- Page 1 PROFESSIONAL SERIES PENDANT SPEAKERS PS-P43T | PS-P63T | PS-P83T | PS-P83WT IN STA LL ATION MANUA L...
- Page 2 INTRODUCTION PENDANT SPEAKERS Sonance Professional Series includes a range of In- PS-P43T | PS-P63T | PS-P83T | PS-P83WT Ceiling, Pendant and Surface Mount speakers that deliver true full range fidelity, extremely low distortion, wide dispersion and a smooth power response. The range also shares consistent voicing, ensuring seamless sonic integration when used together throughout a space.
- Page 3 AMPLIFIER SELECTION SPEAKER PLACEMENT When choosing an amplifier the maximum number of Sonance Professional Series speakers possess extremely speakers and the output level of each speaker must be smooth and predictable off-axis frequency response. The known. The sum of the tap settings should never exceed chart below shows how far apart the speakers can be 80% of the amplifier’s rated output.
- Page 4 PAINTING THE SPEAKER SHELL Sonance Professional Series Pendant speakers feature a tough polypropylene enclosure that can be painted. Sonance recommends using a weather-resistant outdoor paint and a spray gun.
- Page 5 STEP 11 HOW TO USE RELEASE KEY TO Connect the wires from your amplifier to the ADJUST SPEAKER HEIGHT Euroblock connector. STEP 7 Make sure the weight of the load is supported. STEP 12 Feed speaker wire through the hole in the top of the Screw-On Top Cover.
- Page 6 STEP 15 Lay the extra wire slack in a coiled circle on the top of the speaker enclosure. Secure the top cover onto the speaker, covering the coiled wire. The extra wire will act as a strain relief. STEP 16 Determine the proper wattage setting for each speaker in the installation...
- Page 7 SONANCE PS-P43T TECHNICAL SPECIFICATIONS Frequency Range (-10dB) 57Hz – 25kHz Frequency Range (-3dB) 75Hz – 20kHz Power Capacity 60 Watts Continuous Program Power 30 Watts Continuous Pink Noise Nominal Sensitivity 87dB Nominal Coverage Angle 120 degrees conical coverage Directivity Factor (Q) Directivity (DI) 8.1dB...
- Page 8 SONANCE PS-P63T TECHNICAL SPECIFICATIONS Frequency Range (-10dB) 49Hz – 25kHz Frequency Range (-3dB) 65Hz – 20kHz Power Capacity 120 Watts Continuous Program Power 60 Watts Continuous Pink Noise Nominal Sensitivity 88dB Nominal Coverage Angle 120 degrees conical coverage Directivity Factor (Q) Directivity (DI) 7.9dB...
- Page 9 SONANCE PS-P83T TECHNICAL SPECIFICATIONS 41Hz – 25kHz Frequency Range (-10dB) Frequency Range (-3dB) 55Hz – 20kHz Power Capacity 160 Watts Continuous Program Power 80 Watts Continuous Pink Noise Nominal Sensitivity 90dB Nominal Coverage Angle 120 degrees conical coverage Directivity Factor (Q) Directivity (DI) 8.1dB...
- Page 10 SONANCE PS-P83WT TECHNICAL SPECIFICATIONS Frequency Range (-10dB) 32Hz – 300kHz Frequency Range (-3dB) 50Hz – 150kHz Power Capacity 200 Watts Continuous Program Power 125 Watts Continuous Pink Noise Nominal Sensitivity 89dB Nominal Coverage Angle 180 degrees conical coverage Directivity Factor (Q)
- Page 11 Contact Sonance directly at (949) 492-7777 or at www.sonance.com YOU MUST HAVE PRIOR AUTHORIZATION TO RETURN YOUR UNIT. If you are returning the product directly to Sonance, call us to obtain a return authorization number before shipping. Ship the product via United Parcel Service, Federal Express, or other package delivery service.
- Page 12 EXCLUSIVE REMEDY Sonance agrees, at its option during the five (5) year warranty period, to repair any defect in material or workmanship or to furnish an equal product in exchange without charge to the purchaser, subject to verification of the defect and proof of the date of purchase.
