Sony SS-CNX70ED Product Dimensions

SSCNX 70 ED

FRONT VIEW

BACKVIEW
Speaker Grill Not Shown!
Speaker Grill Not Shown!
NOTE:
WHERE THERE ARE CLOSE TOLERANCES
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF
MEASUREMENTS.
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
21 1/4"

TOP VIEW

3 5/8" 8 3/4"
SONY WILL NOT BE RESPONSIBLE FOR
MODEL:
ES High End
DESCRIPTION:
DESCRIPTION:
Speaker System
DIMENSIONS DIMENSIONS
(WHD):
(WHD):
21 1/4" x 10 1/4" x 10 1/4"
WEIGHT:
WEIGHT:
31 lbs

SIDE VIEW

10 1/4"
7 "

BOTTOM VIEW

3 1/8"
2 5/8"
INVOLVED IN CABINET BUILDING
BE USED TO MAKE THE ACTUAL
POWER
REQUIREMENTS: N/A
POWER
HANDILING:
60W@8ohms
120WMax
9"
10 1/4"
FRONT FRONT
WE
INACCURACIES
