  • Page 1 Projector ® User manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY ....................4 Important Safety Instruction....................... 4 Laser Radiation Safety Information ................... 5 Cleaning the Lens........................6 3D Safety Information ........................ 6 Copyright ........................... 7 Disclaimer ..........................7 Trademark Recognition ......................7 FCC ............................8 Declaration of Conformity for EU countries ................8 WEEE ............................
  • Page 3 Remote control codes....................... 47 Troubleshooting ........................49 Warning indicators ........................50 Specifications ........................... 53 Optoma global offices ....................... 54 English...

  • Page 4: Safety

    SAFETY The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 5: Laser Radiation Safety Information

    ‡ Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. ‡ See projector enclosure for safety related markings.

  • Page 6: Cleaning The Lens

    ‡ Additional instructions to supervise children, no staring, and not use optical aids. ‡ Notice is given to supervise children and to never allow them to stare into the projector beam at any distance from the projector. ‡ Notice is given to use caution when using the remote control for starting the projector while in front of the projection lens.

  • Page 7: Copyright

    such as eye or muscle twitching; (5) confusion; (6) nausea; (7) loss of awareness; (8) convulsions; (9) cramps; and/ or (10) disorientation. Children and teenagers may be more likely than adults to experience these symptoms. Parents should monitor their children and ask whether they are experiencing these symptoms.

  • Page 8: Fcc

    This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 9: Introduction

    INTRODUCTION Thank you for purchasing an Optoma 4K UHD projector. For full list of features please visit the product page on our website, where you will also find additional information and documentation such as voice control setup and FAQs. Package Overview Carefully unpack and verify that you have the items listed below under standard accessories.

  • Page 10: Product Overview

    INTRODUCTION Product Overview Minimum 100mm Minimum Minimum 100mm 100mm Minimum Minimum 300mm 300mm Minimum 100mm Note: ‡ Do not block projector intake and exhaust vents. ‡ When operating the projector in an enclosed space, allow at least 30 cm clearance around the intake and exhaust vents.

  • Page 11: Connections

    INTRODUCTION Connections Item Item HDMI 1 Connector Kensington Lock Port (eARC/ARC out; low latency mode) HDMI 2 Connector (pass eARC audio format Audio Out Connector through the HDMI-1 connector) HDMI 3 Connector (pass eARC audio format S/PDIF Connector through the HDMI-1 connector) ‡...

  • Page 12: Keypad

    INTRODUCTION Keypad Item Item Light Source LED Temp LED Power and Power LED Re-Sync Menu Four Directional Select Keys Keystone Correction Source Enter 10. Information English...

  • Page 13: Remote Control

    INTRODUCTION Remote control Item Item Power On 15. User2 (assignable) Re-sync 16. Source Backlight 17. Aspect Ratio Keystone 18. Sleep Timer Contrast 19. 3D Menu On / Off Brightness 20. Lamp 21. HDR Enter 22. Mode Four Directional Select Keys 23.

  • Page 14: Setup And Installation

    °free orientation operation listed below. The projector should be horizontal and not tilted either forwards/ backwards or left/right. Any other orientation will invalidate the warranty and may shorten the lifetime performance of the projector. For non-standard installation advice please contact Optoma. English...
  • Page 15 SETUP AND INSTALLATION Projector installation notice ‡ 360° free orientation operation ‡ Allow at least 30 cm clearance around the exhaust vent. Minimum 100mm Minimum 300mm Minimum 300mm (3.94 inches) (11.81 inches) (11.81 inches) Minimum 100mm (3.94 inches) Minimum 100mm Minimum 100mm (3.94 inches) (3.94 inches)

  • Page 16: Connecting Sources To The Projector

    SETUP AND INSTALLATION Connecting sources to the projector Item Item Item HDMI Cable 12V DC Jack S/PDIF Out Cable HDMI Dongle 3D Emitter Cable RS-232 Cable USB Power Cable Audio Out Cable Power Cord Note: To ensure the best image quality and avoid connection errors, we recommend the use of Premium HDMI cables.

  • Page 17: Adjusting The Projector Image

    SETUP AND INSTALLATION Adjusting the projector image Image height The projector is equipped with elevator feet for adjusting the image height. Locate the adjustable foot you wish to adjust on the underside of the projector. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector. Tilt-Adjustment Feet Tilt-Adjustment Ring Zoom and focus...

  • Page 18: Remote Setup

    SETUP AND INSTALLATION Remote setup Installing / replacing the batteries Two AAA size batteries are supplied for the remote control. Remove the battery cover on the back of the remote control. Insert AAA batteries in the battery compartment as illustrated. Replace back cover on remote control.
  • Page 19 SETUP AND INSTALLATION Effective range Infra-Red (IR) remote control sensor is located on top of the projector. Ensure to hold the remote control at an angle within 30° perpendicular to the projector’s top or front IR remote control sensor to function correctly. The distance between the remote control and the sensor should not be longer than 6 meters (~19 feet).

  • Page 20: Using The Projector

    USING THE PROJECTOR Powering on / off the projector Powering on Securely connect the power lead and signal/source cable. When connected, the On/Standby LED will turn red. Turn on the projector by pressing the “ ” button on the projector keypad or the remote control. A start up screen will display in approximately 10 seconds and the On/Standby LED will be flashing blue.

  • Page 21: Selecting An Input Source

    USING THE PROJECTOR Powering off Turn off the projector by pressing the “ ” button on the projector keypad or the remote control. The following message will be displayed: Power Off Power Off? Press power key again. Press the “ ”...

  • Page 22: Projector Settings Menu (Osd)

    USING THE PROJECTOR Projector settings menu (OSD) Press “ ” on the remote control, select the OSD menu “ ” to review projector information or manage various settings related to the image, display, 3D, audio, and setup. General menu navigation Sub Menu Settings Display...

  • Page 23: Osd Menu Tree

    USING THE PROJECTOR OSD Menu tree Note: The OSD menu tree items and features are subject to models and region. Optoma reserves the right to add or remove items to improve product performance without notice. Main Sub Menu 1 Sub Menu 2...
  • Page 24 USING THE PROJECTOR Main Sub Menu 1 Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Brightness -50 ~ 50 Contrast -50 ~ 50 Sharpness 1 ~ 15 Color -50 ~ 50 Tint -50 ~ 50 Film Video Graphics Gamma Standard(2.2)
  • Page 25 USING THE PROJECTOR Main Sub Menu 1 Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu DynamicBlack Eco. Constant Power Brightness Power =100%/95%/90%/85%/80%/ Mode Image Settings 75%/70%/65%/60%/55%/50% Constant Luminance Power=85%/80%/75%/70% Reset Enhanced Gaming Off [Default] 3D Mode 3D Sync Invert Off [Default] 16:9 Display...
  • Page 26 USING THE PROJECTOR Main Sub Menu 1 Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Off [Default] Direct Power On Off [Default] Signal Power Auto Power Off 0 ~ 180 (5 min increments) (min.) [Default: 20] 0 ~ 990 (30 min increments) Power Settings [Default: 0] Sleep Timer...
  • Page 27 USING THE PROJECTOR Main Sub Menu 1 Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu English [Default] Deutsch Français Italiano Español Language Português 繁體中文 簡体中文 日本語 한국어 Русский Top Left Top Right Menu Location Center [Default] Bottom Left Menu Settings Bottom Right Menu Timer...
  • Page 28 USING THE PROJECTOR Main Sub Menu 1 Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu None [Default for Video/Pro-AV) Blue [Default for Data model) Background Options Color Green Setup Gray Cancel [Default] Reset OSD Reset Cancel [Default] Reset to Default Regulatory Serial Number...

  • Page 29: Display Menu

    USING THE PROJECTOR Display menu Image settings menu Display Mode There are several predefined display modes that you can choose from to suit your viewing preference. Each mode has been fine-tuned by our expert color team to ensure superior color performance for wide range of content. ‡...
  • Page 30 USING THE PROJECTOR Wall Color Designed to adjust the colors of the projected image when projecting on to a wall without a screen. Each mode has been fine-tuned by our expert color team to ensure superior color performance. There are several predefined modes that you can choose from to suit the color of your wall.
  • Page 31 USING THE PROJECTOR ‡ Film: For home theater. Video: For video or TV source. ‡ Graphics: For PC / Photo source. ‡ ‡ Standard(2.2): For standardized setting. ‡ 1.8 / 2.0 / 2.4: For specific PC / Photo source. 2.4 can also be used for video content and games to enable deeper contrast.
  • Page 32 USING THE PROJECTOR Enhanced Gaming menu Enable this feature to reduce response times (input latency) during gaming to 4.5ms for HDMI Port 1. All geometry settings (example: Keystone, Warping) will be disabled when Enhanced Gaming Mode is enabled. Additional information below. Note: ‡...
  • Page 33 USING THE PROJECTOR ‡ To use the Full Screen format, do the following: Set the screen aspect ratio to 2.0:1. Select “Full Screen” format. Align the projector image correctly on the screen. 4K UHD scaling table: 16 : 9 screen 480i/p 576i/p 720p...
  • Page 34 USING THE PROJECTOR Zoom menu Use to reduce or magnify an image on the projection screen. Note: Zoom settings are retained on power cycle of the projector. Image Shift menu Adjust the projected image position horizontally (H) or vertically (V). Note: The image size will reduce slightly when adjusting the horizontal and vertical keystone.

  • Page 35: Audio Menu

    USING THE PROJECTOR Audio menu Audio Mode Select the appropriate audio mode. Input Source Audio Mode HDMI1/HDMI2/HDMI3 Speaker/Audio out SPDIF/ARC: PCM, Dolby Digital, DTS SPDIF/eARC eARC: PCM, Dolby Digital/+, DTS-HD Note: ‡ The selected audio mode applies to all sources: ‡...

  • Page 36: Setup Menu

    USING THE PROJECTOR Setup menu Projection Select the preferred projection between front, rear, ceiling-top, and rear-top. Power Settings Configure power settings. ‡ Direct Power On: Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied, without pressing the “Power” key on the projector keypad or on the remote control.
  • Page 37 USING THE PROJECTOR HDMI Link Settings Note: When you connect HDMI CEC-compatible devices to the projector with HDMI cables, you can control them on the same power on or power off status using the HDMI Link control feature in the projector’s OSD. This lets one device or multiple devices in a group power on or power off via HDMI Link Feature in a typical configuration, your DVD player may be connected to the projector through an amplifier or home theater system.
  • Page 38 USING THE PROJECTOR Options Configure the projector options. ‡ Language: Select the multilingual OSD menu between English, German, French, Italian, Spanish, Portuguese, Traditional Chinese, Simplified Chinese, Japanese, Korean, and Russian. Menu Settings: Set the menu location on the screen and configure menu timer settings. ‡...

  • Page 39: Info Menu

    USING THE PROJECTOR Info menu View the projector information as listed below: ‡ Regulatory ‡ Serial Number ‡ Source ‡ Resolution ‡ Refresh Rate ‡ Display Mode ‡ Projector ID ‡ Brightness Mode ‡ FW Version English...

  • Page 40: Additional Information

    ADDITIONAL INFORMATION Compatible resolutions Video compatibility Signal Resolution SDTV 480p HDTV 720p (50/60Hz), 1080i (50/60Hz), 1080p (24/50/60Hz) 2160p (24/50/60Hz) Video timing in details: Signal Resolution Refresh Rate (Hz) Notes SDTV(480p) 640 x 480 HDTV(720p) 1280 x 720 50/60 HDTV(1080I) 1920 x 1080 50/60 HDTV(1080p) 1920 x 1080...
  • Page 41 ADDITIONAL INFORMATION Timing table for PC: Frequency H. Refresh Rate Signal Resolution (KHz) (Hz) Video Digital Note SVGA 800 x 600 35.2 56.3 √ 56Hz SVGA 800 x 600 37.9 60.3 √ 60Hz SVGA 800 x 600 46.9 √ SVGA 800 x 600 48.1 72.2...
  • Page 42 ADDITIONAL INFORMATION Computer Compatibility for MAC Macbook Macbook Pro Power Mac G5 Power Mac G4 Compatibility (Intel) Compatibility Compatibility Compatibility Resolution Digital Digital Digital Digital 800 x 600 √ √ √ 800 x 600 √ √ √ 800 x 600 √...
  • Page 43 ADDITIONAL INFORMATION Note: ‡ (*1) 1920 x 1200 @ 60Hz only supports RB(reduced blanking). ‡ (*2) Windows 10 standard timing. ‡ (*3) Only supported with HDMI1 and HDMI2. 3D Supported Timing HDMI1.4a 3D Timing for Blue-Ray 3D Signal Timing Supported Port 720p (Frame Packing) 1280 x 720 @ 50Hz HDMI1, HDMI2, HDMI3...
  • Page 44 ADDITIONAL INFORMATION B0/Established B0/Standard Timing B0/Standard Timing B1/Video Mode B1/Detail Timing Timing 4096 x 2160 @ 60Hz 720 x 480p @ 60Hz 16:9 1280 x 720p @ 60Hz 16:9 1280 x 720p @ 50Hz 16:9 720 x 576p @ 60Hz 16:9 Note: ‡...

  • Page 45: Image Size And Projection Distance

    ADDITIONAL INFORMATION Image size and projection distance Diagonal Screen Size W x H Projection Distance (D) Offset (Hd) length (inch) (feet) (inch) size of Width Height Width Height Wide Tele Wide Tele (feet) 16:9 Screen 0.66 0.37 26.15 14.71 43.4 0.02 0.06 1.11...

  • Page 46: Projector Dimensions And Ceiling Mount Installation

    ADDITIONAL INFORMATION Projector dimensions and ceiling mount installation To prevent damage to your projector, please use the Optoma ceiling mount. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: ‡...

  • Page 47: Remote Control Codes

    ADDITIONAL INFORMATION Remote control codes Custom code Key Code Description Byte 1 Byte 2 Byte 3 Byte 3 Power on Press to turn on the projector. Source Press “Source” to select an input signal. Backlight Backlight toggle. Automatically synchronizes the projector Re-sync to the input source.
  • Page 48 Byte 1 Byte 2 Byte 3 Byte 3 Lamp Select the brightness mode. Open the Optoma Color Management System (CMS). (not supported) Select a display mode for optimized Mode settings for different applications. Please see page 27. Configure the (HDR) settings.

  • Page 49: Troubleshooting

    ADDITIONAL INFORMATION Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image problems No image appears on-screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the "Installation"...

  • Page 50: Warning Indicators

    ADDITIONAL INFORMATION Other problems The projector stops responding to all controls ‡ If possible, turn off the projector, then unplug the power cord and wait at least 20 seconds before reconnecting power. Remote control problems If the remote control does not work ‡...
  • Page 51 ADDITIONAL INFORMATION LED status lights On/Standby LED Temp LED Light Source LED Message (Red) (Blue) (Red) (Red) Standby state Steady light (Input power cord) Flashing Power on (Warming) (0.5 sec off / 0.5 sec on) Power on and light source Steady light lighting Flashing...
  • Page 52 ADDITIONAL INFORMATION ‡ Fan failed: Warning FAN LOCKED The projector will switch off automatically Please contact a service center for repair. ‡ Out of display range: HDMI Out Of Range ‡ Power down warning: Warning Power Down Timer Active Time out in Sec.

  • Page 53: Specifications

    ADDITIONAL INFORMATION Specifications Optical Description Technology Texas Instrument DMD, 0.47”/1080p UHD HSSI DMD X1, S451 Output resolution 1920 x 1080 (w/o actuator) Graphic up to 2160p@60Hz ‡ HDMI1 (2.0): 2160p@60Hz ‡ HDMI2 (2.0): 2160p@60Hz Maximum input ‡ HDMI3 (2.0): 2160p@60Hz resolution Maximum Bandwidth: ‡...

  • Page 54: Optoma Global Offices

    ADDITIONAL INFORMATION Optoma global offices For service or support, please contact your local office. Korea 47697 Westinghouse Drive, 888-289-6786 https://www.optoma.com/kr/ Fremont, CA 94539, USA 510-897-8601 www.optomausa.com services@optoma.com Japan https://www.optoma.com/jp/ Canada 47697 Westinghouse Drive, 888-289-6786 Taiwan Fremont, CA 94539, USA 510-897-8601 www.optomausa.com...
  • Page 55 www.optoma.com...
