Rear-Engine Rider
Owner/Operator Manual
Models
927060 - 1028
927062 - 1232
927064 - 1440
Transfer
model &
serial number
label from
product reg-
istration here.
Coller l'autocollant du
modèle et du numéro de
série dans cet encadré.
Transferir aquí la etiqueta del
modelo y número de serie
del registro del producto.
ENGLISH
FRANÇAIS
ESPAÑOL
02783000A 6/04
Supersedes 02783000
Printed in USA

Advertisement

Table of Contents
loading

Related Manuals for Gravely 927060

Summary of Contents for Gravely 927060

  • Page 1 Rear-Engine Rider Owner/Operator Manual Models 927060 - 1028 927062 - 1232 927064 - 1440 ENGLISH FRANÇAIS ESPAÑOL Transfer Coller l’autocollant du modèle et du numéro de model & série dans cet encadré. serial number label from Transferir aquí la etiqueta del product reg- modelo y número de serie...

  • Page 2: Table Of Contents

    INTRODUCTION THE MANUAL PRODUCT REGISTRATION Before operation of unit, carefully and The Gravely dealer must register the product completely read your manuals. The contents at the time of purchase. Registering the will provide you with an understanding of product will help the company process...

  • Page 3: Safety

    1. Make sure all assembly has been properly completed. DISCLAIMER 2. Understand all Safety Precautions Gravely reserves the right to discontinue, provided in the manuals. change, and improve its products at any time 3. Review control functions and operation without notice or obligation to the purchaser.
  • Page 4 CAUTION PRUDENCE PRECAUCIÓN • Maximum tonque weight: 30 lbs. • Poids maximum du timon: 30 livres. • Peso máximo de la lengüeta: 30 lbs. • Maximum trailer weight: 300 lbs. • Poids maximum de la remorque: 300 livres. • Peso máximo del remolque: 300 lbs. •...
  • Page 5 SAFETY RULES Always stand clear of If unit is to be used by someone other than discharge area. Do not direct original purchaser; loaned, rented or sold, discharge toward other people. ALWAYS provide this manual and any needed safety training before operation. OL1810 Only the user can prevent and is responsible for accidents or injuries occurring to...
  • Page 6 Protect eyes, face and head from objects that Follow the manufacturer’s recommendations may be thrown from unit. Wear appropriate for wheel weights or counterweights to hearing protection. Always wear safety improve stability when using attachments. goggles or safety glasses with side shields NEVER carry passengers–especially when operating mower.
  • Page 7 Fuel is highly flammable and its vapors are ALWAYS disconnect negative (-) cable FIRST explosive. Handle with care. Use an and positive (+) cable SECOND. ALWAYS approved fuel container. connect positive (+) cable FIRST, and negative (-) cable SECOND. NO smoking, NO sparks, NO flames. ALWAYS allow engine to cool before A frozen battery can explode and result in servicing.

  • Page 8: Assembly

    ASSEMBLY FIRST TIME USE WARNING: AVOID INJURY. Read 1. Install steering wheel. and understand the entire Safety 2. Connect negative battery cable to section before proceeding. battery. See Battery Removal and Installation on page 18 and perform step TOOLS REQUIRED 1 in the removal section and perform •...

  • Page 9: Operation

    If Fast (2) – Increases engine the unit does not perform as stated, contact speed. your Gravely dealer for repairs. NOTE: With the parking brake engaged, the steering levers are locked in neutral. Test...
  • Page 10 Mower Lift Lever To Side Discharge: 1. Remove wing knobs. 2. Lift up mulch cover and re-install wing knobs on mower deck. OA0080 3. Install the two tabs of the discharge chute into the two slots of the mulch Raises and lowers the mower deck. See cover.
  • Page 11 OPERATING MOWER SEAT ADJUSTMENT 1. Start engine. 1. Remove detent pin from unit (figure 6). 2. Set throttle lever fast. 2. Tip seat forward. 3. Engage PTO to start mower blades. 3. Loosen mounting hardware and slide seat forward or backward to desired 4.

  • Page 12: Maintenance Schedule

    Engage parking brake and engage transmission bypass Brake lever (see Moving The Unit Manually on page 11). Push unit. If unit rolls, contact your Gravely Dealer. Clean Unit Clean engine, battery, seat, mower deck, etc. of all dirt and debris. Do not use solvents, hard cleaners, or abrasives.

  • Page 13: Service And Adjustments

    Interval Task Action Check Battery Keep battery and battery terminals clean (see Cleaning Battery and Battery Cables on page 19). Lubricate Unit Apply grease to two front Zerk wheel zerks, steering 25 Hours gear, and pinion. Steering or Every Gear and Season Pinion Zerk...
  • Page 14 4. Mower Deck 5. Electric Clutch Connector 6. Pivot Pin Figure 9 OE0120 28- and 32-Inch Mower Deck (927060, 062) 1. Guide Arm 2. PTO Belt 3. Lift Link 4. Mower Deck 5. Electric Clutch Connector OE0130 Figure 10 GB - 14...
  • Page 15 LEVELING MOWER DECK AND ADJUSTING MOWER DECK PITCH Adjust on a level surface, with tires inflated to correct air pressure (see Specifications on page 25), and mower lift lever in the middle position. Leveling Mower Deck NOTE: Cutting height should be within 1/4 in. (6.35 mm) on each side of mower deck (figure 11).
  • Page 16 NOTE: Perform steps 4 through 6 for 28- and To Lower 32-inch mower decks. Go to step 7 for 40- Front of inch mower decks. Mower Deck To Raise Front of 1. Front Trunnion Mower Deck 2. Front Lift Link OE0034 Figure 14 1.
  • Page 17 1. Remove mower blade from unit (see Mower Blade Replacement on page 16). 2. Adjust all antiscalp rollers to within 1/2 in. (1.27 cm) of ground (figure 19). Gravely recommends having mower blades sharpened by a professional. Contact your Gravely dealer. GB - 17...
  • Page 18 Battery Removal and Installation Remove (Figure 20) NOTE: Tag and mark wires prior to disconnecting. 1. Remove detent pin and tip seat forward. 2. Disconnect operator presence switch wires and remove seat from seat retainer slots. 3. Disconnect negative (–) cable first then positive (+) cable.
  • Page 19 1. Seat 5. Battery Hold Down 9. Negative (–) Cable Bracket 2. Detent Pin 10.Positive (+) Cable 6. Battery 3. Operator Presence 11.Positive (+) Terminal Switch Wires 7. Cross Brace 4. Seat Retainer Slot 8. Negative (–) Terminal Figure 20 OE0028 Cleaning Battery and Battery Cables •...
  • Page 20 5. Install battery on unit (see Battery 2. Loosen jam nut(s) and turn tie-rod(s) Removal and Installation on page 18). clockwise or counterclockwise until the distance between the jam nuts is within Jump Starting the Battery specifications. (Figure 20) 3. Tighten jam nuts. IMPORTANT: The unit used for jump starting 4.
  • Page 21 4. Install PTO belt (see PTO Belt PTO BELT REPLACEMENT Replacement on page 21). Remove (Figure 23) Mower Deck Shown Removed For Clarity 1. PTO Belt 3. Idler 2. Idler Spring 4. Engine Sheave 1. Idler Spring 4. Hydrostatic Transmission Figure 23 OA0023 2.

  • Page 22: Storage

    MOWER BELT REPLACEMENT (927064) 1. Mower Deck 2, 7 2. Belt Cover 3. Right Pulley 2, 3 4. Front Bracket 5. Clutch 6. Idler 7. Left Pulley 8. Mower Belt 9. Idler Spring 10.Clutch Bracket OA0070 Figure 24 Remove (Figure 24) Install (Figure 24) 1.

  • Page 23: Troubleshooting

    5. Connect spark plug wire or plug faulty. replace spark plug. Refer to Engine Manual for detailed instructions. 6. Faulty electrical system. 6. Contact your Gravely Dealer. 7. Faulty engine. 7. Contact your Gravely Dealer. 1. Choke engaged. 1. Disengage choke. Engine 2.

  • Page 24: Service Parts

    Sharpening Mower Blade on page 17) or replace mower blades (see Mower Blade Replacement on page 16). SERVICE PARTS Be sure to always use genuine Gravely parts to keep your unit running like new. Part no. Description 01600600 28-inch mower blade...

  • Page 25: Specifications

    SPECIFICATIONS Model Number 927060 927062 927064 Description 1028 1232 1440 Engine Type Single Cylinder Briggs & Stratton Engine Power – hp (kW) @Max 9.5 (7) 9.5 (7) 13.5 (10) Governed Engaged RPM Max Governed Engaged RPM 3100 Transmission Hydrostatic Speed Forward Max.

  • Page 26: Warranty

    Gravely will be free from defects in material 920-756-2141 and workmanship for a period of two (2) years after the date of purchase. Gravely Fax 920-756-2407 will repair any defect in material or workmanship, and repair or replace any defective www.gravely.com...
  • Page 27 GB - 27...
  • Page 28 Ariens Company 655 West Ryan Street P.O. Box 157 Brillion, WI 54110-0157 Phone: 920-756-2141 Fax: 920-756-2407 www.ariens.com WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer birth defects or other reproductive harm.
