Lenovo ThinkSystem AFA DG7000 Installation And Setup Instructions

ThinkSystem AFA DG7000
Installation and Setup Instructions
Prepare for installation | Stage 1
Pre-setup
Contents
In the box
Cables in your
shipment are
order-dependent.
Not all cables
shown may be
in your shipment.
You provide
First edition (July 2023)
© Copyright Lenovo 2023.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a
General Services Administration (GSA) contract, use, reproduction, or disclosure is subject to
restrictions set forth in Contract No. GS-35F-05925.
Prepare for installation
1. Unpack all boxes and inventory contents.
Attention: Customers with specific power requirements must check
for their configuration options .
2. Review the ThinkSystem DG7000 Hardware Installation and Maintenance Guide:
https://thinksystem.lenovofiles.com/storage/help/topic/dg7000/overview.html
Note: For MetroCluster configurations, use the MetroCluster installation content:
https://thinksystem.lenovofiles.com/storage/help/topic/ontap-metrocluster_install-ip/index.html
100 GbE cable (QSFP28)
Storage, cluster network, GbE network,
and Ethernet data (order-dependent)
16 Gb FC or 25 GbE cables
Mezzanine cards (SFPs pre-installed):
Rack space Screwdriver
4U for AFA DG7000 + 2U Phillips #2
for each DM240N shelf
Install hardware
1
RJ-45 cables 32 Gb FC (SFP+ Op)
Wrench port (e0M/BMC) FC optical network cable
(order-dependent)
25 GbE cable (SFP28) Slide rail kit
HA interconnect
Additional network cables
For connecting your storage system to your
network switch and laptop or console
LENOVO and LENOVO logo are trademarks of Lenovo.
Microsoft and Windows are trademarks of the Microsoft group of companies.
All other trademarks are the property of their respective owners.
© 2023 Lenovo.
Cable storage
2 3
Lenovo Press (https://lenovopress.com)
Additional cables
Ethernet cables
Micro USB console cable
Cable management tray
Laptop or console
With a USB/serial connection and access
to a Web browser to configure your storage system
Printed in China
(1P) P/N: SP47B71438
Complete system setup
and configuration 4
Power cables
