Selecting the hob surface
This operation optimises automatic operation of the hood.
IMPORTANT: Do not remove the adhesive film protecting the hood controls until the below operations have been completed.
Switch the hood OFF.
Press keys "2" and "3" at the same time for 5 seconds until the hob being used is displayed, according to the following legend:
LD1 LEDs on = gas hob
LEDs LD1+LD2 on = Induction hob
LEDs LD1+LD2+LD3 on = Electric hob
The type of hob can be selected pressing keys "2" and "3".
Ten seconds after the type of hob has been selected, this will be automatically saved by the system.
Saving of the selection will be confirmed by the selection itself flashing 3 times. Once the selection has been saved the hood will go off.
Note: The type of hob set by default is the Gas hob.
