- Page 1 28KF-84H 32KF-84H COLOUR TELEVISION OPERATION MANUAL Please read this operation manual carefully before using the colour television. PRINTED ON ENVIRONMENTALLY FRIENDLY PAPER...
-
Page 2: Terms Of Guarantee
4. In the unlikely event of that your equipment should require repair, please contact the dealer or supplier from whom it was purchased. 5. The cost of carriage to and from the Dealer, Supplier or Sharp approved Service Facility shall be borne by the purchaser. -
Page 3: Safety Precaution
TV set and the stand, table or track. The tube of your TV has a special coating. Do not knock or rub on the tube face with sharp or hard surfaces, otherwise you will damage the coating. To prevent damaging the surface of... -
Page 4: Table Of Contents
Dear SHARP Customer Congratulations! You are now the proud owner of a SHARP Colour Television Receiver. To ensure proper operation, please read this manual carefully. After reading, keep this manual in a safe place for future reference. Contents Terms of guarantee ... 1 Safety precaution ... -
Page 5: Remote Control Buttons
Remote control buttons 1. Stand-by ON/OFF switch (TV) Video 2. Power ON / OFF switch (VCR) 3. Digit buttons 0 ~ 9 4. Flashback button Teletext 5. Green button 6. Red button 7. Volume Down/Cursor control Left 8. Menu button Teletext 9. -
Page 6: Controls And Terminals
Controls and Terminals FRONT TV Main Power On/Off Switch Power Indicator Remote Control Sensor Door HOW TO OPEN THE DOOR Put the finger in the lower part of the door and press upward. Behind the door Volume Button (DOWN) Volume Button (UP) -
Page 7: Typical Connections (Aerial, Vcr, Dvd, Etc.)
Typical Connections Aerial connection - TV set only - BACK OF TV Aerial Connections - TV and VCR - BACK OF TV AV/TERMINAL (AV-1) Scart Lead (Not supplied) BACK OF VCR Audio/Video Note: For further details, please refer to operation manual of your VCR. - Page 8 Typical Connections (Continued) Connections - TV, DECODER and VCR (Videorecorder) - BACK OF TV Euro AV/TERMINAL SCART (AV1) (RGB) Scart lead (Not supplied) BLACK OF VCR Audio/Video Note: For further details, please refer to operation manuals of your DECODER and VCR.
- Page 9 Typiccal Connections (Continued) Connections - TV, DVD Player and Digital Set Top Box - BACK OF TV AV/TERMINAL Euro (AV 1) SCART (RGB) Aerial Lead (Not supplied) RF OUT TV SCART Note: For further details, please refer to operation manuals of your DVD Player and Digital Set Top Box.
- Page 10 Typical Connections (Continued) Connections - TV, VCR and Digital Set Top Box - BACK OF TV Euro AV/TERMINAL SCART (AV1) (RGB) Scart Lead (Not supplied) RF OUT BACK OF VCR Audio / Vídeo Aerial Lead (Not supplied) RF OUT TV SCART Note: For further details, please refer to operation manuals of your VCR and Digital Set Top Box.
- Page 11 WIEW CAM Audio Input Terminal (right) Note: For further details, please refer to operation manual of your Video Camera. Connection-TV power cable to a 220 ~ 240 V system - BACK OF TV Mains Socket Outlet AC 220~240 V, 50 Hz...
-
Page 12: Auto Installation
Your television set is provided with an Automatic Installation System which makes Installation easier. This new system is activated when you turn on the TV for the first time. Note: You may not have to follow this procedure if it has already been done for you at the establishment where you purchased your TV. - Page 13 BLUE button With these options, you will be able to organise the real channels (CH **) memorised in the TV programmes (Pr 01 ... Pr 99) and put them into your own preferred order. The following is a detailed explanation of options a), b), c), d) and e).
-
Page 14: Switching On
TV) again and the TV will return to Stand-by mode. Blue back off timer If noise appears in TV or VCR mode, the screen turns blue. The blue back off-timer is then engaged and will automatically switch the set to Stand-by mode after 15 minutes. -
Page 15: Tv Operation (Channel Selection)
TV Operation Channel Selection Channel selector CH ù /CH Ù buttons Select the programme channel number you want to see, using the channel selector buttons ( As you press these buttons a list of channels appears. Press the again to select another channel. -
Page 16: Menu Structures
Menu Structures This TV set has: a MAIN MENU with four basic menus, which permit access to the different functions of the TV. These menus are as indicated below. By pressing the MENU Button Menu CONTRAST COLOUR BRIGHTNESS SHARPNESS PICTURE... -
Page 17: Picture Adjustments
Picture Adjustments Picture quality (CONTRAST, COLOUR, BRIGHTNESS, SHARPNESS, NORMALISE, TINT CONTROL, ECO MODE, NOISE REDUCTOR, BLACK STRETCHER, ROTATION and SVM) are adjustable in this menu. Press the MENU button to see the MAIN Menu. MAIN Menu Press the MENU button to see the PICTURE Menu. -
Page 18: Eco Mode
ECO MODE Select «ECO MODE» and press the Cursor LEFT/RIGHT buttons to reduce contrast in areas of the picture those are excessively white (ON or OFF). NOISE REDUCTOR Select «NOISE REDUCTOR» and press the Cursor LEFT/RIGHT buttons to reduce the noise when receiving a weak signal and improve the picture quality (OFF, AUTO, MEDIUM or HIGH). -
Page 19: 100 Hz Fast Menu
Settings. Press the BLUE button «EXIT» to quit the Menu. STILL Mode In this mode the TV set freezes the picture. You can also enter to the following functions: «STILL» ON/OFF by RED button «SCOPE» ON/OFF by GREEN button «PICTURE MODE»... -
Page 20: Wide Mode
* AUTO mode (VPS code): The VPS signal is sent by some broadcasting stations with information of the original size. When the TV is in AUTO mode and receives the VPS signal, it changes the size automatically as indicated below: When the TV is receiving VPS code 16:9 the TV selects CINEMA automatically. - Page 21 Wide Mode (Special detail information) Special detail information about PANORAMA, FULL, NORMAL, ZOOM 14:9 and CINEMA (16:9). 16:9 PANORAMA The Panorama Mode adapts the broadcast picture to 16:9 format without changing the centre of view. This is especially useful for programmes like the News when the speaker in the centre of the picture needs to be seen clearly.
-
Page 22: Audio Adjustments
Note: See the -SOUND MODE- (page 23) to change the Sound Mode in the headphones. External source: When you are watching the TV-set through the Euro-SCART, AV-1 or S-Video terminals, the Sound Mode Selector button is not operative. MONO... -
Page 23: Sound Setting Mode
Sound Setting Mode Sound qualities are adjustable in this menu. 1. Press the MENU button to see the MAIN Menu. 2. Press the Cursor DOWN button 3. Press the MENU button to see the SOUND Menu SOUND Menu 4. Press the RED button to select «LOUDSPEAKERS»... - Page 24 If the source feed is STEREO, it produces a spatial effect, expanding the stereophonic image. «SOUND IDENTIFICATION» IDENTIFICATION ON: The TV automatically identifies the received audio system MONO FM, STEREO or DUAL SIGNAL. IDENTIFICATION OFF: Disqualifies the automatic identification of the audio system and forces the sound into MONO FM.
-
Page 25: Features Setting Mode
The selected item will appear on screen in white letters on a blue background. «OTHER FUNCTIONS» Menu «ON TIMER» The On-Timer is used to automatically switch on the TV set during the day. If necessary, repeat steps 1. to 4. to see the «ON TIMER» Menu. 5. Press the Cursor RIGHT button time) in white letters. -
Page 26: Child Lock (Channel Block)
«LOCK ALL» or to specific programmes «LOCK PROGRAMME». With the CHILD LOCK function, you can also programme a time period during which the TV will be protected. (Your children cannot select the channel, which you locked). -
Page 27: Demo
LOCK programmes to avoid malfunction when a new program is set. Notes: In order for the timed protection to function correctly, the internal TV clock must be set at the right time. To check the time setting, see section -Automatic or Manual time adjustment- on page 24. -
Page 28: Postcode Security
Postcode Security This option allows you to set a code (Postcode), which will be displayed at TV switch on time. There is a Password (PSW) to change the code. SET PASSWORD AND POSTCODE 1. Press the MENU button to see the MAIN Menu. - Page 29 7. Enter the 4-digits using the number buttons 0 to 9 to set the new Password. Password set (confirmation) 8. When the new Password is first entered, the TV will ask for confirmation. If this is the case, press the BLUE button Then the "ENTER CODE"...
-
Page 30: Tv Channel Setting (Advanced)
The TV is ready to preset automatically all local channels for you. If the TV is being used with a VCR, turn on the VCR and play back a pre-recorded tape. The signal from the RF terminal of your VCR is assigned to a TV channel. -
Page 31: Manual Channel Preset
Manual Channel Preset (Preset using real channel numbers) Select the programme channel number you want to preset with the 0 ~ 9 digit buttons. Press the MENU button to see the MAIN Menu. MAIN Menu Press the Cursor DOWN button F to select «INSTALL AND TUNE». - Page 32 Manual Channel Preset (Preset using frequency tuning) Select the programme channel number you want to preset with the 0 ~ 9 digit buttons. Press the MENU button to see the MAIN Menu. MAIN Menu Press the Cursor DOWN button F to select «INSTALL AND TUNE».
-
Page 33: After Preset Has Been Performed (Fine-Tuning)
Repeat the above procedure for other programme channels as required. MODE This feature allows you to select TV, VCR, SKIP. First follow the above steps 1., 2., 3., and 4. The TUNE Menu will appear on screen. 5. Press the Cursor DOWN button F to select «MODE». - Page 34 BLUE button With these options, you will be able to organise the real channels (CH **) memorised in the TV programmes (Pr 01 ... Pr 99) and put them into your own preferred order. «Edit this program» Edit name mode...
-
Page 35: Tv/Video Selector, Clock Button, Headphone Jack And Sub-Titles Button
Other Features TV/Video selector button With this button you can select either source of input for the TV. When the TV/VIDEO button menu appears and TV mode changes to VIDEO mode. The screen is displayed in the last VIDEO mode. -
Page 36: Vcr Mode
VCR mode SHARP VCR can be operated using the TV remote control. Channel selector buttons (VCR) These buttons are used for changing channels and setting the timer. Play button Press this button to start playback. Record button Press this button to start recording. If the videocassette is protected against recording, it will be ejected. -
Page 37: Teletext Mode
Teletext features Depending on the TV programme, the Teletext pages are transmitted using different system. Your SHARP TV is adjusted to receive 2 Teletext systems, namely FLOF and LIST, which are automatically identified by the receiver. The user can easily identify them by the manner in which they appear on the screen. - Page 38 You can use this button together with the display CANCEL button Note: picture until the subpage has been found. The on screen TV icon in the top left side of the screen will show «TXT». When the subpage has been found, the screen will change to the subpage number.
- Page 39 How to Operate Page Memory Your TV has 40 teletext page number memories for fast recall of teletext information. In programme positions 1 through 9, four teletext page numbers can be stored in each position; a total of 36 pages.
-
Page 40: 21-Pin Euro-Scart And 21-Pin Audio/Video
21-pin Euro-SCART and 21-pin Audio/Video REAR TV 21-pin In/Out 1. 21-pin Audio/Video (AV-1) With PAL/SECAM/NTSC/S-Video Input 2. 21-pin Euro SCART (RGB) With PAL/SECAM/NTSC Video Input RF Input 3. Aerial terminal 21-pin Euro-SCART (RGB) Audio right output Audio right input Audio left output... -
Page 41: Troubleshooting
If the fault cannot be corrected by using this guide, remove the mains plug from the wall socket and contact the dealer or supplier from whom it was purchased. Where this is not possible, please visit our web-site at www.sharp.co.uk/support. -
Page 42: General Specifications For Television Receiver
General Specifications for Television Receiver Models: 28KF-84H and 32KF-84H Receiving Broadcast Standard Receiving Channel Receiving System Colour System: PAL (SECAM and NTSC playback through the AV Inputs) Field Frequency: 50/60 Hz Capability Power Source Power Consumption at 240V AC 50Hz... -
Page 43: Index Page
Effects (Sound) ... 23 Equalizer ... 22 Features Setting Mode ... 24 Fine tuning ... 32 FLOF (Teletext) ... 36 Front TV ... 5 Headphone jack ... 34 Identification (Sound) ... 23 LIST (Teletext) ... 36, 37, 38 Loudness ... 22 Main power button ... - Page 44 PASSWORD POSTCODE SECURITY TV SHARP 28/32KF-84H SHARP ELECTRÓNICA ESPAÑA, S. A. SHARP ELECTRONICS (U.K.) LTD. Sharp House, Thorp Road, Newton Heath, Manchester M40 5BE PRINTED IN SPAIN TINS-A828WJN0 06/03...
