Toyotomi hydria+ THMU408/1R32 Owner's Manual

Air-to-water heat pump
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Original Instructions
Air Conditioners
Air-to-water Heat Pump
THMU408/1R32
THMU410/1R32
THMU412/1R32
THMU414/1R32
THMU416/1R32
THMU410/3R32
THMU412/3R32
THMU414/3R32
THMU416/3R32
Thank you for choosing commercial air conditioners. Please
read this Owner's Manual carefully before operation and retain
it for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Toyotomi hydria+ THMU408/1R32

Summary of Contents for Toyotomi hydria+ THMU408/1R32

  • Page 1 Original Instructions Air Conditioners Air-to-water Heat Pump THMU408/1R32 THMU410/1R32 THMU412/1R32 THMU414/1R32 THMU416/1R32 THMU410/3R32 THMU412/3R32 THMU414/3R32 THMU416/3R32 Thank you for choosing commercial air conditioners. Please read this Owner’s Manual carefully before operation and retain it for future reference.
  • Page 2 To Users Thank you for selecting Gree’s product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our (1) This equipment should be installed, operated or maintained by the qualified servicemen who have had should be followed strictly.

  • Page 3: Table Of Contents

    Contents Safety Notices (Please be sure to abide ) ..............5 1. Diagram of the Operating Principle ............... 14 2. Operating Principle of the Unit ................15 3. Nomenclature......................16 4. Installation Example ..................... 18 5. Main Components ....................20 6.
  • Page 4 18.2 Test run .........................58 19. Daily Operation and Maintenance ............... 58 19.1 Recovery ........................59 19.2 Decommissioning ......................60 19.3 Notice before seasonal use ..................60 19.4 Safety considerations ....................61 19.5 Maintenance of the water tank ..................62...

  • Page 5: Safety Notices (Please Be Sure To Abide )

    hydria + Air-to-water Heat Pump Safety Notices (Please be sure to abide ) WARNING: If not abide strictly, it may cause severe damage to the unit or the people. NOTE people. This sign indicates that the operation must be prohibited. Improper operation may cause severe damage or death to people This sign indicates that the items must be observed.
  • Page 6 hydria + Air-to-water Heat Pump WARNING Once abnormality Before likeburning smell occurs, wet hand. installation,please see if the voltage of local supply immediately and place accords with then contact with service that on nameplate center. of unit and capacity of power supply, power cord or socket is suitable for input power of this unit.
  • Page 7 hydria + Air-to-water Heat Pump Before cleaning please cut The power supply must adopt special circuit with power cord socket leakage switch and enough without prior consent. capacity. Wiring working must be done by professionals. Ensure good earthing and mode of unit. Otherwise, it may cause electric shock or damage.
  • Page 8 hydria + Air-to-water Heat Pump Never block the air inlet and unit or place anything on it. outlet of unit. spray, gas holder and so on away from the unit above 1m . There is the danger of fall of things or people.
  • Page 9 hydria + Air-to-water Heat Pump WARNING recommended by the manufacturer. Should repair be necessary, contact your nearest dangerous. The appliance shall be stored in a room without continuous operating ignition Appliance shall be installed, operated and stored in a room with a floor area larger than Xm .(Please refer to table “a”...
  • Page 10 hydria + Air-to-water Heat Pump NOTE the system. The used refrigerant is the fluoride R32, which is specially cleaned.The refrigerant is flammable and inodorous. Furthermore, it can leads to explosion under certain conditions. But the flammability of the refrigerant is very low. It can be ignited Compared to common refrigerants, R32 is a nonpolluting refrigerant with no harm to very good thermodynamic features which lead to a really high energy efficiency.
  • Page 11 hydria + Air-to-water Heat Pump Maximum and minimum water operating temperatures Maximum Minimum water operating Item water operating temperatures temperatures Cooling 5°C 25°C Heating 20°C 65°C Water heating 40°C 80°C Maximum and minimum water operating pressures Minimum water operating Maximum water Item pressures operating pressures...
  • Page 12 hydria + Air-to-water Heat Pump NOTE If any hot work is to be conducted on the refrigeration equipment or any associated powder or CO and to the correct specification. At all times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt consult the manufacturer’s technical department for assistance.
  • Page 13 hydria + Air-to-water Heat Pump from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most Particular attention shall be paid to the following to ensure that by working on electrical components, the casing is not altered in such a way that the level of protection is affected.

  • Page 14: Diagram Of The Operating Principle

    hydria + Air-to-water Heat Pump 1. Diagram of the Operating Principle please contact the manufacturer.

  • Page 15: Operating Principle Of The Unit

    hydria + Air-to-water Heat Pump 2. Operating Principle of the Unit (10) (11) (12) (13) (14) (15) Other thermal Cooling: in cooling mode, the refrigerant is condensed in the outdoor unit and evaporated in the indoor unit. Via the heat exchange with water in the indoor unit, the temperature of water decreases and it releases heat while the user’s requirement.

  • Page 16: Nomenclature

    3. Nomenclature Options TOYOTOMI T = TOYOTOMI Heat Pump Water Heater H = Hydria Type MU = Monoblock Unit / S = Split...
  • Page 17 hydria + Air-to-water Heat Pump Model Line-Up Model Heating1, kW Power Input, kW COP, W/W Power supply THMU408/1R32 8.20 1.54 5.32 THMU410/1R32 10.20 2.02 5.05 THMU412/1R32 12.0 2.43 4.93 THMU414/1R32 14.2 2.99 4.75 THMU416/1R32 15.7 3.45 4.55 THMU410/3R32 10.20 2.06 4.95 THMU412/3R32 12.0...

  • Page 18: Installation Example

    hydria + Air-to-water Heat Pump Mode Heat Source Side Temperature (°C) User Side Temperature (°C) Heating -25~35 20~65 Cooling -15~48 5~25 Water Heating -25~45 40~80 4. Installation Example Notes the collector.
  • Page 19 hydria + Air-to-water Heat Pump Sanitary water tank Booster heater Notes (b) Sanitary should be equipped with internal electric heater to to secure enough heat energy in the very cold days. Note...

  • Page 20: Main Components

    hydria + Air-to-water Heat Pump 5. Main Components (1) For models below THMU408/1R32 THMU410/3R32 THMU410/1R32 THMU412/3R32 THMU412/1R32 THMU414/3R32 THMU414/1R32 THMU416/3R32 THMU416/1R32 6. Installation Guideline of Monobloc Unit 6.1 Instruction to installation (1) Installation of the unit must be in accordance with national and local safety codes. installation.

  • Page 21: Installation Of Monobloc Unit

    hydria + Air-to-water Heat Pump 6.2 Installation of monobloc unit 6.2.1 Selection of installation location of monobloc unit (2) Avoid placing the monobloc unit under window or between two constructions, hence to prevent normal operating noise from entering the room. (4) Install at a well-ventilated place, so that the machine can abs fog and polluted air.
  • Page 22 hydria + Air-to-water Heat Pump distance between the inlet side and the nearest barrier is allowed to be no less than 300mm. 6.2.4 Precautions on installation of monobloc unit (1) When moving outdoor unit, it is necessary to adopt 2 pieces of long enough rope to hand the unit from 4 directions.
  • Page 23 hydria + Air-to-water Heat Pump (3) Maintenance notes Check whether the maintenance area or the room area meet the requirement. - It’s only allowed to be operated in the rooms that meet the requirement. Check whether the maintenance area is well-ventilated. - The continuous ventilation status should be kept during the operation process.

  • Page 24: Installation Of Hydraulic Unit

    hydria + Air-to-water Heat Pump 7. Installation of Hydraulic Unit 7.1 Available external static pressure of outlet (1) THMU408/1R32, THMU410/1R32, THMU412/1R32, THMU414/1R32, THMU416/1R32, THMU410/3R32, THMU412/3R32, THMU414/3R32, THMU416/3R32 Notes (a) See the curve above for the maximum external static pressure. The water pump is of variable frequency. And during operation, the water pump will adjust its output based on the actual load.

  • Page 25: Ambient Temperature And Leaving Water Temperature Upper Limit

    hydria + Air-to-water Heat Pump 7.2 Ambient temperature and leaving water temperature upper limit 7.3 Water volume and expansion vessel pressure 8/10/12/14/16kW Notes (b) Total water volume of 66 liter for 8/10/12/14/16kW unit. If total water is changed because of installation condition, the pre-pressure should be adjusted to secure proper operation.

  • Page 26: Selection Of Expansion Vessel

    hydria + Air-to-water Heat Pump For 8/10/12/14/16 units Water volume Installation height <66L >66L 1. Pre-set pressure needs to be adjusted according to the above formula. <12 m Adjustment is not necessary 2. Check if the water volume is lower than the maximum water volume.

  • Page 27: Remote Air Temperature Sensor

    hydria + Air-to-water Heat Pump Temperature Expansion factor e 0.0145 0.0171 0.0198 0.0227 0.0258 0.029 0.0324 0.0359 0.0396 0.0434 8. Remote Air Temperature Sensor Front side Back side Remote Air Temperature Sensor 1.5 Meters Remote Air Environmen t Temp sensor Electric box...

  • Page 28: Thermostat

    hydria + Air-to-water Heat Pump Notes (f) After the remote air temperature sensor is installed, it should be set to “With” through the wired controller so as to set the remote air temperature to the control point. 9. Thermostat Installation of the thermostat is very similar to that of the remote air temperature sensor. 12 13 14 15 Thermostat How to Wire Thermostat...

  • Page 29: Way Valve

    hydria + Air-to-water Heat Pump 2-Way 2-Way 2-Way Valve 1 Valve 1 Valve 1 WARNING • Normal Open type should be connected to wire (OFF) and wire (N) for valve closing in cooling mode. • Normal Closed type should be connected to wire (ON) and wire (N) for valve closing in cooling mode. 11.
  • Page 30 hydria + Air-to-water Heat Pump Other Thermal Optional Water Temp. Sensor 3-Way Valve 2 2-Way Valve 1 Mixing Floor Valve Temp. Water Pump Tank Temp. of Heat pump system Water Tank EH Water Tank Step 2. Electric wiring work Other thermal L and N connect to XT3~1,2. Optional water temperature sensor connecet to AP1 CN16.

  • Page 31: Optional Electric Heater

    hydria + Air-to-water Heat Pump 13. Optional Electric Heater Optional electric heater is allowed for the equipment and controlled in such a way when outdoor temperature is lower than the set point for startup of the optional electric heater. Step 1. Optional electric heater installation Optional electric heater should be installed with monobloc unit in series.Moreover,an accessory called optional water temperature sensor(5 meter length) shall be installed at the same time.The optional electric heater could be 1group or 2 group, and only works fo space heating.

  • Page 32: Gate-Controller

    hydria + Air-to-water Heat Pump 14. Gate-controller 15. Charging and Discharging of Refrigerant The unit has been charged with refrigerant before delivery. Overcharging or undercharging will cause the compressor to run improperly or be damaged. When refrigerant is required to be charged or discharged for installation, maintenance and other reasons, please follow steps below and nominal charged volume on the nameplate.

  • Page 33: Installation Of Insulated Water Tank

    hydria + Air-to-water Heat Pump Leak Detection Methods： (1) The following leak detection methods are deemed acceptable for systems containing flammable refrigerants. (2) Electronic leak detector shall be used to detect flammable refrigerant, but the sensitivity may not be (3) Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant used. (4) Leak detection equipment shall be set at a percentage of the LFL of the refrigerant and shall be calibrated shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work.

  • Page 34: Outline Dimension And Parameter Of Water Tank

    hydria + Air-to-water Heat Pump Safety check valve Tap water Note (1) For safe use of water, water outlet/inlet of water tank must connect with a certain length of PPR pipe ,L (2) The water may drip from the discharge pipe of the pressure-relief device and that this pipe must be left open to the atmosphere.

  • Page 35: Connection Of Waterway System

    hydria + Air-to-water Heat Pump Model Litre 300L 300L H(mm) 1585 1585 A(mm) B(mm) C(mm) E(mm) F(mm) G(mm) I(mm) J(mm) K(mm) L(mm) Model Net weight Gross weight Joints Dimension Joint pipe thread Hot water outlet of water tank Circulating water inlet/outlet of water tank Cooling water inlet of water tank Pipe joint 16.3 Connection of waterway system...
  • Page 36 hydria + Air-to-water Heat Pump Description Joint pipe thread Circulating water inlet/outlet of main unit Cooling water inlet of water tank Circulating water inlet/outlet of water tank Hot water outlet of water tank Code Name QTY. Function 01842800004P01 Retaining Plate Sub-Assy Fix the water tank to the wall 70210087 Bolt M6X16...

  • Page 37: Requirements On Water Quality

    hydria + Air-to-water Heat Pump 16.4 Requirements on water quality Paramete Parametric value Unit pH( 25°C) 6.8~8.0 Cloudy ＜ 1 Chloride ＜ 50 mg/L Fluoride ＜ 1 mg/L Iron ＜ 0.3 mg/L Sulphate ＜ 50 mg/L ＜ 30 mg/L Hardness(count CaCO ＜...
  • Page 38 hydria + Air-to-water Heat Pump wing list are recommended. Minimum Minimum Air Break Minimum Section Minimum Section Power Switch Section Area of Section Area of Break Supply (Electric Area of Earth Wire Area of Power Wire Model Switch heater) Earth Wire (Electric Power Wire (Electric...

  • Page 39: Wring Diagram

    hydria + Air-to-water Heat Pump 17. Wring Diagram 17.1 Control board (1) For models below THMU408/1R32 THMU410/3R32 THMU410/1R32 THMU412/3R32 THMU412/1R32 THMU414/3R32 THMU414/1R32 THMU416/3R32 THMU416/1R32 X24 X23 X22 X21 X20 X34 X33 X32 X31 X30 X29 X28 X27 CN20 AC-L CN21 CN22 CN23 CN24...
  • Page 40 hydria + Air-to-water Heat Pump Silk Screen Introduction Electric three-way valve 2 open Electric three-way valve 2 closed CN18 Build-in water pump signal(PWM) CN19 CN15 20K temperature sensor (inlet water) CN15 20K temperature sensor (outlet water) CN15 20K temperature sensor (refrigerant liquid line) CN16 20K temperature sensor (refrigerant vapor line) CN16...
  • Page 41 hydria + Air-to-water Heat Pump (2) For models below THMU408/1R32 THMU410/3R32 THMU410/1R32 THMU412/3R32 THMU412/1R32 THMU414/3R32 THMU414/1R32 THMU416/3R32 THMU416/1R32 Silk Screen Introduction AC-L Live wire input of power supply Neutral wire input of power supply PWR1 310V Supply 310V DC power to the drive Fuse 4-way valve VA-1...
  • Page 42 hydria + Air-to-water Heat Pump Silk Screen Introduction 1-pin:12V, 2-pin:B, 3-pin: A, 4-pin: ground, To the wired controller, communication cable; 1-pin:+12V, 2-pin:B; 3-pin:A, 4-pin: ground COM_ESPE1 1-pin:+3.3V, 2-pin:TXD, 3-pin:RXD, 4-pin:ground COM_ESPE2 1-pin:+3.3V, 2-pin:TXD, 3-pin:RXD, 4-pin:ground 1-pin: ground, 2-pin:+18V, 3-pin:+15V (3) For models below THMU408/1R32 THMU412/1R32 THMU410/1R32...
  • Page 43 hydria + Air-to-water Heat Pump (4) For models below THMU410/3R32 THMU412/3R32 THMU414/3R32 THMU416/3R32 COMM COMM1 Silk Screen Introduction Connector to the compressor phase-W Connector to the compressor phase-U Connector to the compressor phase-V Connector to reactor (input) Connector to reactor (input) COMM1 Reserved COMM...
  • Page 44 hydria + Air-to-water Heat Pump (5) For models below THMU408/1R32 THMU412/1R32 THMU410/1R32 THMU414/1R32 EE 1 N-OUT L-OUT DC -BUS AC -L Silk Screen Introduction AC-L Live line input of the main board Neutral line of the power supply for the main board L-OUT N-OUT N-OUT1...

  • Page 45: Electric Wiring

    hydria + Air-to-water Heat Pump 17.2 Electric wiring 17.2.1 Wiring principle Refer to Section 16.5. 17.2.2 Electric wiring The wiring diagram stuck to the unit always prevails. THMU408/1R32, THMU410/1R32...
  • Page 46 hydria + Air-to-water Heat Pump THMU412/1R32, THMU414/1R32, THMU416/1R32...
  • Page 47 hydria + Air-to-water Heat Pump (3) THMU408/1R32, THMU410/1R32...
  • Page 48 hydria + Air-to-water Heat Pump (4) THMU412/1R32, THMU414/1R32, THMU416/1R32...
  • Page 49 hydria + Air-to-water Heat Pump (5) THMU410/3R32...
  • Page 50 hydria + Air-to-water Heat Pump (6) THMU412/3R32, THMU414/3R32, THMU416/3R32...
  • Page 51 hydria + Air-to-water Heat Pump (7) THMU410/3R32...
  • Page 52 hydria + Air-to-water Heat Pump (8) THMU412/3R32, THMU414/3R32, THMU416/3R32...
  • Page 53 hydria + Air-to-water Heat Pump (9) Wiring of the water tank for the one-phase units (10) Wiring of the water tank for the three-phase units...
  • Page 54 hydria + Air-to-water Heat Pump 17.2.3 Terminal board (1) THMU408/1R32, THMU410/1R32, THMU412/1R32, THMU414/1R32, THMU416/1R32...
  • Page 55 hydria + Air-to-water Heat Pump (2) THMU410/3R32, THMU412/3R32, THMU414/3R32, THMU416/3R32...
  • Page 56 hydria + Air-to-water Heat Pump (3) THMU410/3R32, THMU412/3R32, THMU414/3R32, THMU416/3R32...

  • Page 57: Commissioning

    hydria + Air-to-water Heat Pump 18. Commissioning 18.1 Check before startup For safety of users and unit, the unit must be started up for check before debugging. The procedures are as refused. Pre-check Check the accessories attached with the unit for quantity, package and so on. Make sure there is drawings in terms of electricity, control, design of pipeline and so on.

  • Page 58: Test Run

    hydria + Air-to-water Heat Pump 18.2 Test run solve problems until the test run is satisfactory. All inspections must meet the requirements before performing the Start up the pretest procedure casualty. Ensure that the compressor of the unit is preheated for 8h. may cause damage to the compressor when starting up the unit.

  • Page 59: Recovery

    hydria + Air-to-water Heat Pump of the unit for protection. water system periodically and frequently check water replenishing device. In order to avoid frost crack of the unit, water in the unit and pipeline system not used for a long period should be drained.

  • Page 60: Decommissioning

    hydria + Air-to-water Heat Pump All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be complete with pressure relief valve and associated shut-off valves in good working order. Empty recovery cylinders are evacuated and, if possible, cooled before recovery occurs.

  • Page 61: Safety Considerations

    hydria + Air-to-water Heat Pump Concentration Freezing Temp Concentration Freezing Temp Concentration Freezing Temp °C °C °C 19.8 23.6 38.8 12.2 27.4 42.6 31.2 46.4 19.4 Safety considerations (1) Pressure relief of the water tank The water may drip from the discharge pipe of the pressure-relief device and that this pipe must be left open to the atmosphere.

  • Page 62: Maintenance Of The Water Tank

    hydria + Air-to-water Heat Pump ① ② ③ ① Safety valve ② Regulator ③ Filter Installation Mode 3 of the Tap Water Safety Valve (Inlet Water Pressure>0.5MPa) A pressure maintaining valve is required in the installation mode 3 to make sure the water tank pressure keep not delivered with the main unit and should be prepared by the client.
  • Page 63 hydria + Air-to-water Heat Pump (6) Close the cap, and replenish water by following water replenishment operations. Note: the Mg-Stick must be replaced by professional maintenance personnel. Please directly contact your local...
  • Page 65 .........67 ................76 ................77 ......................78 ..................80 ....................82 ............83 ....................83 ...................83 ............. 86 ..............86 ....87 ...............87 ......87 ..................88 ........... 89 ......................90 ..................90 ..................91 ................92 ..............93 .................... 94 ................ 94 ............96 .....................96 ............
  • Page 66 ...............121 ........................123 ......................123 ................1 24 .......................125 19.5 ................125...
  • Page 67 hydria + Αντλία Θερμότητας Αέρα-Νερού R32:675...
  • Page 68 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 69 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 70 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 71 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 72 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 73 hydria + Αντλία Θερμότητας Αέρα-Νερού 5°C 25°C 20°C 65°C 40°C 80°C 0.05MPa 0.25MPa 0.05MPa 0.25MPa...
  • Page 74 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 75 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 76 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 77 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 78 hydria + Αντλία Θερμότητας Αέρα-Νερού H = Hydria MU =...
  • Page 79 hydria + Αντλία Θερμότητας Αέρα-Νερού odel Line-Up , kW COP W/W THMU408/1R32 8.20 1.54 5.32 THMU410/1R32 10.20 2.02 5.05 THMU412/1R32 12.0 2.43 4.93 THMU414/1R32 14.2 2.99 4.75 THMU416/1R32 15.7 3.45 4.55 THMU410/3R32 10.20 2.06 4.95 THMU412/3R32 12.0 2.49 4.81 THMU414/3R32 14.2 3.09 4.60...
  • Page 80 hydria + Αντλία Θερμότητας Αέρα-Νερού -25~35 20~65 -15~48 5~25 -25~45 40~80...
  • Page 81 hydria + Αντλία Θερμότητας Αέρα-Νερού Under-floor coil Sanitary water tank...
  • Page 82 hydria + Αντλία Θερμότητας Αέρα-Νερού THMU408/1R32 THMU410/3R32 THMU410/1R32 THMU412/3R32 THMU412/1R32 THMU414/3R32 THMU414/1R32 THMU416/3R32 THMU416/1R32...
  • Page 83 hydria + Αντλία Θερμότητας Αέρα-Νερού THMU408/1R32 THMU410/3R32 THMU410/1R32 THMU412/3R32 THMU412/1R32 THMU414/3R32 THMU414/1R32 THMU416/3R32 THMU416/1R32 Unit: inch...
  • Page 84 hydria + Αντλία Θερμότητας Αέρα-Νερού Outlet > 2000 Outlet Water return Water supply...
  • Page 85 hydria + Αντλία Θερμότητας Αέρα-Νερού 14.5 16.8 19.3 24.8 27.8 34.3 37.8 41.5 45.4 49.4 53.6 11.2 12.4 13.6 16.3 17.8 19.3...
  • Page 86 hydria + Αντλία Θερμότητας Αέρα-Νερού (1) THMU408/1R32 HMU410/1R32 HMU412/1R32 HMU414/1R32 HMU416/1R32 HMU410/3R32 THMU412/3R32 HMU414/3R32 HMU416/3R32 Notes (a) See the curve above for the maximum external static pressure. The water pump is of variable frequency. And during operation he water pump will adjust its output based on the actual load. (2) THMU412/1R32 HMU414/1R32 HMU416/1R32...
  • Page 87 hydria + Αντλία Θερμότητας Αέρα-Νερού 8/10/12/14/16kW...
  • Page 88 hydria + Αντλία Θερμότητας Αέρα-Νερού <12 m ﹥ 12 m ºC 0.00013 0.00027 0.00177 0.00435 0.00782 0.0099 0.0121...
  • Page 89 hydria + Αντλία Θερμότητας Αέρα-Νερού Expansion factor e ºC 0.0145 0.0171 0.0198 0.0227 0.0258 0.029 0.0324 0.0359 0.0396 0.0434 Front side ack side Remote Air Temperature Sensor 1.5 Meters Remote Air Environmen t Temp sensor Electric box...
  • Page 90 hydria + Αντλία Θερμότητας Αέρα-Νερού 12 13 14 15 Thermostat • • • • • • NO 2-wire 230V 50Hz ~AC NC 2-wire 230V 50Hz ~AC...
  • Page 91 hydria + Αντλία Θερμότητας Αέρα-Νερού 2-Way 2-Way 2-Way Valve 1 Valve 1 Valve 1 • • 230V 50Hz ~AC 3-wire 3-Way Valve 2...
  • Page 92 hydria + Αντλία Θερμότητας Αέρα-Νερού • • Other Thermal Optional Water Temp. Sensor 3-Way Valve 2 2-Way Valve 1 Mixing Floor Valve Temp. Water Pump Tank Temp. of Heat pump system Water Tank EH Water Tank...
  • Page 93 hydria + Αντλία Θερμότητας Αέρα-Νερού optional water temperature senso r CN16 Other Thermal Optional Water Temp. Sensor 3-Way Valve 2 2-Way Valve 1 Mixing Floor Valve Temp. Water Pump Tank Temp. of Heat pump system Water Tank EH Water Tank...
  • Page 94 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 95 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 96 hydria + Αντλία Θερμότητας Αέρα-Νερού Wall Water Tank Fixing Strap Floor Safety check valve Tap water...
  • Page 97 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 98 hydria + Αντλία Θερμότητας Αέρα-Νερού H(mm) 1585 1585 A(mm) C(mm) E(mm) F(mm) Net weight...
  • Page 99 hydria + Αντλία Θερμότητας Αέρα-Νερού 01842800004P01 70210087 70110066 0738280101 035033000012 06332800003 75042805 030059000120 05332800002 70814016 2690280000502 0184280000502P...
  • Page 100 hydria + Αντλία Θερμότητας Αέρα-Νερού pH( 25°C) 6.8~8.0 ＜ 1 ＜ 50 ＜ 1 ＜ 0.3 ＜ 50 ＜ 30 ＜ 70 ＜ 10 ＜ 300 ＜ 0.5 ＜ 50 ＜ 3 ＜ 150 (10)
  • Page 101 hydria + Αντλία Θερμότητας Αέρα-Νερού V Ph THMU408/1R32 230VAC THMU410/1R32 THMU412/1R32 THMU414/1R32 THMU416/1R32 THMU410/3R32 400VAC THMU412/3R32 THMU414/3R32 THMU416/3R32...
  • Page 102 hydria + Αντλία Θερμότητας Αέρα-Νερού THMU408/1R32 THMU410/3R32 THMU410/1R32 THMU412/3R32 THMU412/1R32 THMU414/3R32 THMU414/1R32 THMU416/3R32 THMU416/1R32 CN20 CN21 CN22 CN23 CN24 CN26 CN25 CN10 CN16 CN15 CN19 CN18 CN3 CN4 Silk Screen Neutral wire of power supply To the ground E-heater of water tank E-heater 1 E-heater 2 Other thermal by 220VAC...
  • Page 103 hydria + Αντλία Θερμότητας Αέρα-Νερού Silk Screen Electric three-way valve 2 open Electric three-way valve 2 closed CN18 CN19 CN15 CN15 CN15 CN16 CN16 CN16 Rreserved Remote room temperature sensor Water tank temperature sensor Rreserved Rreserved Rreserved CN20 Thermostat CN21 CN22 CN23 CN24...
  • Page 104 hydria + Αντλία Θερμότητας Αέρα-Νερού THMU408/1R32 THMU410/3R32 THMU410/1R32 THMU412/3R32 THMU412/1R32 THMU414/3R32 THMU414/1R32 THMU416/3R32 THMU416/1R32 Silk Screen Neutral wire input of power supply PWR1 Fuse 4-way valve VA-1 E-heater of chassis HEAT Electric heating tape TORO 6-pin:feedback signal TORO1 6-pin: feedback signal T_SENSOR2 T_SENSOR1 H_PRESS...
  • Page 105 hydria + Αντλία Θερμότητας Αέρα-Νερού Silk Screen 1-pin:12V To the wired controller COM_ESPE1 COM_ESPE2 THMU408/1R32 THMU412/1R32 THMU410/1R32 THMU414/1R32 THMU416/1R32 COMM COMP Silk Screen To PFC inductor brown line To PFC inductor white line To PFC inductor yellow line To PFC inductor blue line COMP W-03)(variable-frequency) COMM...
  • Page 106 hydria + Αντλία Θερμότητας Αέρα-Νερού THMU410/3R32 THMU412/3R32 THMU414/3R32 THMU416/3R32 COMM COMM1 Silk Screen Connector to the compressor phase-W Connector to the compressor phase-U Connector to the compressor phase-V Connector to reactor (input) Connector to reactor (input) COMM1 Reserved COMM Communication Switch power input...
  • Page 107 hydria + Αντλία Θερμότητας Αέρα-Νερού THMU408/1R32 THMU412/1R32 THMU410/1R32 THMU414/1R32 EE 1 N-OUT Silk Screen Neutral line of the power supply for the main board N-OUT N-OUT1 Output neutral line Output live line Screw hole for grounding THMU410/3R32 THMU412/3R32 THMU414/3R32 THMU416/3R32 Silk Screen Connect to the power supply input of the drive board Neutral line for power supply to the main control board...
  • Page 108 hydria + Αντλία Θερμότητας Αέρα-Νερού (1) THMU408/1R32 HMU410/1R32...
  • Page 109 hydria + Αντλία Θερμότητας Αέρα-Νερού (2) THMU412/1R32 HMU414/1R32 HMU416/1R32...
  • Page 110 hydria + Αντλία Θερμότητας Αέρα-Νερού THMU408/1R32 HMU410/1R32...
  • Page 111 hydria + Αντλία Θερμότητας Αέρα-Νερού (4) THMU412/1R32 HMU414/1R32 HMU416/1R32...
  • Page 112 hydria + Αντλία Θερμότητας Αέρα-Νερού (5) THMU410/3R32...
  • Page 113 hydria + Αντλία Θερμότητας Αέρα-Νερού (6) THMU412/3R32 HMU414/3R32 HMU416/3R32...
  • Page 114 hydria + Αντλία Θερμότητας Αέρα-Νερού THMU410/3R32...
  • Page 115 hydria + Αντλία Θερμότητας Αέρα-Νερού (8) THMU412/3R32 HMU414/3R32 HMU416/3R32...
  • Page 116 hydria + Αντλία Θερμότητας Αέρα-Νερού (9) Wiring of the water tank for the one-phase units (10) Wiring of the water tank for the three-phase units...
  • Page 117 hydria + Αντλία Θερμότητας Αέρα-Νερού (1) THMU408/1R32 HMU410/1R32 HMU412/1R32 HMU414/1R32 HMU416/1R32...
  • Page 118 hydria + Αντλία Θερμότητας Αέρα-Νερού (2) THMU410/3R32 HMU412/3R32 HMU414/3R32 HMU416/3R32...
  • Page 119 hydria + Αντλία Θερμότητας Αέρα-Νερού (3) THMU410/3R32 HMU412/3R32 HMU414/3R32 HMU416/3R32...
  • Page 120 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 121 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 122 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 123 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 124 hydria + Αντλία Θερμότητας Αέρα-Νερού 19.8 23.6 38.8 12.2 27.4 42.6 31.2 46.4...
  • Page 125 hydria + Αντλία Θερμότητας Αέρα-Νερού ① ② ① Safety valve ② Filter ① ② ③ ① Safety valve ② Check valve ③ Filter ① ② ③ ① Safety valve ② Regulator ③ Filter...
  • Page 126 hydria + Αντλία Θερμότητας Αέρα-Νερού...
  • Page 127 Notes / Σημειώσεις...
  • Page 128 È vietato ristampare o riprodurre tutto o parte di questo manuale in qualsiasi modo senza il permesso scritto di TOYOTOMI ITALIA S.R.L. Quedan prohibidas la reimpresión y reproducción de este manual o partes del mismo sin permiso previo por escrito de TOYOTOMI EUROPE SALES SPAIN S.A. ΕΠΙΣΗΜΗ ΑΝΤΙΠΡΟΣΩΠΕΙΑ ΕΛΛΑΔΑΣ Γ.Ε.ΔΗΜΗΤΡΙΟΥ Α.Ε.Ε.
