INSTALLATION INSTRUCTIONS

ED/DF175 22" CCM322/522 N
This Nordic style kit applies to the Cornelius 22" wide CCM322/522 ice maker.
Item No. Part No.
620043511
1
620043512
2 620046011
3 22127
4 70217
5 50904
6 90221
7 620204721INS
8 620701902
9 620701901
10 620037007
11 621701903
12 630500109
!
WARNING:
Disconnect power to the unit before installing the adaptor following all lockout/tag out procedures established by the
user. Verify that all the power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All ice baffle plates and bin stats, if included or recommended in this kit, must be installed as directed in this manual or
the equipment manufacturer's instructions.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All of the attachment screws and plates must be installed as directed in this manual.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
The dispenser must be secured with 3/8-16 bolts (6) to the counter before installing this Icemaker Adapter Kit. Refer
to the installation manual and Figure 2 for the counter mounting template.
1. Unpack Kit.
2. Insert baffle assembly into the adapter lid.
3. Place (2) sealing washers (item 9) over studs and (2) flat washers (item 11), then fasten in place with (2) plastic
acorn nuts (item 8).
4. Set ice maker lid on the top of the dispenser.
5. Using the slotted holes in the lid as a template, drill four (4) 0.140" diameter (9/64") holes at the bottom of the slots
(see detail A). Use extreme care not to drill into the hopper. Fasten the lid to the dispenser with four (4) #8 sheet
metal screws, two on each side.
6. Seal the ice maker to the top of the dispenser as follows:
Release Date: October 29, 2010
© 2007-2010, IMI Cornelius Inc.
ED/DF175 22" CCM322/522 Nordic Style Lid Kit Installation Instructions
B
ORDIC LACK
Table 1. Loose Shipped Parts
Cover, Gray
Cover, Black
Lid Assembly
Bracket
#8 Screw
RTV
Label
Installation Instruction
Acorn Nut, 8–32 Nylon
Sealing Washer
Ice Baffle ED150
#8 Nylon Washer
Bin Stat
