Sony SS-X90ED Product Dimensions

SSX90ED
10 1/4"

FRONT VIEW

TOP VIEW

NOTE:
WHERE THERE ARE CLOSE TOLERANCES
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF
MEASUREMENTS.
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
MODEL:
DESCRIPTION:
DESCRIPTION:
DIMENSIONS DIMENSIONS
(WHD):
(WHD):
WEIGHT:
WEIGHT:
11 7/8"
39"

SIDE VIEW

11 7/8"
Speaker Grill Not Shown!
Speaker Grill Not Shown!
SONY WILL NOT BE RESPONSIBLE FOR
ES High End
Speaker System
10 1/4" x 39" x 11 7/8"
70 lbs 8 oz
37 7/8"
4 3/4"
6 7/8
2 1/4"
8 3/8"
1 5/8"
INVOLVED IN CABINET BUILDING
BE USED TO MAKE THE ACTUAL
INACCURACIES
POWER
REQUIREMENTS:
N/A
POWER
HANDLING:
100W@8ohms
200W Max
MID-HIGH FREQ IN
LOW FREQ IN
3 3/4"
BACKVIEW
FRONT FRONT
5 3/4"
Screw Dia
6mm

BOTTOM VIEW

WE
