- Page 1 GRAVITY DISCHARGE TOILET OWNER’S MANUAL Dometic 3200 Series All-Ceramic Toilets WARNING This manual must be read and under- stood before installation, adjustment, service, or maintenance is performed. Modification of this product can result in property damage.
-
Page 2: Table Of Contents
4. Make sure all guests understand operation of the toilet. TOILET MODEL IDENTIFICATION The model identification label is located on the inside wall of the toilet under the access cover. It will show the model number and serial number. Dometic is a registered trademark of Dometic Corporation. -
Page 3: Toilet Dimensions
• 1/2-inch (12.7 mm) water line terminating in 1/2-inch MPT fitting (to connect to toilet water supply hose). • 4-bolt floor (closet) flange. Dometic flanges available include 3-inch spigot, socket, MPT, or 45-degree swivel socket. • 12 VDC through 2-amp fuse or circuit breaker. Use 14-gauge stranded copper wire. - Page 4 STEP 5a: For through-the-floor water line and electrical wires, mark another centerline 6 inches (152 mm) from Below-Floor Installation the back wall (fig. 4). Fig. 4 STEP 5b: For through-the-wall water line and electrical Above-Floor Installation wires, mark a centerline 8 inches (203 mm) up from the floor centerline (fig.
- Page 5 STEP 9: WITH THE ELECTRICAL POWER OFF, route STEP 13: Temporarily set the toilet in place on the floor #14 gauge stranded copper wire from 12 VDC ground flange (fig. 14). and positive 12 VDC from the fuse panel through a 2-amp fuse or circuit breaker.
-
Page 6: Toilet Operation
4. Never use drain openers, alcohol, solvents, etc. in the toilet. 5. If the toilet does not function properly, refer to the Troubleshooting section of this manual and repair as neces- sary. If problem persists, contact your local Dometic product dealer or see the Customer Service section of this manual. -
Page 7: Proper Cleaning And Maintenance
® Teflon is a registered trademark of DuPont Co. ® WD-40 is a registered trademark of WD-40 Company. WINTERIZING At the end of each traveling season, the Dometic toilet should be winterized for storage by using potable water-safe antifreeze in the system. To use antifreeze: 1. -
Page 8: Deodorants And Special Tissue
DEODORANTS AND SPECIAL TISSUE Your Dometic toilet requires the regular addition of a deodorant product to reduce malodors and to help break down holding tank contents. Several factors should be considered in selecting a deodorant product. Liquid or Dry: Liquid products obviously work more quickly by readily going into solution. Granulated powder formulations, on the other hand, have the advantage of requiring less storage space and are less likely to leak if the package is inadvertently damaged. -
Page 9: Flush Mechanism Components
FLUSH MECHANISM COMPONENTS 3. Lift china toilet 1. To access base straight up from base assembly components, remove decorative screw and set it down just in front of floor flange. caps and unscrew two Turn off water to bolts that hold china toilet toilet and disconnect to floor. -
Page 10: Troubleshooting
Possible Cause Service Instructions 1. Toilet emits odor (flush ball a. Odor emitting from base of toilet. a. Use Dometic brand deodorants. open). b. Plugged holding tank vent line. b. Clear obstructions from vent line. 2. Water will not stay in bowl. -
Page 11: Wiring Diagram
TOILET ORDERING PARTS Dometic is ready to assist you in the event service is required. Before calling, please have the following informa- tion available. Your cooperation in having this information ready is appreciated and allows us to better meet your needs. -
Page 12: Customer Service
If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
