Toro Leveler TXL 2000 Installation Instructions

Hydraulic Scarifier
Leveler TXL 2000 Tool Carrier
Model No. 22551
Safety
Safety and Instructional
Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger. Replace any decal that is damaged or missing.
1. High pressure fluid hazard, injection into the body—read
the Operator's Manual before performing maintenance.
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Description
No parts required
Left claw
Center claw
Right claw
Shaft
Bolt (1/2 x 3 inches)
Locknut (1/2 inch)
Hydraulic cylinder assembly
Bolt (3/4 x 4 inches)
Nut (3/4 inch)
Safety decal (125-6128)
© 2018—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
125-6128
Register at www.Toro.com.
decal125-6128
Qty.
–
Prepare the machine.
1
1
1
1
6
Install the scarifier.
6
1
1
1
1
Form No. 3426-151 Rev B
Installation Instructions
Use
Original Instructions (EN) All Rights Reserved *3426-151* B
Printed in the USA
