Denso BHT-M70 Hardware User Manual

Barcode/2d code handy terminal
Hide thumbs Also See for BHT-M70:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for Denso BHT-M70

Summary of Contents for Denso BHT-M70

  • Page 2: Liability Limitations

    DENSO WAVE. The use of DENSO WAVE ’ s products in a manner for which they were not intended nor designed. The modification of DENSO WAVE ’ s products by parties other than DENSO WAVE.

  • Page 3: Customer Registration And Inquiries

    BHT-M70 Series Customer Registration and Inquiries Customer Registration To allow us to provide our customers with comprehensive service and support, we request that all customers complete a Member Registration Form. Registered members will be offered the following privileges. The latest upgrade information •...

  • Page 4: Safety Precautions

    Barcode / 2D Code Handy Terminal Safety Precautions Be sure to observe all these safety precautions. Please READ through this manual carefully. It will enable you to use the BHT and CU correctly. Always keep this manual nearby for speedy reference. Safety precautions description in this document Strict observance of these warnings and cautions is a MUST for preventing accidents that could result in bodily injury and substantial property damage.
  • Page 5 BHT-M70 Series DANGER Handling the batteries Wrong handling the batteries may result in electrical shock, overheating, smoke generation, combustion, blowout, or leakage of battery fluid. Please read the following items prior to use. • Never disassemble or modify the battery.
  • Page 6 Barcode / 2D Code Handy Terminal WARNING To system designers • When introducing BHTs in those systems that could affect human lives, develop applications carefully through redundancy and safety design which avoids the feasibility of affecting human lives even if a data error occurs. Handling the BHT Wrong handling of the BHT may affect normal operation or result in, electric shock, generating heat and smoke, and vision disturbance.
  • Page 7 BHT-M70 Series Handling the batteries Wrong handling the batteries may result in electrical shock, overheating, smoke generation, combustion, or blowout. Please read the following items prior to use. • The battery is exclusively for the BHT. Do not use the battery for purposes other than charging the BHT.
  • Page 8 If you register the serial number of the product within one month after your purchase, the warranty of the registered product will be prolonged to three years from the one-year warranty. Please access the URL below to register. https://www.denso-wave.com/ The serial number for registration is found under the QR Code on the name plate.
  • Page 9 BHT-M70 Series CAUTION Handling the BHT Wrong handling of the BHT may affect normal operation or result in overheating, smoke generation, failure, and vision disturbance. Be sure to observe the following. When using the hand strap or neck strap, exercise due care to avoid getting them caught in •...

  • Page 10: About This Product

    Barcode / 2D Code Handy Terminal About This Product The BHT-M70 handy terminal, powered by Android 10, is light-weight, easy to use, providing powerful and handy tools for the purpose of delivering flexibility in customization. Specifically designed to work as an industrial PDA, it provides rich options for data collection, voice and data communication, long-lasting working hours, and so on.
  • Page 11 BHT-M70 Series • The optional products include communication units CU-M70U/M70L/M70UQ, 4-slot terminal charger CH-M70-4, USB cable, lithium-ion battery, etc. * IP67 is not a guaranteed value, but a test value at the normal temperature.

  • Page 12: Component And Functions

    Barcode / 2D Code Handy Terminal 1 Quick Start Guide 1.1 Component and Functions Upper side Receiver, Speaker Status indicator Microphone USB connector Lower side Interface connector Hand belt Rear camera Code reading window Battery cover locks M1 key M2 key Left trigger key Power key M3 key...
  • Page 13 BHT-M70 Series 1.2 Supporting Model List For the BHT-M70 Series, the equipped functions are different as shown in the table below. WWAN BHT-M70-QW — — BHT-M70-QWG ✓ ✓...
  • Page 14 Barcode / 2D Code Handy Terminal 1.3 Mounting the Hand Belt Attach the hand belt to each of the two places as shown in the figure. Connect the hand belt. Install the stylus as shown. Select the right or left side of the hand belt.

  • Page 15: Installing And Removing Battery

    BHT-M70 Series 1.4 Installing and Removing Battery The BHT main body and the battery are packaged separately due to the conditions of shipment and storage. Caution: Incorrect handling may decrease the lifetime of battery. Warning: Before powering on, confirm that the battery cover lock is positioned at the “ Lock ” position.
  • Page 16 1.5 Installing and Removing SIM Card/microSD Card BHT-M70-QW Handy Terminal Wireless LAN model is equipped with one microSD card slot. BHT-M70-QWG Wireless LAN + WWAN model comes with one microSD card slot and one nano SIM card slot. Installation of a card Remove the battery by following the description of removing battery.
  • Page 17 BHT-M70 Series (B) Push in the card with a fingertip until it fits in the slot. Never use an actual pen or other sharp object to insert the card. Otherwise, internal parts may be damaged and result in failure of the device. While the SIM card is locked with a click, the microSD card is not locked.
  • Page 18 Barcode / 2D Code Handy Terminal Place the battery cover back and push the battery cover lock to the “ Lock ” position. Do not use a pointed object such as a pen tip when removing a card. Doing so may damage internal parts and result in inappropriate terminal operation.
  • Page 19 BHT-M70 Series 1.6 Power ON/OFF BHT Power ON To power on BHT, press and hold the power button located on the upper right side of BHT. BHT will turn on and show the lock screen after splash screen. Swipe the lock screen upward to display the home screen.
  • Page 20 Barcode / 2D Code Handy Terminal Power OFF Press the power button , and a menu will appear on the screen which allows you to power off BHT. Make sure all user data have been stored before tapping on Power off.
  • Page 21 BHT-M70 Series 1.7 Charging The battery may not be charged to full for shipment. When you first receive the kit package, you need to charge the battery to full before using BHT. You may use the Communication Unit or multiple BHT charger to charge the BHT.
  • Page 22 Barcode / 2D Code Handy Terminal 1.7.4 Use of USB Direct Cable The USB Direct Cable provides a convenient way to charge your BHT. Fasten the USB Direct Cable to the lower end of the BHT. Connect the other end of the cable to the USB port or the USB power adapter of a host computer. It may take long to charge to full depending on the power supply capacity of the host computer.
  • Page 23 BHT-M70 Series 1.7.5 Use of Communication Unit The Communication Unit charges both your BHT and a spare battery at the same time. Preparation of Communication Unit Connect the AC adaptor to the Communication Unit. To carry out data communication, connect a communication cable to the Communication Unit.
  • Page 24 Barcode / 2D Code Handy Terminal Charging procedure Place the BHT upright and gradually tilt away from you. Note: When placing the BHT on the cradle, ensure there is no tangled strap between the device and the cradle. A specific part of the BHT may get warm while charging depending on operating environment and conditions.
  • Page 25 BHT-M70 Series Charging Spare Batteries CU-M70U spare battery charge indicator turns red and charging commences. The charge indicator turns blue upon completion of battery charging. To install a spare battery, as the illustration below shown, incline and insert the spare battery into the battery well, and press it down to install properly.
  • Page 26 Barcode / 2D Code Handy Terminal 1.8 Communication The barcode data collection system using BHT can connect various types of hardware to the BHT through each communication system.

  • Page 27: Ethernet Communication

    (Wired LAN) interface to enable the data communication complying with 100BASE-TX or 10BASE-T standard. For the connection with the Communication Unit, refer to BHT-M70 Software User's Manual. For the data communication through the Ethernet, refer to “ Wired LAN ” in the BHT-M70 Software User's Manual. 1.8.3 WLAN Communication Communication between BHT and a host computer through the LAN access point to enable the data communication complying with IEEE 802.11 a/b/g/n/ac standard.

  • Page 28: Nfc Communication

    Barcode / 2D Code Handy Terminal 1.8.6 NFC Communication NFC supporting model BHT can exchange NFC tags and data that satisfy Mifare and Felica specifications with NFC supporting devices. NFC establishes wireless communication via electromagnetic fields in short distance (within 1 cm). BHT can collect information from NFC tags and exchange information with other NFC supporting devices.

  • Page 29: Airplane Mode

    BHT-M70 Series 1.8.7 Airplane mode Turning on the Airplane mode enables you to turn off all the wireless radios on your BHT (including call functions and data communication functions using Bluetooth , Wi-Fi, and 3G/4G), which will ® considerably reduce power consumption of your battery.
  • Page 30 Barcode / 2D Code Handy Terminal 2 Using BHT-M70 2.1 Battery Battery BHT is powered by rechargeable Li-ion battery pack. It takes approximately 3 hours at 18 ° C to 35 ° C ambient temperature to charge them to full using the Communication Unit with AC adaptor or the charger.

  • Page 31: Battery Status Indicators

    BHT-M70 Series 2.1.1 Battery Status Indicators The battery pack is the only power source for BHT to work. Therefore, when the battery level goes low, you need to replace the battery pack with a charged one or charge it as soon as possible. You should backup important data on a regular basis.
  • Page 32 Barcode / 2D Code Handy Terminal 2.1.2 Monitoring Battery Level Battery level The battery is the only source that feeds BHT to work. It also supplies the sub battery on the main board in order to avoid the data loss. When the battery level gets low, recharge it or replace it as soon as possible.
  • Page 33 BHT-M70 Series Battery saver mode You can have the Battery saver mode automatically turned on when the battery level gets low. This mode will limit the use of location services, vibration and most background processing data. To open Battery Saver, swipe down from the top of the screen and open Quickstep.
  • Page 34 Barcode / 2D Code Handy Terminal Turn ON this function and select the condition to automatically enable this mode. When Based on percentage is selected, percentage can be specified.
  • Page 35 BHT-M70 Series Battery optimization With Battery optimization enabled for the applications, you can make sure they stay inactive when your BHT is idle or when applications have not been used for days. On battery screen, tap Menu and then select “ Battery optimization ” .
  • Page 36 Barcode / 2D Code Handy Terminal Low battery alert BHT prompts a warning notification reminding you to charge the battery and the status indicator will blink red when the battery level drops to 15% and 5%. Opening Notification Drawer, you will also see this warning appearing on the notification list; you may turn on Battery saver mode, connect BHT to an external power source, or replace the battery pack as soon as possible.
  • Page 37 BHT-M70 Series Replacing battery When the battery level is low, follow the steps below to replace the battery. Press and hold the power button on the side of the BHT. Tap “ Power off ” in the pop up menu. BHT will power off.
  • Page 38 Barcode / 2D Code Handy Terminal Hot swap Sub battery supplies system power during battery swap. When battery cover is removed, the system will enter suspend mode and not wake up until the battery cover is put back and the power button is pressed. To perform the hot swap: Make sure the new battery is fully-charged.

  • Page 39: Power Management

    BHT-M70 Series 2.1.3 Power Management Here are some tips to help you save battery power. Caution: Using backlight, wireless connectivity, and peripheral devices while on battery power will substantially reduce battery power. Bring an additional battery pack with you when you go out.

  • Page 40: Touch Screen

    When selecting an SD card for the best compatibility and performance with BHT-M70 series, please make sure of the capacity you need. For the use of SDXC card, please use a new card and make sure that it has not been used in other host devices (computers, cameras, or SD card readers).

  • Page 41: Status Indicator

    BHT-M70 Series 2.4 Notifications 2.4.1 Status Indicator Status indicator located above the touch screen provide information about charging status, scanner light beam, and scanner “ Good Read ” during data collection. Status Action Description indication Blue, solid Charging complete Red, solid...

  • Page 42: Legal Information

    Barcode / 2D Code Handy Terminal 2.4.3 Vibration BHT is integrated with a vibrator and it can be helpful when working in noisy environments. You may also set BHT to vibrate only, in which all system sounds will be muted and replaced by the vibrator. On any screen, press down Volume Up or Volume Down key to open the quick sound menu.

  • Page 43: Basic Operation

    BHT-M70 Series 3 Basic Operation This chapter describes the basic skills to work with BHT-M70 handy terminal, for instance how to operate the home screen, check of system statuses and management notifications. The add-on utilities for applications regarding data reading, processing and transmission are introduced in the following chapters.

  • Page 44: Keyboard Input

    Barcode / 2D Code Handy Terminal 3.2 Keyboard Input When the text input field appears, the on-screen keyboard is opened automatically. The style of keyboard varies according to the data type (texts or numbers) this field requires. Data can also be input with the keyboard in the main body of BHT.

  • Page 45: Security Lock

    BHT-M70 Series 3.3.2 Security lock Setting a screen lock allows you to protect your personal data on the BHT while it is not at your hand. Since various types of screen lock and Smart Lock are available, you cannot only enjoy the benefits of this function but also great convenience.

  • Page 46: Resetting To The Factory Default

    Barcode / 2D Code Handy Terminal 3.4 Resetting to the Factory Default Resetting to a factory default will erase all data on your BHT including call logs, messages files as well as your installed apps and their associated data, and revert the BHT back to its original state in which you powered on for the first time.

  • Page 47: Maintenance

    BHT-M70 Series 4 Maintenance 4.1 Storing the BHT Store the BHT with a fully charged battery installed. 4.2 Handling the Batteries 4.2.1 Battery Life Batteries are consumables. As the charging is repeated, the battery service life per charge declines. If a battery as described below is used, replace the current battery with a new one: When the recharge has been repeated to a battery more than 300 times, or when a battery has been used for more than one year.

  • Page 48: Daily Maintenance

    Barcode / 2D Code Handy Terminal 4.4 Daily Maintenance 4.4.1 Proper Care of the BHT Wipe any dirt from the BHT housing, interface connector terminals, and battery terminals with a dry, soft cloth. Make sure to turn OFF the BHT before cleaning. Notes Never use substances such as alcohol, as this may cause the housing to be marred or paint to •...
  • Page 49 1,500 times Solutions: 70% ethanol/ 10 ppm to 80 ppm hypochlorous acid water/ 70% isopropyl alcohol/ 3% hydrogen peroxide Applicable models: AUTO-ID product models selected by material and posted on the DENSO WAVE ’ s website. Note - Do not apply any liquid on the reading window or the dust-proof plate.
  • Page 50 Barcode / 2D Code Handy Terminal 5 Specifications 5.1 Model/Platform/Processor/Memory BHT-M70 comes in t models as described below: WWAN model: BHT-M70-QWG WLAN model: BHT-M70-QW 5.1.1 Operating system/CPU OS version Android™ 10 Qualcomm SDM660 ® Memory 64 GB eMMC 4 GB LPDDR3 SDRAM...

  • Page 51: Electrical Characteristics

    BHT-M70 Series 5.2.2 Data/Image Capture Cameras Rear Camera 13-Mega pixels. Code Reader 2D Imager HF RFID Reader ISO14443A/B (Mifare), ISO15693 (Felica) Supports NFC (P2P, Card reader, Card emulation) Perform a sufficient reading test with a card to be used preliminarily.

  • Page 52: Physical Characteristics

    Barcode / 2D Code Handy Terminal 5.4 Physical Characteristics 5.4.1 Color Touch Screen Display 4.0 ″ Transmissive IPS LCD, Dragontrail PRO Glass Display ® Resolution HD (480 X 800 pixels) 5.4.2 Notifications Status indicator Lighting red when charging, Blue when charging is completed Lighting blue when reading is completed Audio Integrated with one speaker with echo and noise cancellation.

  • Page 53: Reading Configuration

    BHT-M70 Series Appendix I Reading configuration Symbologies supported Codabar Code 11 Code 39 Code 39 Trioptic Code 39 Italian Pharmacode (Code 32) Code 93 Code 128 Code 128 GS1-128 (EAN-128) ISBT 128 Code 2 of 5 Chinese 25 Industrial 25 (Discrete 25)
  • Page 54 Barcode / 2D Code Handy Terminal EAN/UPC EAN-8 EAN-8 Extend EAN-13 Bookland EAN (ISBN) ISSN EAN UPC-A UPC-E Convert to UPC-A UPC-E1 Convert to UPC-A 2D Symbologies Aztec Data Matrix Maxicode MacroPDF MicroPDF417 MicroQR PDF417 QR Code...
  • Page 55 Handy Terminal BHT-M70 series Hardware User’s Manual First Edition May. 2022...
