HOTEL DISPENSER
Model CHD22 /CHD30
Service Parts Manual
Publication Number: 631806054
Revision Date: October 6, 2008
Revision: B
Visit the IMI Cornelius web site at
www.cornelius.com
for all your Literature needs.
CHD22/CHD30 Service Parts Manual
Manual Number 631806054
Advertisement
Table of Contents
Related Manuals for Cornelius Hotel Dispenser CHD22
Summary of Contents for Cornelius Hotel Dispenser CHD22
- Page 1 IMI CORNELIUS INC. www.cornelius.com HOTEL DISPENSER Model CHD22 /CHD30 Service Parts Manual Publication Number: 631806054 Revision Date: October 6, 2008 Revision: B Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs. CHD22/CHD30 Service Parts Manual Manual Number 631806054...
-
Page 3: Table Of Contents
Wiring Diagram for Coin Mechanism Model· · · · · · · · · · · · · · · · · · · · · · · · · · · · Page 13 Schematic Diagram for Coin Mechanism Model · · · · · · · · · · · · · · · · · · · · · · · · · Page 14 Website: www.cornelius.com Telephone Number... -
Page 4: Front And Top Panels
CHD22 and CHD30 Service Parts Item Part Number Number Description 620204172 Gasket tape, order by ft. Use 27.5” for CHD30, 19.5” for HD22 Use 27.88” Use 27.25” for CHD30, 19.25” for HD22 620204214 CHD30 top panel 620204215 CHD22 top panel 620204229 Top panel screw 620204216... - Page 5 CHD22 and CHD30 Service Parts CHD30B & CHD22B Front Panel Item Part Number Number Description 620204231 Screw 620204188 CHD30 stiffener 620204189 CHD22 stiffener 620204224 Retainer 620204209 CHD30 side flange 620204210 CHD22 side flange 620204712 CHD30 Front panel* 620204713 CHD22 Front panel* 620204237 Snap bushing 620204222...
- Page 6 CHD22 and CHD30 Service Parts CHD30N and CHD30W Front Panel & Related Parts Item Part Number Number Description 620204261 Water inlet fitting 620204262 Straight connector 620204221 Pal nut 620204264 Male elbow connector 620204213 Water faucet 620204258 Tubing, order per ft 620204265 Shut off valve 620204200...
-
Page 7: Side, Back And Interior Panels
CHD22 and CHD30 Service Parts Side, Back and Interior Panels Item Part Number Number Description 620204720 Screw 620204279 CHD30 back panel 620204203 HD22 back panel 620204278 Right side panel, includes mounting hardware 620204220 Screw 620204281 Bin support, right 620204280 Bin support, left 620204178 Drain fitting 620204187... -
Page 8: Dispensing Components
CHD22 and CHD30 Service Parts Item Part Number Number Description 620204232 Hitch pin 620204212 Sweep arm 620204723 Dispense rotor 620204732 Hub plate 620204272 CHD30 bin assembly 620204273 CHD22 bin assembly 620204260 Insulation pad 620204235 Loop clamp 620204724 Screw 620204259 Insulation for hub 620204253 Dispense gearmotor, dual voltage... -
Page 9: Ice Chute Mechanism
CHD22 and CHD30 Service Parts Item Part Number Number Description 620204199 Clip 620204720 Screw 620204192 Bracket 620204182 Door lock 620204181 Door 620204206 Wire 620204180 Dispense chute 620204240 Vend switch Ice Chute Mechanism Page 7... -
Page 10: Ice Catch Pan
CHD22 and CHD30 Service Parts Item Part Number Number Description 620204283 Screen 620204726 Screw 620204174 Drain top 620204727 Complete assembly as shown 620204256 O-ring 620204177 Drain bottom 620204263 Drain fitting 620204198 Drain pan bracket 620204218 Foam pad 620204197 Drain guard Ice Catch Pan Page 8... -
Page 11: Control Box
CHD22 and CHD30 Service Parts Item Part Number Number Description 620204244 Coin mech timer 620204223 Screw 620204245 Adjustment module 620204720 Screw 620204234 Loop clamp 620204728 Snap bushing 620204729 Free vend switch 620204236 Strain relief 620204242 60 Hz off cycle timer 620204243 50 Hz off cycle timer 620204282... -
Page 12: Wiring Diagram, 115 Volt, 60 Hz Basic And Water Station
CHD22 and CHD30 Service Parts Wiring Diagram, 115 volt, 60 Hz Basic and Water Station 17-2956-01 ALL CONTROLS SHOWN IN NORMAL ICE DISPENSING MODE EARTH GROUND INLET POWER CORD OFF CYCLE AGITATION TIMER 6 HOURS OFF 3 SEC. ON ADJUSTABLE USE COPPER CONDUCTORS ONLY DISPENSING SWITCH... -
Page 13: Schematic Diagram, Basic And Water Station Models
CHD22 and CHD30 Service Parts Schematic Diagram, Basic and Water Station Models DISPENSING SWITCH OFF CYCLE AGITATION ADJ. TIMER 6 HOURS OFF 3 SEC. ON GEARBOX MOTOR INTERLOCK SWITCH Page 11... -
Page 14: Wiring Diagram, 230 Volt, 50 Hz Basic
CHD22 and CHD30 Service Parts Wiring Diagram, 230 volt, 50 Hz Basic 17-2987-01 ALL CONTROLS SHOWN IN NORMAL ICE DISPENSING MODE EARTH GROUND INLET POWER CORD OFF CYCLE AGITATION 6 HOURS OFF TIMER 3 SEC. ON ADJUSTABLE USE COPPER CONDUCTORS ONLY DISPENSING SWITCH BK/W... -
Page 15: Wiring Diagram For Coin Mechanism Model
CHD22 and CHD30 Service Parts Wiring Diagram for Coin Mechanism Model 17-2967-01 EARTH GROUND INLET POWER CORD OFF CYCLE AGITATION TIMER: 3 SEC. ON 6 HRS. OFF (ADJ.) ADJ. COIN MECHANISM TIMER W/BU USE COPPER CONDUCTORS ONLY FREE VEND DISPENSING SWITCH (2) 15K OHM 2 WATT... -
Page 16: Schematic Diagram For Coin Mechanism Model
CHD22 and CHD30 Service Parts Schematic Diagram for Coin Mechanism Model COIN MECH. SWITCH FREE VEND SWITCH (2) 15K OHM 2 WATT RESISTOR COIN MECH. INDICATOR LIGHT DISPENSING SWITCH Page 14 OFF CYCLE AGITATION ADJ. TIMER COIN MECH. ADJ. TIMER GEAR MOTOR INTERLOCK...
