Linear MULTI-CODE 1051 Manual

INSTR,INSTL,MC1051,GATE XMTR, PN: 216977 Rev-B, INK: Black, MATERIAL: 20 LB, MEAD BOND, SIZE: 7.500" X 7.500", SCALE: 1-1
3. You should test your entire system occasionally in
order to be sure that all components are working in
good order.
4. Nortek Security & Control LLC's dealers can provide
you with information regarding the use of our radio
controls, and can provide valuable installation and
operation information, when requested.
WARNING: Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the Federal
Communications
Commission (FCC) rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC & IC Notice
This device complies with Part 15 of the FCC Rules and Industry Canada
license exempt standard(s). Operation is subject to the following two
conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including
interference received that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes:
1) l'appareil ne doit pas produire de brouillage, et
2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
For service, return to your dealer or shop prepaid to:
USA & Canada Toll Free (800) 421-1587
or dial (760) 438-7000
www.nortekcontrol.com
Copyright ©2020 Nortek Security & Control LLC
PRINT INSTRUCTIONS:
®
SAFETY EDGE TRANSMITTER
The MULTI-CODE 1051 transmitter has been designed to
provide great reliability and safety, but it must be installed
correctly. Read the enclosed instructions carefully.
The Model 1051 may be used for a variety of purposes,
and wherever remote signaling is desirable, as specified
by FCC & IC regulations. If this transmitter is to be used in
an application which may be safety related be sure to take
special precautions. Nortek Security & Control LLC has
taken every step to insure the best possible product, but
you must be certain to install the 1051 transmitter correctly.
Before installing the 1051 transmitter, open it up by
removing the four screws which secure the top of the
case. You will note that there is a terminal block (see figure
1), to which you will secure the wires coming from your
device. Run your wire through the strain relief fitting, leaving
enough wire to provide adequate length for stripping.
YOUR WIRE SHOULD BE 18 TO 24 GAUGE, although any
wire that fits snugly in the strain relief fitting may be used.
Be sure to check the water-tightness of the fitting if you
use anything other than 18-24 gauge wire, as this may
compromise the integrity of the case. Put your two wires
under the terminal blocks, and fasten by screwing down.
Next, code your transmitter and, if necessary, your receiver.
The code switch (see figure 1) allows for 1024 possible
combinations. If you have an existing receiver, you may
code the 1051 to the same code, or you may choose to
wire a separate receiver. If you wire a second receiver, be
sure to separate the two receivers as much as possible, to
avoid any possibility of interference.
216977 Rev-B
Model 1051
Important! Read
Before Installation
