COOPER LIGHTING - SURE-LITES
CC3
CC4
CC5
CC6
C o n t r a c t o r 's C h o i c e
E M E R G E N C Y L I G H T
• Dual-voltage input
120/277VAC, 60Hz, isolation
transformer
• Injection-molded, color-
stable, high-impact UL-94-5V
rated polycarbonate housing
and mounting plate (Housing
is tethered to mounting
plate)
• Designer-white textured
finish
• Two PAR36 type lamps in
fully adjustable high-impact
polycarbonate lampholders
• Sealed lead calcium
maintenance free battery
• Cutouts provided for surface
conduit on top
• Universal J-box mounting
pattern, keyhole slots
• Remote Capability
CC5, CC6
• Line-Latching, Solid-State
Voltage Limited Charger,
Solid-State Switching, Low-
Voltage Disconnect,
Brownout Circuit,
Overload/Short Circuit
Protection, Test switch/power
Indicator light
• UL 924 Listed, UL Damp
Location Listed (CC5SD
Only), Life Safety NFPA 101,
CSA Certified, NEC/OSHA,
most state and local codes
616
COOPER LIGHTING
D E S C R I P T I O N
The CC Series Contractor's Choice
Emergency Lighting Unit is the ideal
choice when a simple installation and
a reasonable cost are required. Its
contemporary round corner styling,
designer white finish, and consistent
family appearance enables it to blend
with any decor. The components are
injection molded from tough
polycarbonate materials which resist
discoloration due to age and ultraviolet
radiation.
E L E C T R I C A L R AT I N G S
Rated Wattage
Model
DC Voltage 1 1/2 hours
CC3
6
10.8
CC3 NC
6
16
CC4
6
18
CC4 NC
6
18
CC5
6
27
CC5 NC
6
24
CC6
6
32
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : C C 5 W H S D
Housing
Model
Finish
Number
(Must be
CC3
specified)
CC3NC
(4)
WH=White
CC4
BK=Black
CC4NC
(4), (6)
CC5
CC5NC
(4), (6)
Voltage
CC6
Blank=120/277
347=120/347 VAC
E n e r g y D a t a
Input Current (Max.):
Model No.
120V
277V
347V
CC3
.12A
.05A
.01A
CC4
.12A
.05A
.01A
CC5
.13A
.06A
.06A
CC6
.13A
.06A
.06A
(1)
Provision for one meter only.
(2)
Consult your Cooper Lighting Representative.
damp location standard.
(6)
CC4NC, CC5NC not available in SD.
®
D I M E N S I O N S
to 87 1/2% of rated D.C. Voltage
2 hours
3 hours
4 hours
7.2
-
-
-
-
-
15
10
8
24
18
14
-
-
-
Options
Accessories
(add as suffix)
(Order separately)
MRT=MR16 Heads (5W
WG1 =Wire Guard
Standard CC3,
WG2 =Wire Guard (use
CC3NC; 9W
for heads adjusted at
Standard CC4, CC5,
45° or greater)
and CC6)
VS1=Polycarbonate
SQ=Square Head (5.4W
Vandal Shield
Standard)
VS1WP=Polycarbonate
Vandal Shield
A=Ammeter
(1)
Weather
SD=Self-Diagnostics
(3), (5), (6)
Resistant
V=Voltmeter
(1)
CSK120=Cord Set 120V
TDM=Time Delay Monitor
Alternate Lamps
(2)
Other Options
(2)
(3)
13"
(330mm)
6 3/8"
(162mm)
17 1/2"
(445mm)
4 3/4"
(121mm)
SURE-LITES
Lamp Information
Type
Wattage
Incandescent
5.4
Incandescent
5.4
Incandescent
9
Incandescent
9
Incandescent
9
Incandescent
9
Incandescent
9
Not available w/CC6.
(4)
NC=Nickel Cadmium Battery.
Number
29-121
29-121
29-84
29-84
29-84
29-84
29-84
(5)
CC5SD is
