EN
User Manual
L 76684 NWD
Washer Dryer

Advertisement

Table of Contents
loading

Related Manuals for AEG L 76684 NWD

Summary of Contents for AEG L 76684 NWD

  • Page 1 User Manual L 76684 NWD Washer Dryer...

  • Page 2: Table Of Contents

    16. TECHNICAL DATA....................32 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 The appliance shall be installed as a freestanding • product or below the kitchen worktop if space margins permit. Do not install the appliance behind a lockable door, a • sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open.
  • Page 5 ENGLISH Items that have been soiled with substances such as • vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer.

  • Page 6: Safety Instructions

    2. SAFETY INSTRUCTIONS 2.1 Installation • Do not pull the mains cable to disconnect the appliance. Always pull The installation must comply the mains plug. with relevant national • Do not touch the mains cable or the regulations. mains plug with wet hands.

  • Page 7: Product Description

    ENGLISH – If a detergent ball is used, remove • Cut off the mains electrical cable it before starting a drying close to the appliance and dispose of programme. – Do not use a detergent ball if • Remove the door catch to prevent setting a non-stop programme.

  • Page 8: Control Panel

    3.3 Installation on suspended 3.4 Fixing plate kit flooring (4055171146) Suspended wooden floors are Available from your authorised dealer. particularly susceptible to vibration. If you install the appliance on a plinth, To limit vibration we recommend placing secure the appliance in the fixing plates.
  • Page 9 ENGLISH Temperature area: Temperature indicator Cold water indicator Spin area: Spin speed indicator No Spin indicator Rinse Hold indicator 1) Only available for Spin/Drain programme. Dryness level symbols Iron dry Cupboard dry Extra dry Display indicators Door locked - You cannot open the door when this symbol is on. You can open the door only when the symbol goes off.

  • Page 10: Programmes

    Time area: Programme duration (washing and/or drying phase) When the programme starts, the time decreases in one minute steps. Delay start When you press the delay start button, the display shows the delay start time. Alarm codes If the appliance has a malfunction, the display shows alarm codes.
  • Page 11 ENGLISH Programme Maximum load Programme description Temperature range Maximum spin (Type of load and soil level) speed Machine washable wool, hand washa- 1.5 kg ble wool and other fabrics with «hand 1200 rpm Wool/Handwash washing» care symbol 40°C - Cold NonStop 60min.
  • Page 12 Programme Maximum load Programme description Temperature range Maximum spin (Type of load and soil level) speed Drying programme for cotton items. 4 kg Cottons 1) The washing programme Cottons Eco at 60ºC with a load of 8 kg and the drying programme Cottons are the reference programmes for the data entered in the energy label, in compliance with EEC 92/75 standards.
  • Page 13 ENGLISH Programme Time Spin Delay Start Save ■ ■ ■ ■ Delicates 1) If the permanent Extra Rinse option is activated, the appliance adds some additional rinses. In the Rinse programme, if you set a low spin speed the appliance performs delicate rinses and a short spin. 2) If you set the shortest duration, we recommend that you decrease the load size.
  • Page 14 5.3 Timed drying Dryness Level Type of fabric Load Spin Suggested (kg) speed duration (rpm) (mins) Extra Dry Cottons and Linen 1600 165 - 180 For towelling materials (bathrobes, bath towels, etc) 1600 90 - 100 1600 60 - 70...

  • Page 15: Consumption Values

    ENGLISH 6. CONSUMPTION VALUES Stated values are obtained in laboratory conditions with relevant stand- ards. Different causes can change the data: the quantity and type of laundry and ambient temperature. Water pressure, the supply voltage and the temperature of inlet water may also affect the washing pro- gramme duration.

  • Page 16: Settings

    7.4 Drying time Additional spin options: No Spin Press this button to set the time that suits • Set this option to remove all spin the fabrics you have to dry. The display phases. shows the set value. • Set it for very delicate fabrics.

  • Page 17: Before First Use

    ENGLISH 8.3 Permanent Extra Rinse time until the indicator comes on/ goes off. With this option you can permanently You can activate this option: have an extra rinse when you set a new • After you press Start/Pause : the programme.
  • Page 18 10.3 Check the position of the With the flap in the flap position DOWN: • Do not use 1. Pull out the detergent dispenser until gelatinous or thick it stops. liquid detergents. 2. Press the lever down to remove the •...
  • Page 19 ENGLISH 10.6 Starting a programme 1. Press button Start/Pause to set the appliance to pause. without the delay start The related indicator flashes. 2. Press button Delay Start repeatedly Press button Start/Pause to start the programme. until the display shows . The relevant indicator stops to flash and 3.

  • Page 20: Daily Use - Drying Only

    The programme or the delay start 1. If necessary, decrease the spin continues. speed. 2. Press the Start/Pause button. 10.13 End of cycle The appliance drains the water and spins. When the programme has finished, the 3. When the programme is completed appliance stops automatically.
  • Page 21 ENGLISH 2. Load the laundry one item at a time. «Programmes for timed drying» 3. Turn the programme dial to the table). programme applicable for the items • The display shows the set time to dry. The display shows the drying value: e.g.

  • Page 22: Daily Use - Washing & Drying

    12. DAILY USE - WASHING & DRYING To have a good drying the WARNING! appliance does not let you Refer to Safety chapters. set a too low spin speed for the items to be washed and This appliance is an dried.

  • Page 23: Hints And Tips

    ENGLISH For more information see "At the end of • Line dry this type of fabrics at open air the drying programme " of the previous when they are washed the first time. chapter. • Clean the drain filter. • After the drying phase, clean the 1.
  • Page 24 – liquid detergents, preferably for • Check if the drain hose is connected low temperature wash properly. Refer to installation chapter programmes (60 °C max) for all for more information. types of fabric, or special for • For the maximum laundry load of the woollens only.

  • Page 25: Care And Cleaning

    ENGLISH To avoid the static charge at the end of WARNING! the drying cycle: To avoid creasing and 1. Use fabric conditioner in the washing shrinkage do not overdry cycle. the laundry. 2. Use special fabric conditioner for tumble dryers. 13.11 General Tips When the drying programme is Refer to the «Drying programmes»...
  • Page 26 14.5 Cleaning the detergent dispenser 14.6 Cleaning the inlet hose and the valve filter...
  • Page 27 ENGLISH 45° 20° 14.7 Cleaning the drain filter Do not clean the drain filter if the water in the appliance is hot. Regularly check the drain pump filter and make sure that it is clean. Repeat the steps 2 and 3 until the water stops flowing out. 180°...
  • Page 28 14.9 Frost precautions Always keep a rag nearby to dry up any water spillage. If the appliance is installed in an area where the temperature can be less than Make sure that the impeller 0° C, remove the remaining water from of the pump can rotate.

  • Page 29: Troubleshooting

    ENGLISH 15. TROUBLESHOOTING • - The appliance door is open or WARNING! not closed correctly. Please check the Refer to Safety chapters. door! 15.1 Introduction • - The mains supply is unstable. Wait until the mains supply is stable. The appliance does not start or it stops •...
  • Page 30 Problem Possible solution The appliance does not • Make sure that the drain hose is in the correct position. The fill with water and drain hose may be too low. Refer to 'Installation instruction'. immediately. • Make sure that the sink spigot is not clogged.
  • Page 31 ENGLISH Problem Possible solution • Increase the detergent quantity or use a different deter- gent. The washing results are • Use special products to remove the stubborn stains before not satisfactory. you wash the laundry. • Make sure that you set the correct temperature. •...

  • Page 32: Technical Data

    4. Keep the emergency unlock trigger 5. Take out the laundry and then close pulled downward and, at the same the appliance door. time, open the appliance door. 6. Close the filter flap. 16. TECHNICAL DATA Dimension Width/ Height/ Depth/...
  • Page 33 ENGLISH product to your local recycling facility or contact your municipal office.
  • Page 34 www.aeg.com...
  • Page 35 ENGLISH...
  • Page 36 www.aeg.com/shop...
