COOPER LIGHTING - SURE-LITES
RD SERIES
Tw o I n j e c t i o n M o l d e d
T h e r m o p l a s t i c H e a d s
RLM SERIES
Tw o H i g h - I m p a c t
T h e r m o p l a s t i c H e a d s
R e c e s s e d H o u s i n g
E M E R G E N C Y L I G H T
• Dual-voltage input
120/277VAC, 60Hz
• 20 gauge die-formed steel
housing with white powder
coat finish
• Heads match housing
finish
• Knockout, conduit or cord
set
• Supplied with hanger bars,
T-Bar clips
• Single modular electrical
connector
• Remote capability
• Line-latching, Solid-State
voltage limited charger,
Solid-State switching,
low- voltage disconnect,
brownout circuit,
overload/short-circuit
protection, test
switch/power indicator
light
• UL 924 Listed, Life Safety
NFPA 101, NEC/OSHA,
most state and local codes
606
COOPER LIGHTING
D E S C R I P T I O N
The RD Series is a recessed
emergency lighting system
designed for locations where
aesthetics are of utmost
importance. The housing is
fully recessed in dry wall or
grid ceiling installations.
Designer pinchback heads
rotate 358° and swivel 90° to
0°. Ideal for commercial and
institutional environments
where easy recessed
installation and minimal
maintenance are desired.
The RLM Series is a recessed
system packaged in an
attractive flame-resistant
metal housing. It is the unit
of choice for installations
where a recessed product is
desired and the size and cost
of emergency lighting must
be kept to a minimum
without sacrificing
dependability or light output.
E L E C T R I C A L R A T I N G S
Rated Wattage
Model
Battery
DC Voltage
RD1
SLC
6
RD3
SLC
6
RD4
SLC
12
RD6
SNC
6
RD7
SNC
6
RLM1
SLC
6
RLM2
SLC
6
RLM3
SLC
6
RLM4
SLC
12
RLM8
SNC
6
RLM9
SNC
6
SLC=Sealed Lead Calcium Battery
SNC=Sealed Nickel Cadmium Battery
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : R D 1 V
Options
Model Number
(Add as suffix)
RD1
A=Ammeter
(2)
RD3
SD=Self-Diagnostics
RD4
TDM=Time Delay Monitor
RD6
V=Voltmeter
RD7
Alternate Lamps
RLM1
Other Options
RLM2
RLM3
RLM4
RLM8
RLM9
E n e r g y D a t a
Input Current (Max.):
Model No.
120V
277V
RD1, RD3
.12A
.05A
RD4, RLM4
.30A
.13A
RD6
.06A
.03A
RD7
.07A
.04A
RLM1, RLM2, RLM3
.12A
.05A
RLM8
.06A
.03A
RLM9
.07A
.04A
(1)
Consult your Cooper Lighting Representative.
®
D I M E N S I O N S
4 5/8"
(118mm)
6 1/4" (159mm)
9 1/4" (235mm)
8 1/4"
(210mm)
5 1/8"
(130mm)
10 1/4" (260mm)
12 7/8" (327mm)
to 87 1/2% of rated D.C. Voltage
1 1/2 hours
2 hours
3 hours
4 hours Type
18
15
10
27
24
18
14
54
-
-
15
12
8
24
18
12
10
10.8
7.2
-
18
15
10
27
24
18
14
54
-
-
15
12
8
24
18
12
10
Accessories
(Order separately)
WG2 =Wire Guard
WG7 =Wire Guard
VS=Choose polycarbonate
vandal shield desired
(2)
from accessories
(1)
sheet
(1)
(2)
Provision for one meter only.
8 1/4"
(210mm)
3 1/2"
(89mm)
7" max.
(178mm)
5 1/8"
(130mm)
10 1/4" (260mm)
12 7/8" (327mm)
4 5/8"
(118mm)
3 1/2"
6"
(RLM4 Only)
(89mm)
(152mm)
9 1/4"
(235mm)
6 1/4"
(159mm)
9 1/4" (235mm)
Lamp Information
Wattage
8
Tungsten Halogen
6
Tungsten Halogen
12
-
Incandescent
9
6
Tungsten Halogen
6
Tungsten Halogen
12
-
Incandescent
5.4
8
Incandescent
9
Incandescent
9
-
Incandescent
9
-
Incandescent
7.2
Incandescent
7.2
6"
(RD4 Only)
(152mm)
Number
29-12
29-66
029-86
29-12
29-66
29-121
29-84
29-84
029-86
29-88
29-88
