DSL-2740U
Wireless Module Parameters
Wireless connection rate
Transmitter output power
The maximum value of the
transmitter output
depends upon the
frequency regulations applied in
your country
Receiver sensitivity
Modulation schemes
· IEEE 802.11b: 1, 2, 5.5, and 11Mbps
· IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54Mbps
· IEEE 802.11n: from 6.5 to 300Mbps (from MCS0 to
MCS15)
·
802.11b (typical at room temperature 25 °C)
16.5 ~ 18dBm
·
802.11g (typical at room temperature 25 °C)
13.5 ~ 16.5dBm
power
radio
· 802.11n (typical at room temperature 25 °C)
13.5 ~ 16.5dBm
· 802.11b (typical at room temperature 25 °C)
-84dBm
·
802.11g (typical at room temperature 25 °C)
-72dBm
·
802.11n (typical at room temperature 25 °C)
HT20
-70dBm
HT40
-67dBm
·
802.11b: CCK (11, 5.5Mbps), DQPSK (2Mbps), DBPSK
(1Mbps), DSSS
·
802.11g: PSK/CCK, DBPSK, DQPSK, OFDM, BPSK,
QPSK, 16QAM, 64QAM
· 802.11n: PSK/CCK, DBPSK, DQPSK, OFDM, etc.
