Sanyo PLC-EF12N Specifications

3700 ANSI LUMENS
PLC-EF12N
SXGA Multimedia Projector
DIRECT PC INTERFACE WITH PANELLINK™ TECHNOLOGY
Utilizing PanelLink™ protocol, the PLC-EF12N offers a true
digital connection to a PC. SANYO digital interfacing greatly
reduces ghosting, noise and signal degradation. It also allows
for longer cable runs and eliminates the need for complicated
adjustments such as dot clock ro synchronization of frequencies,
enabling true plug and play compatibility with PCs!
DIGITAL PROGRESSIVE SCANNING
Proprietary SANYO digital progressive scanning doubles the
video information being sent to the projector, substantially
increasing video-image detail and resolution. Each pixel is
monitored using SANYO's original motion detection algorithm to
ensure increased vertical resolution and crisper moving images.
POWER LENS SHIFT
Results in minimal geometric distortion for up/down image
alignment when twin stacking.
SUPERIOR HDTV PERFORMANCE
HDTV Compatible, accepting the 1080i, 1035i, 720p, 575p, 575i,
480p, and 480i HDTV resolution standards.
WIDE ARRAY OF LENS OPTIONS
Seven lenses are available to provide tremendous placement
flexibility.
*
Optional Lenses sold separately
ALSO AVAILABLE: PLC-EF12NL
Same features as PLC-EF12N except unit is shipped without a
lens. Purchaser can select from a variety of optional lenses
PRESENTATION TECHNOLOGIES
21605 Plummer Street
Chatsworth, CA 91311
Ph: 818.998.7322 ext. 288
Fax 818.717.2719
www.sanyolcd.com
TRUE SXGA
l
Type
Brightness
Uniformity
LCD Panel System
Number of Pixels
Contrast Ratio
Projection Image (diagonal)
Aspect Ratio
Throw Distance
Zoom/Focus
Keystone Ratio (up/down)
Power Lens Shift
Projection System
Projection Lens
Projection Lamp
Scanning Frequency
Color System
Computer Compatibility
Sound Output
Voltage
BTU
dB Rating
Dimensions (WxHxD)
Net Weight
Warranty
User Maintenance
Computer Input Panel 1
Computer Input Panel 2
A/V Input Panel
Included Accessories
Optional Accessories
PRELIMINARY SPECIFICATION SHEET ONLY Because its products are subject to
continuous improvement, SANYO reserves the right to modify product design and
specifications without notice and without incurring any obligations.
Standard Standard
Zoom 1 Zoom 2
Part No. LNS-S01 LNS-S02
Zoom Yes
Throw 1.8 - 2.9:1 2.0 - 2.6:1
Ratio
F Stop 2.6 - 3.5 2.0 - 2.3
Length 6.9"
Weight 3.74 lbs. 4.2 lbs.
MULTIMEDIA PROJECTOR
l
S p e c i f i c a t i o n s
Nearly 7,400 ANSI Lumens when twin-stacked
Auto - H. Sync. 15-100kHz, V. Sync. 50-120Hz
Optional Lens Specifications
Wide
Fixed Wide Zoom
LNS-W01 LNS-W02KS
Yes No Yes
1.2:1 1.35 - 1.8:1
2.5 2.53 - 2.95
8.0" 9.4" 8.3"
12.8 lbs. 4.8 lbs.
SXGA (1280 x 1024) Multimedia
3700 ANSI Lumens
Over 85%
1.8" TFT polysilicon type x 3
3,932,160 (1,310,720 x 3)
500:1
40" – 600"
5:4
5.0' to 107'
Powered
1:1
10 Up/Down from center
Polarized beam splitter with integrator lens
F2.0 to 2.3; f3.0" to 3.8"
Throw Ratio 2.0 - 2.6:1
440W DC Metal Halide
PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
Compressed UXGA, SXGA, XGA,
SVGA, VGA, MAC, PC98
Two-piece, 3-watt Stereo
100-240V AC; 50/60/Hz (auto sense/select)
2218
48.0
15.4"x9.2"x22.9"
39.2 lbs.
Three years parts and labor; 90 days lamp;
Quick Repair Program under warranty
Clean air filter, replace lamp assembly
MDR 20-pin Terminal (digital) D-Sub 15
12-pin control port and USB port
5 BNC (RGBHV)
12-pin control port and USB port
BNC Type {Video/Y, C/Cb (B-Y), Cr (R-Y)} x 2
RCA Type (Audio R and L) x 2 S-Video x 2
Wireless and Wired Remote AC Power Cord
3 Mouse Control Cables (PS/2, Serial, ADB)
VGA Computer Cable VGA-MAC Adapter
Wired Remote Cable Digital Flat Panel Cable
PCI Graphic Accelerator Board & Software
Lens Cap Dust Cover Owner's Manual
Digital Graphics Accelerator PC-Card
ATA Shipping Case (PLCCSE07)
Semi-Long Long
Zoom Zoom
LNS-M01 LNS-T02
Yes Yes
3.5 - 4.6:1 4.6 - 6.0:1
2.0 -2.6 2.0 - 2.8
6.9" 9.4"
4.2 lbs. 6.8 lbs.
Long
Fixed
LNS-T01
No
7.0:1
2.0
8.6"
8.4 lbs.
