IMPORTANT SAFETY INSTRUCTIONS

When using your Sonance Navigator® Harbor, basic
safety precautions should always be followed to reduce
the risk of fire, electric shock, and injury to persons,
including the following:
1. Read instructions – All the safety and operating instructions
should be read before the appliance is operated.
2. Retain instructions – The safety and operating
instructions should be retained for future reference.
3. Heed warnings – adhere to all warnings and
precautions listed on the appliance and in the
operating instructions.
4. Follow instructions – Follow all operating instructions.
5. Water and moisture – The appliance should never be
used next to water; for example, near a bathtub,
kitchen sink, laundry tub, in a wet basement, or near
a swimming pool, etc.
6. Carts and stands – The appliance should be used
only with a cart or stand that is recommended by
the manufacturer.
7. An appliance and cart combination should be
moved with care. Quick stops, excessive force, and
uneven surfaces may cause the appliance and cart
combination to overturn.
8. Caution: To prevent electric shock, do not use the
Sonamp (polarized) plug with an extension cord,
receptacle, or other outlets unless the blades can be
fully inserted to prevent blade exposure.
9. Ventilation – The appliance should be situated so
that its location does not interfere with its proper
ventilation. For example, the appliance should not
be situated on a bed, sofa, register, or similar surface
that may impede the flow of air through the
ventilation openings.
10.Heat – The appliance should be situated away from
heat sources such as radiators, heat registers, stoves,
or other appliances (including amplifiers) that
produce heat.
11.Power sources – The appliance should be connected
to a power supply only of the type described in the
operating instructions or as marked on the appliance.
12.Grounding or polarization – Grounding or
polarization are the precautions that should be taken so
that these attributes of an appliance are not defeated.
13.Power-Cord Protection - Power supply cords should
be routed so that they are not likely to be walked on
or pinched by items placed upon or against them,
paying particular attention to cords at plugs,
convenience receptacles, and the point where they
exit from the appliance.
14.Cleaning - The appliance should be cleaned only as
recommended by the manufacturer.
15.Non-Use Periods- The power cord of the appliance
should be unplugged from the outlet when left
unused for a long period of time.
16.Object and Liquid Entry - Care should be taken
I N S TA L L AT I O N I N S T R U C T I O N S
SONANCE NAVIGATOR
M U L T I - Z O N E P R E - A M P L I F I E R
so that objects do not fall and liquids are not spilled
through the opening of the enclosure.
17.Damage Requiring Service - The appliance should
be serviced by a qualified service personnel when:
A. The power-supply cord or the plug has been damaged
B. Objects have fallen, or liquid has been spilled into the appliance
C. The appliance has been exposed to rain
D. The appliance does not appear to operate normally or
exhibits a marked change in performance
E. The appliance has been dropped, or the enclosure damaged
18.Servicing - The user should not attempt to service
the appliance beyond that described in the operating
instructions. All other servicing should be referred
to qualified service personnel.
19.Lifting – Do not attempt to lift the Sonance
Navigator Harbor without assistance. Improper
lifting of this 20 lb. unit can cause personal injury.
20.Power requirement – Do not connect the Sonance
Navigator Harbor to the accessory outlet of
another component.
21. Storms – To prevent damage to components, unplug
all electronic equipment during thunderstorms.
®
HARBOR

Advertisement

Table of Contents
loading

Summary of Contents for Sonance Navigator Harbor

  • Page 1: Important Safety Instructions

    All other servicing should be referred to qualified service personnel. 19.Lifting – Do not attempt to lift the Sonance Navigator Harbor without assistance. Improper lifting of this 20 lb. unit can cause personal injury.
  • Page 2: Introduction Of Functions

    In the case of a zone failure, it is no longer necessary to return the entire unit. Swap out the bad card and return it to Sonance for repair. See the Switcher Card Installation/Removal section for details.
  • Page 4 Front Panel Function Details The front of the Sonance Navigator Harbor is simple and elegant but it provides all necessary system information. The data available on the front panel is as follows: A.C.
  • Page 5 DND switch to “Off ” and that zone will receive a page. Keypad Connector: This removable five-pin connector is used to connect an IR based keypad like the Sonance Navigator K1 or K2 keypad. A standard three-wire IR receiver, like the Sonance OptiLinQ MR1, SMR1 or...
  • Page 6 Sonance Navigator Harbor remote control commands can be learned into any IR keypad or learning remote. The remote control can be used to control the Sonance Navigator Harbor through the IR window on the front panel or through an IR receiver connected to the keypad connector on each zone card.
  • Page 7: Installation Diagrams

    Harbor. Sonance strongly suggests that only a qualified technician do this procedure. 1. With the Sonance Navigator Harbor sitting on a stable work surface, with the top cover in place and while still plugged into a grounded AC outlet, touch one of the top cover mounting screws with a bare finger.
  • Page 8 • Sonance Navigator K1 or K2 keypads in each zone Sources can be controlled globally by all zones or by only a single zone. This diagram makes use of a Sonance Navigator Harbor with zone IR output controlling two tuner's. While other zones can select and listen to these tuner's, only zone five can control the first tuner and only zone six can control the second tuner.
  • Page 9 A Basic Six Zone System (fig. 1)
  • Page 10 Multiple Sonance Navigator Harbors (fig. 2)
  • Page 11 Single Zone Source Control (fig. 3)
  • Page 12 Video Distribution Techniques (fig. 4)
  • Page 13 Paging Input (fig. 5)
  • Page 14 Six Zone System with “Party” Capability (fig. 6)
  • Page 15 Other IR Input (fig. 7)
  • Page 16: Specifications

    6. For warranty work, please include a copy of the original bill of sale inside the package. Sonance • 212 Avenida Fabricante • San Clemente, CA 92672-7531, USA • (800) 582-7777 or (949) 492-7777 • FAX: (949) 361-5151 • Technical Support: (800) 582-0772 Ship the packaged unit to:...
