- Page 1 Dishwasher GSN 9120 Instruction Manual...
- Page 2 Welcome Dear customer Congratulations on your choice of a Blomberg quality dishwasher which has been designed to give you lasting service. Please read these instructions before installing the dishwasher and using it for the first time. The information contained herein is provided to avoid accidental risks and/or damage to your appliance Make sure you understand the controls prior to using your appliance.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Know your dishwasher / 6. Operating the dishwasher specification Hot Air Drying Standards and testing information / EC Declaration of conformity 7. How to clean your machine 23 Upper spray arm 2. Warning and safety Lower spray arm information 8. -
Page 4: Know Your Dishwasher / Specification
Know your dishwasher / specification ��������� �������� �������������� ����� ������������ ��������� ������������������������ ��������������� ���������������� ��������� ������������������� ����� ������������ ��������� �������������� ������� ������������������� ������������� ��������� ���������� ��������� ������������������ ����� ������������������������������� �������������������������� ������������������������ � ������������������������� �������������������� ������������������� ����������������� �������������� ����������� ��������������� ���������������� 5 GB... - Page 5 Specification Load Capacity : 12 Place settings Height : 850 mm Width : 598 mm Depth : 598 mm Depth/Height : 570 mm / 820 mm (without worktop) Net weight : 47 kg Supply voltage : 220-240 V ~ 50 Hz Fuse currrent : 13 A Total power...
-
Page 6: Warning And Safety Information
Warning and safety information Electrical Safety Keep detergents out of children’s reach and do not put detergent in the The dishwasher should only be machine until right before you start the operated on the voltage specified. For washing programme. electrical safety, only earthed plugs and sockets should be used. -
Page 7: Recycling
Please dispose of the packaging Directive 2002/96/EC in order to be material and old appliances carefully. recycled or dismantled to minimize its Please ensure old machines do not impact on the environment. For further become a threat to child safety. It is information, please contact your local or known that children lock themselves regional authorities. -
Page 8: Before First Use
Iron and cast iron objects can rust and Installation stain other items. When deciding on where to install Pay special attention to whether or not your new dishwasher, ensure that the the item you wash in the dishwasher is position of your dishwasher makes it dishwasher-proof. -
Page 9: Important
Destroy the old plug, which is cut off as ���������������� a plug with a bared cord could cause a �������� shock hazard if inserted into a socket elsewhere in the house. The moulded plug on this appliance incorporates a 13A fuse. Should the fuse need to be replaced an ASTA approved BS1362 fuse of the same rating must be used. -
Page 10: Water Inlet Hose Connection
Water inlet hose connection Drain Hose Connection Make sure your plumbing is suitable to Fit the drainage hose of your machine install your new dishwasher. If in doubt to the drainage pipe without bending. contact a qualified plumber. Secure your hose firmly to the waste The appliance must be connected pipe to avoid it coming off during the to the water mains using the new... - Page 11 Installation of dishwasher tap and a drain. Remove all packaging before When inserting the machine, ensure positioning the machine. that the water inlet and drain hoses are not linked or squashed. See the following diagram. Ensure there is a clearance each side of the Care must be taken to ensure that machine to allow slight side ways the appliance does not stand on the...
-
Page 12: How To Use
When the appliance is correctly levelled, the door will not catch on the inner liner on either side of the cabinet. If the door does not close correctly, loosen or tighten the adjustable feet, until the machine is � � �... -
Page 13: Water Hardness Level Adjustment Table
To Adjust the Water Hardness; 1. Move the programme selection knob to position 1 when the machine is turned off. 2. Press Start/Pause/Cancel button. 3. Press On/Off button while keeping the Start/Pause/Cancel button pressed to turn the machine on. Do not release the Start/Pause/Cancel button until “Water Hardness Level”... -
Page 14: Filling The (Water Softener) Dishwasher Salt
Filling the (water softener) Detergent use dishwasher salt Any brand of powder, gel and tablet detergents that have been designed for Only use special pelletized dishwasher household dishwasher, may be used. salt in your machine to soften the hard water. Never use other types of salts Keep detergents in a cool and dry including table salt, animal feeding salt, place and out of the reach of children. - Page 15 Warning! dishwasher. Always place the Two-in-one and three-in-one tablets in the detergent dispenser detergents of the detergent holder. You will obtain the best results from your dishwasher if you use separate Using three-in-one detergent, detergent, rinse aid and water- softening salt and rinse aid. softening salt.
-
Page 16: Filling Detergent Dispenser
Using two-in-one detergent and hardness shown in the manual. rinse aid • Put the rinse aid setting at the • These detergents will not give you correct level. the same drying performance that you can obtain by using separate detergent, salt and rinse aid. To increase the drying performance: •... -
Page 17: Rinse Aid
After you put in the detergent, shut the washing. Reduce it if there are sticky container lid (D) and ensure you hear whitish streaks on the dishes. the clicking sound. During the wash programme the Filling the rinse aid dispenser detergent will dispense automatically Open the rinse aid dispenser lid by and the lid (D) will remain open when... -
Page 18: Loading The Dishwasher
Loading the dishwasher Loading the dishwasher correctly will increase the washing, drying and energy performance of your machine. Examine the information given in this section and the information stated in the Programme chart and quick reference card given with the manual. Remove any large scraps of food from the dishes before placing in the dishwasher to avoid clogging the filters. -
Page 19: Folding Plate Support Rods
Folding plate support rods Movable Cutlery Basket There are two separate “folding plate Designed to allow free placement of support rods” in the lower basket of the dishes according to their size, the your dishwasher designed to allow movable cutlery basket can slide over you more space to accommodate the tines to the left (A) and right (B) saucepans and large bowls in the... -
Page 20: Upper Basket With Variable Height Setting
Upper basket with variable height setting The upper basket is equipped with a lifting mechanism which enables you to change the height of the basket without having to remove it from the dishwasher, even if it is fully loaded. � The height of the upper basket was set to its lowest position at the factory. -
Page 21: Operating The Dishwasher
Operating the dishwasher • Care must be taken if opening the Turn the water tap on. Open the door, as steam and water will escape. door of the machine. • Then after putting in the item, close Check that the upper and lower the door. -
Page 22: How To Clean Your Machine
How to clean your machine Cleaning your machine at regular intervals ensures longer product life and reduces the risk of recurring problems. Clean spray arms and in particular filters at least once a week ! Always unplug the appliance and turn �����������... -
Page 23: Upper Spray Arm
Clean all three filters under running tap Upper spray arm water with a brush. Turn the nut anti clockwise and remove both the nut and the spray arm. Reinsert the main filter in its place. Flush away food particles under Place the coarse filter into the micro running water. -
Page 24: Before Calling Service / Trouble Shouting
Before calling service / Trouble shouting Before calling service check the following & Trouble shooting guide supplied on the following page. � ������������������������������������� �������������������������� ������������������������ ������������������������������ � ��� ���� ���������� ������� ������ ������������������������������� ������ ���� ������������ ��� ����� ���������� ���������������������������������� ���������������������������... - Page 25 Remove spots with silver polish. Rewash. Wash soon Prolonged contact with salty Pitting of after use, or pre-wash items if they will not be washed or highly acidic foods or stainless steel right away. Do not overload cutlery basket. Avoid with undissolved or highly items spilling or pouring detergent directly on flatware.
-
Page 26: How To Obtain Service
How To Obtain Service Please keep your purchase receipt or other proof of purchase in a safe place; you will need to have it should the product require attention under guarantee. You should also complete the details below; it will help us assist you when requesting service. -
Page 27: Guarantee Details
• The cost of functional replacement parts, but excluding consumable items. • The labour costs of a BLOMBERG approved repairer to carry out the repair. What is not covered? • Transit, delivery or accidental damage or misuse and abuse. - Page 28 Blomberg, 36-38 Caxton Way, Watford, Hertfordshire, WD18 8UF Tel: 0845 6048340 Fax: 0845 6004922 email: service@blomberguk.com www.blomberguk.com...
