6. Push the “RESET” switch and Yamaha dealer check the vehicle. To set the clock then release it to start the clock. The self-diagnosis device also detects...

  • Page 26: Handlebar Switches

    1. Turn the key to “OFF”. key and both standard keys to a 2. Push and hold the “ ” side of the Yamaha dealer and have the stan- “SELECT” switch. dard keys re-registered. 3. Turn the key to “ON”, and then re- lease the “SELECT”...
  • Page 27 INSTRUMENT AND CONTROL FUNCTIONS Right ter position. To cancel the turn signal EAU12735 Hazard switch “ ” lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all EAU12501...

  • Page 28: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU42536 EAU12821 EAU12882 “RESET” switch Clutch lever Shift pedal This switch is used to reset the tripme- ters, to set the clock and to set the brightness control mode of the multi- function meter unit. See “Multi-function meter unit” on page 4-6 for detailed information.

  • Page 29: Brake Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12892 EAU12944 EAU13075 Brake lever Brake pedal Fuel tank cap 1. Brake lever 1. Brake pedal 1. Fuel tank cap lock cover 2. Unlock. The brake lever is located on the right The brake pedal is located on the right side of the handlebar.

  • Page 30: Fuel

    INSTRUMENT AND CONTROL FUNCTIONS EAU13222 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 WARNING not properly closed and locked.

  • Page 31: Fuel Tank Breather Hose And Overflow Hose

    Your Yamaha engine has been de- signed to use regular unleaded gaso- line with a research octane number of 91 or higher. If knocking (or pinging)

  • Page 32: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS EAU13434 ECA10702 EAU42753 Catalytic converter Rider seat NOTICE This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. To remove the rider seat of leaded gasoline will cause unre- 1.

  • Page 33: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS To release the helmet from the hel- EAU14325 Helmet holder met holder Remove the rider seat, remove the hel- met from the helmet holder, and then install the seat. 1. Projection 2. Seat holder 1. Helmet holder 2.

  • Page 34: Adjusting The Shock Absorber Assembly

     Do not tamper with or attempt It is recommended to have a Yamaha to open the cylinder assembly. dealer adjust the spring preload.  Do not subject the shock ab- 1.

  • Page 35: Sidestand

    EAU15306 EAU44893 Sidestand Ignition circuit cut-off system Yamaha dealer repair it if it does not The sidestand is located on the left The ignition circuit cut-off system function properly. side of the frame. Raise the sidestand...
  • Page 36 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 37: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-13 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 38 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-15, 7-23 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-23 •...
  • Page 39 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE • Check operation of ignition circuit cut-off system. 4-18 Sidestand switch • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 40: Operation And Important Riding Points

     a lean angle sensor to stop the en-  The transmission is in the neutral understand, ask your Yamaha dealer. gine in case of a turnover. In this EWA10272 position.

  • Page 41: Shifting

    The neutral indi- quate lubrication may damage cator light should come on. If not, the transmission. 1. Shift pedal ask a Yamaha dealer to check the  Always use the clutch while 2. Neutral position electrical circuit. changing gears to avoid dam- Shifting gears lets you control the 3.

  • Page 42: Tips For Reducing Fuel Consumption

    Since the engine is brand new, do not gine speeds during acceleration. immediately have a Yamaha dealer  Do not rev the engine while shift- put an excessive load on it for the first check the vehicle.

  • Page 43: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17214 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10312 WARNING  Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 44: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 45: Owner's Tool Kits

    Owner’s tool kits If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you. 1. Owner’s tool kit The owner’s tool kit is located under the rider seat. (See page 4-15.)

  • Page 46: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills.

  • Page 47: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770K General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ Air filter element •...
  • Page 48 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for exces- √ √...
  • Page 49 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and for oil leak- √...
  • Page 50 PERIODIC MAINTENANCE AND ADJUSTMENT EAU18681  Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...

  • Page 51: Removing And Installing The Panel

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18752 EAU42433 Removing and installing the Checking the spark plugs panel The spark plugs are important engine components, which are easy to check. The panel shown needs to be removed Since heat and deposits will cause any to perform some of the maintenance spark plug to slowly erode, the spark jobs described in this chapter.
  • Page 52 In- was handed out separately at the To install a spark plug stead, have a Yamaha dealer check purchase of the vehicle. 1. Clean the surface of the spark the vehicle.

  • Page 53: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU4259A Engine oil and oil filter car- If a torque wrench is not available tridge when installing a spark plug, a good The engine oil level should be checked estimate of the correct torque is 1/4– before each ride.
  • Page 54 Make sure that the O-ring is properly An oil filter wrench is available at a seated. 1. Engine oil drain bolt Yamaha dealer. 2. Gasket 7. Install the new oil filter cartridge 6. Apply a thin coat of clean engine...
  • Page 55 8. Install the engine oil drain bolt and  In order to prevent clutch slip- off and have a Yamaha dealer check its new gasket, and then tighten page (since the engine oil also the vehicle.

  • Page 56: Coolant

    If water has been specified in the periodic maintenance added to the coolant, have a and lubrication chart. Yamaha dealer check the anti- freeze content of the coolant as EAU42635 soon as possible, otherwise the To check the coolant level effectiveness of the coolant will 1.

  • Page 57: Replacing The Air Filter Element

    1. Air filter case cover tenance and lubrication chart. Have a 4. Install the air filter case cover by 2. Bolt Yamaha dealer change the coolant. installing the bolts. 2. Pull the air filter element out. WARNING! Never attempt to remove the radiator cap when the engine is hot.

  • Page 58: Checking The Throttle Grip Free Play

    Therefore, it must be adjusted by a Yamaha dealer is essential to maintain the tires in good at the intervals specified in the periodic condition at all times and replace them maintenance and lubrication chart.
  • Page 59 * Total weight of rider, passenger, car- or glass fragments in it, or if the side- surface must first be “broken go and accessories wall is cracked, have a Yamaha dealer in” for it to develop its optimal replace the tire immediately. characteristics.

  • Page 60: Cast Wheels

    If any damage is found, have clutch lever. could lead to an accident. a Yamaha dealer replace the 2. Loosen the locknut. After extensive tests, only the tires list- wheel. Do not attempt even the 3.

  • Page 61: Checking The Brake Lever Free Play

    If there is free play, If the specified clutch lever free play 7. Tighten the locknut at the clutch have a Yamaha dealer inspect the could be obtained as described above, cable, and then slide the rubber brake system.

  • Page 62: Brake Light Switches

    1. Brake pad wear indicator groove adjusted by a Yamaha dealer. Each front brake pad is provided with Turn the rear brake light switch adjust- wear indicator grooves, which allow...

  • Page 63: Checking The Brake Fluid Level

    Rear brake EAU22582 Checking the brake fluid level peared, have a Yamaha dealer replace Before riding, check that the brake fluid the brake pads as a set. is above the minimum level mark. Check the brake fluid level with the top...

  • Page 64: Changing The Brake Fluid

    EAU22733 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the further riding. may deteriorate, causing leak- brake fluid at the intervals specified in age.

  • Page 65: Drive Belt Slack

    EAU23041 Drive belt slack with a force of 45 N (4.5 kgf, 10 lbf) have a Yamaha dealer adjust it. The drive belt slack should be checked applied to the belt with a belt ten- and adjusted at the intervals specified sion gauge as shown.

  • Page 66: Checking And Lubricating The Cables

    Yamaha dealer at the intervals bricated if necessary. cated if necessary. If a cable is specified in the periodic maintenance...

  • Page 67: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23144 Recommended lubricant: Recommended lubricants: Checking and lubricating the Lithium-soap-based grease Brake lever: brake and clutch levers Silicone grease The operation of the brake and clutch Clutch lever: Lithium-soap-based grease levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 68: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- be checked before each ride, and the sion must be lubricated by a Yamaha ed by a Yamaha dealer at the intervals sidestand pivot and metal-to-metal dealer at the intervals specified in the specified in the periodic maintenance...

  • Page 69: Checking The Front Fork

    WARNING! To avoid injury, of it falling over. have a Yamaha dealer check or re- [EWA10752] securely support the vehicle so 2. Hold the lower ends of the front pair it.

  • Page 70: Checking The Wheel Bearings

    (See page 4-15.) hub or if the wheel does not turn This model is equipped with a VRLA smoothly, have a Yamaha dealer (Valve Regulated Lead Acid) battery. check the wheel bearings. There is no need to check the electro- lyte or to add distilled water.
  • Page 71 To charge the battery of water. charge it if necessary. Have a Yamaha dealer charge the bat- • INTERNAL: Drink large quan- 3. Fully charge the battery before in- tery as soon as possible if it seems to stallation.

  • Page 72: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU47135 Replacing the fuses The main fuse, the fuel injection sys- tem fuse, and the fuse box, which con- tains the fuses for the individual circuits, are located under the rider seat. (See page 4-15.) 1. Signaling system fuse 1.

  • Page 73: Replacing The Headlight Bulb

    4. If the fuse immediately blows cohol or thinner. again, have a Yamaha dealer  Headlight lens check the electrical system. Do not affix any type of tinted film or stickers to the headlight lens.
  • Page 74 PERIODIC MAINTENANCE AND ADJUSTMENT 1. Bolt 1. Headlight bulb holder 9. Have a Yamaha dealer adjust the 2. Headlight bulb headlight beam if necessary. 3. Disconnect the headlight coupler, 5. Place a new headlight bulb into and then remove the headlight position, and then secure it with bulb cover.

  • Page 75: Replacing The Auxiliary Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU42874 EAU24285 Replacing the auxiliary light Replacing a turn signal light bulb bulb or the tail/brake light bulb If the auxiliary light bulb burns out, re- 1. Remove the lens by removing the place it as follows. screws.

  • Page 76: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT 2. Remove the burnt-out bulb by 3. Remove the license plate light EAU42486 Replacing the license plate pushing it in and turning it coun- bulb socket (together with the light bulb terclockwise. bulb) by turning it counterclock- 1.

  • Page 77: Supporting The Motorcycle

    PERIODIC MAINTENANCE AND ADJUSTMENT 6. Install the socket (together with a jack either under each side of the EAU24351 Supporting the motorcycle the bulb) by pushing it in and turn- frame in front of the rear wheel or under Since this model is not equipped with a ing it clockwise until it stops.

  • Page 78: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 79: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 80 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 81: Motorcycle Care And Storage

    Some models are equipped with matte colored finished parts. Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE used. A rusty exhaust pipe may go un-...
  • Page 82 MOTORCYCLE CARE AND STORAGE off any detergent residue using shield. Test the product on a plenty of water, as it is harmful small hidden part of the wind- Salt sprayed on roads in the winter to plastic parts. shield to make sure that it does may remain well into spring.

  • Page 83: Storage

    Contaminants on the brakes or tires of the presence of ammonia) can cause loss of control.  Consult a Yamaha dealer for ad- and areas where strong chemi-  Make sure that there is no oil or vice on what products to use.
  • Page 84 MOTORCYCLE CARE AND STORAGE 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.

  • Page 85: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Recommended brand: Recommended fuel: 2490 mm (98.0 in) YAMALUBE Regular unleaded gasoline (Gasohol (E10) Overall width: Type: acceptable) 985 mm (38.8 in) SAE 10W-30, 10W-40, 10W-50, 15W-40, Fuel tank capacity: Overall height: 20W-40 or 20W-50 19.0 L (5.02 US gal, 4.18 Imp.gal) 1150 mm (45.3 in) Fuel reserve amount:...
  • Page 86 SPECIFICATIONS 2nd: Loading: Specified brake fluid: 1.778 (32/18) DOT 4 Maximum load: 3rd: Rear brake: 209 kg (461 lb) 1.381 (29/21) (Total weight of rider, passenger, cargo Type: 4th: and accessories) Single disc brake 1.115 (29/26) Tire air pressure (measured on cold Operation: 5th: Right foot operation...
  • Page 87 SPECIFICATIONS Headlight: Fuses: Bulb type: Main fuse: Halogen bulb 50.0 A Bulb voltage, wattage × quantity: Headlight fuse: 20.0 A Headlight: 12 V, 60.0 W/55.0 W × 1 Signaling system fuse: 10.0 A Tail/brake light: 12 V, 5.0 W/21.0 W × 1 Ignition fuse: 15.0 A Front turn signal light:...

  • Page 88: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number The vehicle identification number is The engine serial number is stamped stamped into the steering head pipe.

  • Page 89: Motorcycle Noise Regulation (For Australia)

    This information TROL SYSTEM PROHIBITED: will be needed when ordering spare Owners are warned that the law may parts from a Yamaha dealer. prohibit: a. The removal or rendering inopera- tive by any person other than for...

  • Page 90: Index

    INDEX Front fork, checking ......7-26 Noise regulation (for Australia) ....10-2 Fuel............4-13 Air filter element, replacing ....7-14 Fuel consumption, tips for reducing ..6-3 Auxiliary light bulb, replacing....7-32 Oil level warning light ......4-4 Fuel level warning light ......4-4 Fuel tank breather hose and overflow Battery ..........7-27 Panel, removing and installing ....7-8...
  • Page 91 INDEX Troubleshooting........7-35 Troubleshooting charts......7-36 Turn signal indicator light ....... 4-4 Turn signal light bulb or tail/brake light bulb, replacing ........7-32 Turn signal switch......... 4-10 Valve clearance ........7-15 Vehicle identification number ....10-1 Wheel bearings, checking ....7-27 Wheels..........
  • Page 94 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2014.07-0.3×1 CR...
