Sony VAIO Slimtop PCV-L620 Specifications

FEATURES
• Intel ® Pentium ® III processor 500 MHz
• 128 MB PC-100 SDRAM (expandable to 256 MB)
• 13 GB †† Ultra ATA hard drive
• 4.8X DVD-ROM (max) drive
• 24X CD-ROM (max) disc read
• i.LINK ® (IEEE-1394) chipset
®
• i.LINK (IEEE-1394) interface and USB
connections
• 2X AGP 3D Graphic Hardware Acceleration
(ATi Rage LT Pro)
• 8 MB Video Memory (SGRAM)
• Dynamic 3D PCI Audio
• Type II PC Card Slot (CardBus & Zoomed

Video Support)

™
• VAIO Smart Convertible Keyboard
• V.90 Modem
Sony Electronics Inc.
Information Technologies Marketing Division
3300 Zanker Road, San Jose, California 95134
For more information: 1.800.4SONYPC (476-6972)
Web address: http://www.sony.com/pc
Computer Interface: The computer industry lacks standards, and therefore, there are a multi-
tude of varying software packages and add-on hardware options. This personal computer is
not manufactured to any specific software, and Sony does not and cannot make any warranty
or representation with respect to the performance of this product with any particular software
packages and/or non-Sony add-on hardware option except those mentioned in this document.
Sony hereby disclaims any representations or warranty that this product is compatible with
any combination of non-Sony products you may choose to connect. While Sony representa-
tives or Sony authorized dealers may be able to assist you and may make recommendations,
they are NOT authorized to vary or waive this disclaimer. Purchasers must determine for them-
selves the suitability and compatibility of the hardware and software in each and every particu-
lar instance. Some pre-installed software titles may not include full documentation. Software
titles pre-installed on the Sony Notebook Computer are subject to change without notice.
Simulated graphic shown on display.
©1999 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without writ-
ten permission is prohibited. Sony, i.LINK, Multiscan, Trinitron, and VAIO are trademarks of
Sony. Intel, the Intel Inside logo, and Pentium are registered trademarks of Intel Corporation.
Microsoft, Windows and the Windows logo are trademarks of Microsoft Corporation. All other
trademarks are trademarks of their respective owners. This product meets the standards of the
International Energy Star Program for energy efficiency. The Energy Star emblem does not rep-
resent EPA endorsement of any product or service. Features and specifications are subject to
change without notice. Non-metric weights and measurements are approximate.
Printed in U.S.A. 9/99

ADDITIONAL SPECIFICATIONS

Model
PCV-L620
Processor
® ®
Intel Pentium III Processor 500 MHz
Cache Memory
512 KB Level 2
Standard RAM
†
128 MB PC-100 SDRAM, expandable to 256 MB
Hard Drive
13 GB Ultra DMA Hard Drive
DVD/CD-ROM Drive
4.8X max. DVD-ROM Drive
24X max. CD-ROM Disc Read
Floppy Disk Drive
3.5" 1.44 MB Floppy Disk Drive
Video & Graphics
3D Graphics Hardware Acceleration
(ATi Rage LT Pro)
8 MB Video Memory (SGRAM)
Digital Audio
3D PCI surround sound (Aureal)
Positional 3D Audio (A3D)
Speakers
Harmon-Kardon in LCD Panel
Modem
V.90 Modem
Expansion Slots
Two PCI (one occupied by Modem)
Port Connectors
Two USB (one front / one rear)
One PS/2 Mouse/Keyboard
One VGA
One Serial
One Parallel
One 6pin i.LINK
One 4pin i.LINK
One Headphone Out/Line Out (front)
One Line In
One Line Out
One Microphone (front)
One Modem Line (RJ-11)
One Phone LIne (RJ-11)
One LCD Port (LVDS)
Supplied Accessories
VAIO Smart ™ Convertible Keyboard
Wheel Mouse
RJ-11 Phone Cord
Power Cord
4 MB Memory Stick
Power Requirements
100-120V -3A (50/60Hz)
Power Management
ACPI 1.0 Compliant
Advanced Power Management (APM version 1.2)
Sony VAIO Slimtop
™
Ergo-Angle Multimedia LCD Display
4.8X max. DVD-ROM Drive
i.LINK ® (IEEE-1394) Interface
Sony Memory Stick
™
Media
PCV-L620
™
Computers
i.LINK
(IEEE-1394)
™ Slot
Dimensions (CPU)
CPU: 11.2"(W) x 3.6"(H) x 13.4"(D)
Keyboard: 15.9"(W) x 1.8"(H) x 7.1"(D)
Display: 17.8"(W) x 12.6"(H) x 6.9"(D)
Weight
CPU: 11.9 lbs.
Keyboard: 2.9 lbs.
Display: 6 lbs.
Service
One Year Limited Expressed Repair Service*
Limited Warranty
One Year Parts and Labor (upon registration; 90 days
without registration)*
Telephone Support
Hardware: One Year
Software and Operating System: 90 Days
Pre-Installed Software
Operating System
Microsoft ® Windows ® 98 Second Edition
Sony Original Software
DVgate ™ Motion
DVgate ™ Still
PictureGear ™
Media Bar
Smart Capture
Smart Connect
Other Software Applications
Microsoft ® Works Suite 99
Microsoft Word 97
Microsoft Works 4.5
Microsoft Works Calendar
Microsoft Money 99
®
Microsoft Encarta 99
Microsoft Greetings 99
Microsoft Expedia ® Street 98
Adobe ® Premiere ® 5.1 LE
Adobe ® Acrobat ® Reader
Adobe ® PhotoDeluxe ® Business Edition
Intuit ® Quicken ® Basic 99
Sonic Foundry ® : Sound Forge ® XP 4.5
Symantec WinFax ® Basic Edition
Online Center
America Online ® **
CompuServe ® **
Microsoft ® Internet Explorer for Windows
Netscape ® Communicator ®
®
Progressive Networks RealPlayer
®
Prodigy Internet**
™
EarthLink Sprint TotalAccess **
AT&T WorldNet Service**
Tool Center
McAfee VirusScan
Sony Application Recovery CD
System Recovery CD
† MHz denotes microprocessor internal clock speed; other factors may
affect application performance.
†† GB means one billion bytes when referring to hard drive capacity.
Accessible capacity may vary.
* Certain restrictions apply.
** Requires payment of additional fees or subscription for use.
®
® 98
